The RISC-V Platform Specification aims to ensure RISC-V hardware and software compatibility

The RISC-V platform specification aims to define a set of rules to make sure operating systems like Linux or the Zephyr Project can boot properly on all RISC-V hardware compliant with the specs.

If you’ve ever worked with the Arm Linux kernel over ten years ago, you may remember board files, which were replaced by device tree bindings, and eventually, Arm defined several standards culminating with Arm SystemReady certifications allowing compliant Arm platforms to boot off-the-shelf OS images like in the x86 world.

While we are probably a long way from a “RISC-V SystemReady” platform certification program, the RISC-V platform specification is currently being worked on to define requirements for two types of platforms with optional extensions:

Eventually, there should/could be extensions for other types of hardware including “mobile”, “edge computing”, “machine-learning”, “automotive”, and so on.

Looking at the OS-A platform, there’s a long list of requirements with architecture (RV32GC/RV64GC), PMU, debugging, system peripherals, the boot processor with EBBR, UEFI (and ACPI for the Server extension), and many more.

You’ll find the current RISC-V platform specification on Github. If you’d like to participate in the specifications, submit patchsets, or simply follow the progress, you can do so on the tech-unixplatformspec mailing list, which contrary to what its name implies, is not only about UNIX-based operating systems anymore.

Via Drew Fustini
