Mediatek Unveils Sensio MT6381 6-in-1 Biosensor Module for Smartphones

Nearly exactly two years ago, Samsung unveiled S3FBP5A bio-processor for fitness tracking wearables with five analog frontends measuring PPG, ECG,skin temperature, BIA, and GSR data, and that is (or was?) expected in the company’s S-Patch3 health tracker.

Mediatek has now come up with something with similar functionalities, but instead of being a standalone bio-processor for wearables, Sensio MT6381 biosensor module is designed as a companion chip for smartphones, and capable for delivering 6 different types of heart and fitness data in about 60 seconds.

MediaTek Sensio key features and specifications:

• Integrated R and IR LEDs for reflective PPG measurement + 1-channel ECG analog front-end
• Health Data
  • Heart-rate in heart beats per minute
  • Heart-Rate Variability (variation in the time between heartbeats).
  • Blood Pressure Trends
  • Peripheral Oxygen Saturation (SpO₂) – amount of oxygen in the blood.
  • Electrocardiography (ECG) – electrical activity of the heart over a period of time
  • Photoplethysmography (PPG) – change in volume of blood.
• I²C /SPI digital interface
• Dimensions – 6.8 mm x 4.93 mm x 1.2 mm OLGA 22-pin package
• Total External BOM – 4 caps + 2 electrodes

The company explains roughly how it works, and how the user will be using the solution once embedded in a smartphone:

The module uses light emitting diodes (LEDs) in conjunction with a light sensitive sensor to measure the absorption of red and infrared light by the user’s fingertips. By touching a device’s sensors and electrodes with your fingertips, MediaTek Sensio creates a closed loop between your heart and the biosensor to measure ECG and PPG waveforms.

MediaTek Sensio will be available in early 2018. Visit the product page for a few more details.
