June 10, 2022June 10, 2022 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

ShaRPiKeebo handheld Linux computer based on Raspberry Pi Zero (2) W ships with a LoRa radio (Crowdfunding)

Raspberry Pi Zero portable Linux computer with LoRa

Morpheans ShaRPiKeebo is a portable Linux computer based on Raspberry Pi Zero W or Zero 2 W SBC that reminds me of the Allwinner R8 powered PocketCHIP handheld computer that was introduced in 2016, and was quite popular (for a niche product) at the time. The ShaRPiKeebo comes with a physical QWERTY keyboard, a daylight-readable screen, and Wi-Fi & Bluetooth connectivity, but also adds a 433 MHz LoRa radio that should make it usable as an off-the-grid communicator. Just like PocketCHIP, the ShaRPiKeebo can be used for system administration, retro-gaming, pen testing, STEM education, and all sort of maker projects. ShaRPiKeebo specifications: Supported SBCs via 40-pin GPIO header – Raspberry Pi Zero W, Raspberry Pi Zero 2 W, and (maybe) compatible SBCs like Radxa Zero or Banana Pi M2 Zero Display – 2.7- inch SHARP memory display (LS027B7DH01) with 400×240 resolution, low-latency, low-power Connectivity 802.11 b/g/n WiFi 4, Bluetooth 4.2 […]

June 9, 2022 by Jean-Luc Aufranc (CNXSoft) - 9 Comments

LimeSDR Mini 2.0 USB SDR board gets an upgrade to Lattice Semi ECP5 FPGA (Crowdfunding)

The LimeSDR Mini is an open-source hardware full-duplex USB SDR board based on Intel Altera Max 10 Altera FGPA that was introduced in 2017 on Crowd Supply and raised close to $2 million US dollars. Since it has been used in various projects including digital TV transmitters. Lime Microsystems is now back on Crowd Supply with the similar-looking LimeSDR Mini 2.0 replacing the MAX 10 FPGA with 16K logic gates with a more powerful and capable Lattice Semiconductor ECP5 FPGA with 44K logic gates while keeping the company’s LMS7002 RF transceiver. LimeSDR Mini 2 specifications: FPGA – Lattice Semi ECP5 (LFE5U-45F) with 44K logic gates, 108 sysMEM blocks (18kb), 1,944 Kb embedded memory, 351 Kb distributed RAM bits Storage – 4 MB flash memory for data; 2x128KB EEPROM for RF transceiver MCU firmware and data RF Lime Microsystems LMS7002M RF transceiver Tx & Rx SMA connectors Frequency range – 10 […]

June 9, 2022June 9, 2022 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Kodi 20 “Nexus” Alpha 1 gets AV1 hardware decoding, DietPi 8.5 released

I’ll combine two unrelated short news about software releases for TV boxes, Raspberry Pi, and other SBCs: Kodi 20 “Nexus” Alpha 1 media center, and DietPi 8.5 lightweight Debian-based image for SBC’s. Kodi 20 “Nexus” Alpha 1 The first alpha release of Kodi 20 “Nexus” is out with one highlight being support for AV1 hardware video decoding in Android and x86 (VAAPI) platforms with AV1-capable GPU or VPU. Other notable changes include: FFMPEG upgraded to version 4.4 Plenty of subtitle related changes: Added Steam Deck built-in controller support Initial support for M1 native including native windowing/input handling Pipewire support in Linux Various PVR improvements including in terms of performance when a large number of channels is displayed You’ll find more details in the announcement. The RetroPlayer project based on Kodi, but adding some game-related features, has also released some test images based on Kodi 20. Note that since it’s an […]

June 9, 2022June 9, 2022 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Bluetooth Auracast broadcast audio is the new name for Bluetooth LE audio sharing

Multi-stream and broadcast audio features part of the Bluetooth LE Audio standard have been given a brand name by the Bluetooth Special Interest Group (SIG). Meet Bluetooth Auracast broadcast audio, or simply Auracast for shorts. As a reminder, Bluetooth Audio LE broadcast enables an audio transmitter, be it a smartphone, laptop, television, or public address system to broadcast audio to an unlimited number of nearby Bluetooth audio receivers that could be speakers, earbuds, or even hearing devices. Auracast broadcast audio will let users invite others to listen to the same music without disturbing others around them, for example, a group of friends could listen to the music in the subway or on a bus through Auracast-enabled earbuds. Auracast will also be useful in public places, where for instance, users could listen to the audio from muted televisions at airports, gymnasiums, or train stations, and public announcements (e.g. gate changes, boarding […]

June 8, 2022June 9, 2022 by Sponsored Post - 23 Comments

Use your favorite laptop keyboard with the Techlabz Keybox (Sponsored)

The Techlabz Keybox allows you to re-use your favorite laptop keyboard over USB or Bluetooth. The solution support laptop keyboard from Dell, Asus, Apple, HP, Chromebook, and most other brands on the market. This is how it works. After disassembly of your laptop, or purchasing a replacement laptop keyboard, you can place your keyboard into the provided case, connect it with the provided FFC cable, and use it as a standalone USB or Bluetooth keyboard. Alternatively, you could also place it on top of your laptop palm rest and use it in lieu of the keyboard there. Techlabz Keybox features: Host interfaces USB Type-C port Bluetooth 4.1 LE + EDR Sensor – Ambient Light Detector Battery – 250 mAh/~1Wh battery The Techlabz Keybox also comes with a USB-A to USB-C adapter, a Keyboard Interface Adapter (KIA), an FFC Cable to connect to Keybox from the KIA, a keyboard case, some […]

June 8, 2022June 8, 2022 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

Renesas RZ/T2M dual Arm Cortex-R52 MPU delivers high-precision servo motor control

Built around two Arm Cortex-R52 cores clocked at up to 800 MHz, Renesas RZ/T2M microprocessor units (MPUs) target real-time, high-precision motor control applications such as AC servo drives and industrial robots. The RZ/T2M microprocessor also supports Ethernet with TSN and functional safety, and has been designed in such a way to reduce the number of external components in order to both decrease the BoM costs and the product size. Renesas RZ/T2M key features and specifications: CPU – Up to 2x Arm Cortex-R52 cores clocked at up to 800MHz, one core for motor control, and the other for networking Trigonometric function accelerator Memory – Tightly coupled memory 576KB with ECC, 2MB RAM with ECC Storage I/F – Octa/Quad SPI support Networking 3-port Gigabit Ethernet switch with TSN Industrial Ethernet: EtherCAT, PROFINET RT/IRT, EtherNet/IP, etc… Motor control 2-channel encoder interface with support for A-format, EnDat, BiSS, HIPERFACE DSL, Tamagawa Functional safety support […]

Rockchip RK3568/RK3588 and Intel x86 SBCs

June 8, 2022June 8, 2022 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

u-blox XPLR-IOT-1 explorer kit embeds cellular IoT, Wi-Fi, BLE, GNSS, and sensors for IoT evaluation

u-blox XPLR-IOT-1 explorer kit is an all-in-one IoT evaluation platform with cellular IoT, Wi-Fi, Bluetooth Low Energy, and GNSS, plus some sensors to evaluate various IoT products and enable proofs of concepts such as logistics container trackers, industrial automation, sensor-to-cloud applications, and fleet management solutions. The device’s main module is the u-blox NORA-B106 with a dual-core Arm Cortex M33 microcontroller and Bluetooth LE 5.2 radio that host the application software and control the other modules, namely the SARA-R510S module for LTE-M and NB-IoT cellular connectivity, NINA-W156 2.4 GHz Wi-Fi module, and the MAX-M10S GNNS module. The XPLR-IOT-1 platform is also equipped with an accelerometer, a gyroscope, a magnetometer, and temperature, humidity, pressure, and ambient light sensors. u-blox XPLR-IOT-1 specifications: Main MCU – Nordic Semi nRF5340 dual-core Arm Cortex M33 @ 128/64 MHz with 512 + 64 kB RAM memory and 1024 + 256 kB flash (found in NORA-B106 module) Wireless […]

June 8, 2022 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

MYIR MYC-J1028X CPU module features NXP LS1028A dual Cortex-A72 SoC with time-sensitive networking (TSN)

MYIR has introduced the MYC-J1028X CPU module based on NXP LS1028A dual Cortex-A72 processor with time-sensitive networking (TSN) support, as well as the MYD-J1028X development board with five Gigabit Ethernet ports, and other interfaces to evaluate the solution. The MYC-J1028X is equipped with 2GB DDR4, 8GB eMMC flash, a 32Kbit EEPROM, and a temperature sensor by default, and exposes all I/Os through a 314-pin MXM 3.0 edge connector. The module also comes with footprints to solder a QSPI NAND Flash, XSPI NOR Flash, and/or ECC memory. Typical applications include industrial routers, industrial control, edge computing, automotive electronics, industrial IoT, and more. MYC-J1028X CPU module MYC-J1028X SoM specifications: SoC – NXP Layerscape LS1028A (LS1028AXN7PQA) dual-core Cortex-A72 processor @ 1.5 GHz with 3D GPU, integrated TSN Ethernet switches and Ethernet controllers System Memory – 2GB DDR4 (optional 3GB / 4GB DDR4); optional DDR4 ECC Storage 8GB eMMC flash (optional 16GB / 32GB) […]
