$5 board eases ATX power supply connection to single board computers

Many people have ATX power supplies from older desktop PCs that they may want to reuse with Arduino boards, Raspberry Pi, or other single board computers. It’s indeed possible to do so by trimming some cables and making a circuit to protect the board from over-voltage or over-current. But ZJ-012 adapter board offers a simpler solution with a 24-pin header for the ATX power supply, terminal blocks for connection to the target board, some fuses for protection, and a header to connect an on/off button. JZ-012 (also known as JZ-024) ATX power adapter board’s key features and specifications: Power Input – 20-pin or 24-pin computer ATX power supply Power output – 9-pin terminal block with +3.3V, +5V, -12V, +12V, +5V, GND with fuses for each power outputs On/Off control – Toggle switch or header for external button/switch (shorted for power on) Misc – Power indicator (red LED) Dimensions – 70 […]

Posted on

CanLite ESP32 board for CAN Bus hacking support up to two high-side switches

Voltlog’s CanLite is not the first ESP32 CAN bus board we’ve covered here at CNX Software, having written about Olimex ESP32-EVB and CAN32 boards a few years ago. But the open-source hardware, compact CanLite board offers an alternative for CAN bus hacking with a built-in automotive-grade DC-DC converter as well as an optional two-channel high-side automotive-grade switches capable of switching up to 6A per channel. CANLite key features and specifications: Wireless module – ESP32-WROOM-32D module with Espressif ESP32-D0WD dual-core Tensilica processor, 4MB SPI flash, Wi-Fi 802.11 b/g/n up to 150 Mbps, Bluetooth 4.2 LE Terminal block for CAN Bus (ISO 11898-2 standard) up to 1Mbps via SN65HVD231 CAN transceiver. Output – High-side switching of the VBAT input up to 6A. (only if the option is purchased during checkout). Programming – 6-pin JST-SH VoltLink pin header Power Supply – 12V/0.5A via terminal block Dimensions – TBD The ESP32 CANLite board supports […]

ArmSoM CM5 Raspberry Pi CM4 alternative with Rockchip RK3576 SoC
Posted on

PandaZhu – ESP32 powered 3D Printer controller board supports Marlin 2.0 & ESP3D WebUI

Around two years ago, we noted beta Marlin 2.0 support for ESP32  and some initiatives to create ESP32 powered 3D printer controller boards with built-in WiFi connectivity. Now Marlin 2.0 firmware officially supports ESP32 boards such as FYSETC E4, E4d@BOX, or MRR ESPA. Another ESP32 based 3D printer controller board has now been brought to my attention. PandaZhu supports up to eight motor drivers, up to three heaters, up to three thermistors, one external LCD display, and on the software-side, the board is compatible with Marlin 2.0 as well as ESP3D WebUI. PandaZhu board’s specifications: Wireless module – ESP32-WROOM-32 based on Espressif ESP32 dual-core Xtensa processor @ 240MHz with 520 KB SRAM, plus 4MB flash Connectivity – 802.11b/g/n up to 150 Mbps, Bluetooth 4.2 3D printer peripherals Up to 8x motor drivers Up to 3x heaters Up to 3x thermistors  with 30°C to 250°C range, BLTouch auto-leveling sensor with a […]

Posted on

NodeMCU ESP32-C3 WiFi & BLE IoT boards show up for about $4

ESP32-C3 RISC-V IoT processor with 2.4 WiFI and Bluetooth LE 5.0 was unveiled in December 2020, and Espressif Systems’ own ESP32-C3-DevKitM-1  board has been available in limited quantities as an “engineering sample”. But now I’ve noticed third-party NodeMCU ESP32-C3 boards are being sold on Aliexpress for around $4 with ESP32-C3S_Kit and ESP-C3-01M-Kit both based on AI Thinker ESP32-C3 modules announced a few months ago. NodeMCU ESP32-C3S_KIt Specifications: Wireless module – AI Thinker ESP32-C3S (footprint compatible with ESP32-S / ESP32-WROOM-32D) with ESP32-C3 RISC-V processor @ 160 MHz, 2.4 GHz WiFi, Bluetooth 5.0 LE, 4MB flash, on-board PCB antenna, and IPEX connector (which may be soldered or not). USB – Micro USB port for power and programming via CH340C USB to TTL chip Expansion – 2x 15-pin headers with GPIO, SPI, UART, ADC, I2S, 3.3V, GND Misc – RGB LED, Reset key, user-programmable key Dimensions – 49 x 26 mm ESP32-C3S_Kit is […]

Posted on

Tiger Lake UP3 single board computer offers quad displays, 2.5 GbE, PCIe Gen4, up to 32GB RAM

Taiwan Commate Computer Inc, also known as just Commell, has unveiled LE-37O 3.5-inch single board computer based on Intel Tiger Lake UP3 embedded processors for industrial applications. The SBC supports up to 32GB DDR4 single-channel memory, up to four displays through DisplayPort, HDMI, VGA, and LVDS interfaces, and offers both Gigabit Ethernet and 2.5 GbE ports, as well as PCIe Gen4 via an M.2 socket. Commell LE-37O specifications: SoC – Intel Tiger Lake UP3 processor with Iris Xe graphics; FBCGA1449 package; 12-28W TDP; default: Core i7-1185G7E quad-core/octa-thread processor; option: Celeron 6305E dual-core processor System Memory – 1x 260-pin DDR4 3200 MHz SO-DIMM up to 32GB non-ECC, unbuffered memory Storage – 2x SATA III ports with RAID 0,1 support, M.2 and mSATA storage (see Expansion section) Video Outputs HDMI port DisplayPort port 24-bit dual channel LVDS connector with +3.3V/+5V/+12V supply; 1x LCD inverter connector VGA connector Quad independent display support Optional […]

Posted on

Art-Pi STM32H750 Cortex-M7 board supports RT-Thread, mainline Linux

I like to browse Linux changelog to learning about new features in the kernel, but also new hardware that made it into mainline Linux, even if only preliminary or partial. And in the just-released Linux 5.13, one board that caught my eye was Art-Pi, powered by an STMicro STM32H750 Cortex-M7 microcontroller without MMU (memory management unit) that was initially designed for RT-Thread real-time operating system. Art-Pi specifications: MCU – STM32H750XBH6 Value Line Cortex-M7 microcontroller @ 400 MHz, with 128KB flash, 16KB D/I cache, 864 SRAM, 64KB+128KB TCM with ECC correction System Memory – 32MB SDRAM Storage – MicroSD card slot, 16 MB SPI flash, 8MB QSPI flash Display – FPC connector for RGB888 displays Connectivity – SDIO WiFi 4 and UART Bluetooth via Ampak AP6212 module USB – 1x USB OTG Type-C port Debugging – On-board ST-LINK/V2.1 via USB-C DBG port Expansion – 2x 40-pin P1 & P2 headers with […]

Rockchip RK3568, RK3588 and Intel x86 SBCs and SoMs in 2025
Posted on

Coral Dev board news – NXP critical firmware update, manufacturing demo, and WebCoral in Chrome

Google Coral is a family of development boards, modules, M.2/mPCIe cards, and USB sticks with support with local AI, aka on-device or offline AI, based on Google Edge TPU. The company has just published some updates with one important firmware update, a manufacturing demo for worker safety & visual inspection, and the ability to use the Coral USB accelerator in Chrome. Coral firmware update prevents board’s excessive wear and tear If you own the original Coral development board or system-on-module based on NXP i.MX 8M processor, you may want to update your Mendel Linux installation with:

The update includes a patch from NXP with a critical fix to part of the SoC power configuration. Without this patch, the SoC might overstress and the lifetime of your board could be reduced. Note this only affects NXP-based boards, so other Coral products such as Coral Dev Mini powered by Mediatek MT8167S […]

Posted on

Olimex STM32MP1 SoM and evaluation board support Linux 5.10

Olimex has just announced the availability of an STMicro STM32MP1 Cortex-A7/M4 powered system-on-module (SoM) and an evaluator board with respectively STMP15X-SOM available in extended and industrial temperature variants, as well as STMP1(A13)-EVB evaluation board that works with the new STM32MP1 module, as well as earlier A13-SOM Allwinner A13 based system-on-module. Beyond the hardware, the company told us their upcoming STMP1-OLinuXino-LIME2 SBC could support mainline Linux in February, and the company prepared some Linux 5.10 based Debian Buster and Ubuntu Focal images which are now also available for the STMP15X-SOM module. STMP15X-SOM system-on-module Specifications: SoC – STMicro STM32MP151/153/157 dual-core Cortex-A7 @ 650 to 800MHz and Arn Cortex-M4 real-time core @ 209 MHz System Memory – 256 or 512 MB DDR3L Storage – MicroSD card socket Audio – On-module audio codec Board-to-board connectors GPIO-1 40-pin connector with 39 GPIOs, 3x UARTs, 1x QuadSPI, 2x I2C, 2x eMMC GPIO-2 10-pin connector with USB […]
