Posted on

PineSound is a development board for earbuds and digital audio players

You may have read Pine64’s April’s Fools spoof about the PineBuds and PinePod earlier this month. It turns out those will be real, and the Pine64 PineSound development board will be used to bring the PineBuds earbuds and PinePod digital audio player to market. The PineSound board features Bestechnic BES2300 Bluetooth 5.0 audio chip, two coaxial & optical input and output, a 3.5mm headphone jack, 4.4mm and 2.5mm balanced jacks, an SMA connector, a USB Type-C connector, plus interfaces for a touchscreen display. PineSound preliminary specifications: WiSoC – Bestechnic BES2300-YP dual-core Arm Cortex-M4F @ up to 300 MHz with HW DSP instruction, 992KB SRAM, 4MB flash, Bluetooth 5.0 dual mode. Supports hybrid ANC (active noise cancellation) and TWS (true wireless stereo). Note: the datasheet has been made available in the comments section. Display – LCD (should be SPI) and touch panel connectors Audio Coaxial & optical input (left) Coaxial & […]

Posted on

Apcsilmic Dot 1 – A Windows 11 Arm mini PC powered by Snapdragon 7c SoC

Apcsilmic Dot 1 is an affordable Snapdragon 7c powered Windows 11 Arm Mini PC that offers an alternative to ECS LIVA Mini Box QC710 Desktop Snapdragon 7c developer kit with extra features and resources. The Dot 1 mini PC comes with up to 8GB RAM, up to 256GB storage, dual HDMI output, as well as optional 4G LTE connectivity. It’s also thinner and remains fanless. Apcsilmic Dot 1 Mini PC specifications: SoC – Qualcomm Snapdragon SC7180 (Snapdragon 7c) with octa-core Qualcomm Kryo 468 (2x Cortex-A76, 6x Cortex-A55) CPU @ up to 2.4 GHz, Adreno 618 GPU Memory & Storage options 4GB RAM + 64GB storage 6GB RAM + 128GB storage 8GB RAM + 256GB storage MicroSD card on all variants Video Output – 2x HDMI ports up to 2K resolution (2560×1440) Audio – 3.5mm MIC jack, 3.5mm stereo audio jack Networking 10/100M Ethernet Dual-band WiFi 5, Bluetooth 5.1 with SMA […]

ArmSoM RK3588 AIModule7 NVIDIA Jetson Nano-compatible SOM
Posted on

OK3568-C SBC provides dual GbE, WiFi 5, 4G/5G connectivity, multiple display interfaces

Taking a break from the recent RK3588 news, let’s check out a board based on Rockchip RK3568 quad-core Arm Cortex-A55 processor with the Forlinx OK3568-C single board computer equipped with up to 8GB RAM and 64 GB storage. The board is comprised of the company’s FET3568-C system-on-module and OK3568-C carrier board offering multiple display interfaces, plenty of connectivity options with dual Gigabit Ethernet, WiFI 5, Bluetooth 5.0, as well as optional 4G or 5G cellular connectivity, and PCIe slots. OK3568-C specifications: FET3568-C SoM SoC – Rockchip RK3568 quad-core Cortex-A55 processor @ up to 2.0 GHz with Mali-G52-2EE GPU supporting OpenGL ES 1.1, 2.0, 3.2, Vulkan 1.0,1.1, OpenCL 2.0, 1 TOPS NPU, 4K H.264, H.265, VP9 VPU System Memory – 2GB (default), 4GB, or /8GB DDR4 Storage – 16GB eMMC flash 4x 80-pin board-to-board connectors with I/Os and power signals Supply Voltage – DC5V Dimensions –  70 x 45mm Temperature range […]

Posted on

Radxa E25 carrier board, 2.5GbE switch, and WiFi 6 router

I’ve just received an early sample of Radxa E25 dual 2.5 GbE carrier board for Radxa CM3 Plus (RK3568) system-on-module, a 2.5GbE TP-Link switch, and Xiaomi AX6000 WiFi 6 + 2.5GbE router. Here’s the back story before looking into the devices. I’ll soon have to review UP Xtreme i11 mini PC with a 2.5GbE port, and after writing about the upcoming ROCK5 Model B SBC with both 2.5GbE and WiFI 6/6E, I realized I should really get some hardware to test 2.5GHz and WiFi 6. So I started to ask what could be the best options for a $200 budget. While thinking about it, I remember Radxa was working on the Radxa E23 board with 2.5GbE, and adding a WiFi 6 USB dongle might be an option. But they told me Radxa E25 would be a better option with two 2.5GbE ports and support for WiFi 6, although that one […]

Posted on

PCIe 6.0 delivers up to 256 GB/s for Big Data applications

The PCI-SIG has just released the PCIe 6.0 specification reaching 64 GT/s transfer speeds, or 256GB/s, doubling the PCIe 5.0 specification data rate, and aimed at Big Data applications in the data center, artificial intelligence/machine learning, HPC, automotive, IoT, and military/aerospace sectors. PCIe 6.0 follows PCIe 5.0 announced in 2019 and can achieve the 256GB/s data rate in a 16-lane configuration. Implementation will take time, as even PCIe 5.0 is not widely used yet, and in the embedded space, I only found PCIe 5.0 in the recently announced Alder Lake-S Desktop IoT processors, with the Alder Lake Mobile IoT processors still being limited to PCIe 4.0. PCIe 6.0 highlights: 64 GT/s raw data rate and up to 256 GB/s via x16 configuration Pulse Amplitude Modulation with 4 levels (PAM4) signaling, leveraging existing PAM4 already available in the industry Lightweight Forward Error Correct (FEC) and Cyclic Redundancy Check (CRC) mitigate the […]

Posted on

Year 2021 in review – Top 10 posts and statistics

As per tradition, we’ll look back at what happened during the year in the last post, and see what 2022 may have in store, plus the usual statistics from CNX Software website. The biggest story of 2021 has to be the worsening of semiconductors shortages with extremely long lead times, prices of some components going up multiple folds, constant complaints on Twitter about availability and prices. I think I even saw a website, hopefully misconfigured, showing an estimated availability of a specific STM32 MCU in 2037. This also gave rise to opportunities and board redesigns, with MotorComm Ethernet chips replacing some Realtek chips in SBCs such as NanoPi R2C and  Orange Pi R1S Plus LTS, and CH9102F showing up as a replacement for CP2104 in some IoT boards. We also got some interesting Arm processors, but sadly the high-expected Rockchip RK3588 got delayed by another year, although it’s getting really […]

Rockchip RK3568, RK3588 and Intel x86 SBCs and SoMs in 2025
Posted on

UGOOS UT8 PRO – An RK3568 TV box with 8GB RAM, 64GB storage

UGOOS UT8 PRO is the first TV box I’ve seen with a Rockchip RK3568 processor, if we exclude Firefly Station P2 that’s more like an Arm Linux mini PC. The device runs Android 11 and is equipped with 8GB RAM, 64GB eMMC flash, and offers WiFi 6 connectivity. There’s also the “UGOOS UT8” with basically the same features except it ships with 4GB RAM and  32GB flash, and a dual-band WiFi 5 and Bluetooth module. We previously had seen TV boxes and mini PCs with the similar Rockchip RK3566 SoC in T95 Plus, H96 Max, and Zidoo M6, and the only reason for going with RK3568 in UGOOS UT8 (PRO) should be the extra USB 3.0 host/OTG interface, adding to the USB 3.0 host interface found in both RK3566 and RK3568 processors. UGOOS UT8 (PRO) specifications: SoC – Rockchip RK3568 with a quad-core Cortex-A55 processor @ up to 1.8/2.0GHz, Arm […]

Posted on

Allwinner Processor 2021-2022 Roadmap – Allwinner T827, T723 and T1033 SoC’s

Last year, we published the Allwinner A-series processor roadmap for 2020-2021 with notably Allwinner A33E, A100, and A200 SoCs. Allwinner A100 was supposed to be released in 2019, but a search on Aliexpress showed exactly zero matches. We did write about Allwinner A100 mainline Linux support a little while ago, and today, I eventually found one Allwinner A100 tablet with the $60 Hyundai HyTab 7WC1. I had no better luck in my search for Allwinner A33E and A200 platforms. But I also got lucky today with another Allwinner roadmap for 2021-2022 with some very interesting new processors, provided they happen. A look at 2020 processors But let’s look at the year 2020 first. We already have most details about Allwinner A133 quad-core Cortex-A53 processor, which is also called T509 apparently following the merging of the Allwinner A-Series business unit, focusing on tablets, into the Allwinner T-Series for industrial & automotive […]

Boardcon CM3588 Rockchip RK3588 System-on-Module designed for AI and IoT applications
