Rockchip RK3288 based Android Mini PCs and TV Boxes Are Starting to Show Up (Wholesale)

Rockchip RK3288 based devices should be available soon. At the end of last month, I read Pipo was about to introduce RK3288 Tablets at the Hong Kong electronics fair this month, and yesterday I’ve been informed some RK3288 mini PCs and TV Boxes had started to appear on Alibaba.

RK3288 HDMI TV Dongle (D368)

D368 mini PC is said to come with the following specs according to a product page on Alibaba:

• SoC – Rockchip RK3288 quad core ARM Cortex-A17 with Mali-T7xx 3D GPU (OpenGL ES 1.1/2.0 /3.0,and OpenCL 1.1)
• System Memory – 2GB DDR3  (Optional:1GB)
• Storage – 8GB NAND Flash (Options: 4GB and 16GB), micro SD card (up to 32GB)
• Video & Audio Output – HDMI 1.4a (Resolution 4K and 1080p60 support)
• Connectivity – Dual band Wi-Fi 802.11 b/g/n and 802.11ac, optional Bluetooth 4.0.
• Video Codecs
  • Decode – H.265, MPEG-1, MPEG-2, MPEG-4,H.263, H.264, AVS, VC-1, RV, VP6/VP8, Sorenson Spark, MVC
  • Encode – H.264, H.265,VP8, MVC(1080P)
  • Max H.264/H.265 datarate – 60 Mbps
• Audio Formats –  MP1,MP2,MP3,WMA,WAV,OGG,OGA,APE,FLAC,AAC,M4A,3GPP…etc
• USB – 2x USB 2.0 host ports, 1x micro USB for power.
• Power Supply – 5V/2A via micro USB
• Certification – CCC, CE, EMC, FCC, Wi-Fi
• Dimension – 110 x 40 x 12.9 mm

The dongle comes with a USB cable, an HDMI cable, a power adapter and a user’s manual by default. Options include a Y-type USB cable, a USB to Ethernet cable, an IR remote with an IR receiver (USB), and/or a 2.4GHz RF air mouse. There’s no price available yet.

RK3288 Android TV Box (B368)

B368 Android TV Box has the following specs, against according to its page on Alibaba:

• SoC – Rockchip RK3288 quad core ARM Cortex-A17 with Mali-T7xx 3D GPU (OpenGL ES 1.1/2.0 /3.0,and OpenCL 1.1)
• System Memory – 2GB DDR3
• Storage – 8GB NAND Flash, micro SD card (up to 32GB)
• Output – HDMI 1.4a (Resolution 4K and 1080p60 support), AV (CVBS) via 3.5mm jack
• Audio Output – HDMI, AV jack, 1x optical S/PDIF
• Connectivity – Gigabit Ethernet, dual band Wi-Fi 802.11 b/g/n and 802.11ac with external Wi-Fi antenna, and Bluetooth 4.0.
• Video Codecs
  • Decode – H.265, MPEG-1, MPEG-2, MPEG-4,H.263, H.264, AVS, VC-1, RV, VP6/VP8, Sorenson Spark, MVC
  • Encode – H.264, H.265,VP8, MVC(1080P)
  • Max H.264/H.265 datarate – 60 Mbps
• Audio Formats –  MP1,MP2,MP3,WMA,WAV,OGG,OGA,APE,FLAC,AAC,M4A,3GPP…etc
• USB – 2x USB 2.0 host ports, 1x micro USB  OTG port.
• Power Supply – 5V/2A via micro USB
• Certification – CCC, CE, EMC, FCC, Wi-Fi
• Dimension – 142.3 x 108.6 x 21mm

The specs are basically the same as the HDMI TV dongle, expect for the addition of AV output, optical S/PDIF, and Gigabit Ethernet, as well as the different dimensions. Both products are listed by the same company (Shenzhen Tena Electronics), and will run Android 4.4 Kitkat.

This Android TV box comes with an HDMI cable, a composite + stereo cable, an IR remote, a power adapter and a user’s manual by default. Options include an RF air mouse or an RF mouse and keyboard. There’s no price available yet, but AndroidPC.es recently wrote about G20, another upcoming RK3288 TV Box, running Aliyun OS, that should be available soon for 598 CNY, or about $97, in China. This price apparently includes a Wii-like remote. We’ll have to see how the market evolve, but it appears AMLogic S802 (4x A9 + Mali-450) and Rockchip RK3288 (4x A17 + Mali-T764) devices may have similar pricing.

ARM announced the first Cortex A17 based devices should become available in Q1 2015, but products based on Rockchip RK3288 may be available in a few weeks or a couple of months, so I wonder if we could end up with two kinds of RK3288, one with Cortex A12, and the other Cortex A17, as both cores are pretty similar.

Thanks to csgabe for the tip.
