Posted on

SONOFF NSPanel Pro Android control panel doubles as WiFi & Zigbee Smart Home gateway

ITEAD has introduced the SONOFF NSPanel Pro Smart Home control panel running Android 8.1 on a Rockchip PX30 quad-core Cortex-A35 processor and acting as a Smart Home gateway thanks to an 802.15.4 radio for Zigbee 3.0, and 2.4 GHz 802.11b WiFi for connectivity. The NSPanel Pro follows the ESP32-powered SONOFF NSPanel introduced just last year but offers much more flexibility with Android, 2GB RAM, 8GB eMMC flash, and also offers a slightly larger 3.95-inch capacitive touchscreen display with 480×480 resolution. SONOFF NSPanel Pro specifications: SoC – Rockchip PX30 quad-core Cortex-A35 processor with Arm Mali-G31 GPU System Memory – 2GB DDR3 Storage – 8GB eMMC 5.1 flash Display – 3.95-inch capacitive touchscreen color TFT display with 480×480 resolution Audio – 1W speaker, digital microphone for two-way communication (intercom) Connectivity 802.15.4 radio with Zigbee 3.0 support. Matter and BLE Mesh scheduled for 2023 2.4 GHz 802.11b WiFi Sensor – Light sensor for […]

Posted on

Sonoff ZBDongle-E Zigbee 3.0 USB dongle features EFR32MG21 MCU with +20dBm radio

ITEAD has just released a new “ZBDongle-E” Zigbee 3.0 USB adapter with Silicon Labs Mighty Gecko EFR32MG21 Arm Cortex-M33 microcontroller with a +20dBm radio for extended range. The new dongle is an alternative to the popular Texas Instruments CC2652P-based Sonoff Zigbee 3.0 USB Dongle Plus, also known as “ZBDongle-P”, with a more compact design, and many of the same features. Sonoff ZBDongle-E specifications: Wireless MCU – Silicon Labs EFR32MG21 Arm Cortex-M33 multiprotocol wireless MCU @ 80 MHz with 64KB RAM, 768KB flash, +20 dBm 802.15.4 radio for Zigbee 3.0 and Thread support, and as well as a Bluetooth 5.1 Low Energy radio Connectivity – Zigbee 3.0 with SMA antenna connector, +20 dBm output power Host interface – USB port with CH9102F USB to TTL chip Expansion – 7-pin IO header with programming pins Misc – Boot and reset buttons, Zigbee LED, Power LED Power Supply – 5V/100mA via USB port, […]

ArmSoM RK3588 AIModule7 NVIDIA Jetson Nano-compatible SOM
Posted on

SONOFF POW Elite ESP32 WiFi power meter switch handles up to 20A load

SONOFF POW Elite is an ESP32-powered smart power meter switch that can handle up to 20A max load to monitor the power consumption of all appliances in a whole room. The data can be visualized in real-time on the built-in LCD or via the eWelink app, up to six-month of hourly power consumption history can be saved, and the system can also be integrated with third-party solutions such as a Home Assistant, IFTTT, and Alexa Energy dashboard. SONOFF POW Elite specifications: WiSoC – Espressif Systems ESP32 dual-core Xtenxa processor @ up to 240 MHz with 2.4 GHz WiFi 4 and Bluetooth 4.2 connectivity Wireless – 2.4GHz 802.11 b/g/n WiFi 4 (Bluetooth does not seem to be used) Power Input/Output POWR316D model – 100-240V~ 50/60Hz 16A Max POWR320D model – 100-240V~50/60Hz 20A Max Dimensions – 98 x 54 x 31mm (DIN Rail mountable) Casing Material – PC V0 (Tested with UL94v-0 […]

Posted on

SONOFF Zigbee Bridge Pro gateway supports up to 128 sub-devices

ITEAD has just introduced the SONOFF Zigbee Bridge Pro WiFi <-> Zigbee gateway as an upgrade to the Sonoff ZBBridge gateway launched in 2020. Both devices look exactly the same, and the changes are under the hood with the EFR32MG21 and ESP8266/ESP8285 combo being replaced by Texas Instruments SimpleLink CC2652P and ESP32 chips to boost the number of supported sub-devices from 32 to 128. Other changes include the addition of a buzzer acting as an alarm or doorbell chime, as well as a “built-in high-precision local RTC” for gateway time synchronization of local scene schedules. SONFF Zigbee Bridge Pro (aka ZB Bridge-P) specifications: Wireless MCUs Texas Instruments CC2652P SimpleLink Arm Cortex-M4F multiprotocol 2.4 GHz wireless MCU with integrated power amplifier Espressif Systems ESP32-DOWN-V3 dual-core processor with WiFi 4 and Bluetooth LE Wireless Connectivity – 2.4 GHz 802.11b/g/n WiFi 4 and Zigbee 3.0 Supports for up to 128 sub-devices Support for […]

Posted on

Sonoff ZBBridge gateway can be used as a Zigbee router/repeater

Sonoff ZBBridge WiFi to Zigbee gateway was introduced in April 2020, and a few months later got support for Tasmota ESP8266 firmware and Gecko firmware for either Home Assistant or Zigbee2MQTT support. But there’s now a new Tasmota firmware that converts Sonoff ZBBridge into a Zigbee router (a.k.a. Zigbee Signal Repeater or Zigbee Range Expender) following a request on Tastoma Github’s issue tracker from last year. The firmware, unofficial yet signed, was released a few days ago by xsp1989 Github’s user with a link to the firmware on Google Drive. Digiblur successfully tried it out on its own Sonoff Zigbee bridge and published the instructions. Assuming you already have Tasmota flashed to the device, switching to the router software is basically a firmware upgrade from the Tasmota web interface. Once the update is complete, you’ll still need to access the console in Tasmota in order to run a command to […]

Posted on

SONOFF releases HTTP API for SPM-Main power meter

SPM-Main is the main unit of Sonoff Smart Stackable Power Meter using RS485 to provide up to 128 relays. Besides support for the eWelink mobile app, we were promised an HTTP API at the time of the launch in September 2021. ITEAD kept its promises and has now released the HTTP API for the SPM-Main smart power meter to allow IoT home automation users and developers to control SONOFF devices via existing home automation open-source platform or local HTTP client. It’s the same REST API used for SONOFF MINI & R3 smart switches, but it adds support for power monitoring as well. The API allows you to switch between eWelink and DIY modes as needed, and provides the following functions: Device Status Broadcast – Returns the switch status of all channels with current, voltage, power, overload status, RS485 communication status, and more Get the List of Sub-device – List of […]

Advertisement

Posted on

Playing with Sonoff Zigbee & WiFi automation – Part 1: Hardware overview

I don’t think I’ve ever used Zigbee, but I’ll soon have the opportunity as ITEAD sent me the Sonoff ZBBridge gateway, a Sonoff T2 2-gang WiFi switch as well as a Zigbee motion sensor. I had reviewed several Sonoff devices in the past, but it had been over three years that I hadn’t. ITEAD recently contacted me basically telling me I could select whatever I wanted from their product list for a review on CNX Software. Since I had reviewed several of the company’s WiFi smart sockets, smart switches, and a light bulb, I had less to play with, and then I thought it might be fun to play with Sonoff Zigbee products. But I did not own any Zigbee hardware, so I had to think about a use case. I have a small annoyance in the house I rent. When we come back at night, we have to leave […]

Posted on

Sonoff NSPanel – A 3.5-inch HMI display for home automation (Crowdfunding)

You’ll soon be able to control all Sonoff smart switches, sockets, light bulbs, IP cameras, as well as Philips lighting solutions with the Sonoff NSPanel, a 3.5-inch HMI display supporting wall installation to US or EU standards. The ESP32 based touchscreen display integrates a dual-channel wall switch, supports Amazon Alexa, Google Home, or Yandex Alice voice assistants, and if you are not at home, you can still control your appliances with eWelink app for Android or iOS. Sonoff NSPanel specifications: WiSoC – Espressif ESP32-DOWD V3 dual-core Xtensa processor @ 160 MHz with 512KB RAM, 2.4 GHz 802.11n/g/n WiFi 4, and Bluetooth 4.2/5.x Display – 3.5-inch capacitive touchscreen display with 480×320 resolution Power Input – 100-240V @ 50/60Hz up to 4A Power Output – 100-240V @ 50/60Hz up to 2A per gang, or 4A in total LED Load 110V – 150W per gang, 300W total 220V – 300W per gang, 600W […]
