Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on SOPHON BM1684/BM1684X Edge AI computer delivers up to 32 TOPS, decodes up to 32 Full HD videos simultaneously

SOPHON BM1684/BM1684X Edge AI computer delivers up to 32 TOPS, decodes up to 32 Full HD videos simultaneously

Sophon BM1684 BM1684X Edge AI computer

Firefly EC-A1684JD4 FD and EC-A1684XJD4 FD are nearly identical Edge AI embedded computers based on respectively SOPHON BM1684 and BM1684X Arm AI SoC delivering up to 32 TOPS of AI inference, and capable of decoding up to 32 H.265/H.264 Full HD videos simultaneously for video analytics applications. The BM1684(X) SoCs are equipped with eight Cortex-A53 cores clocked at 2.3 GHz to run Linux, and the systems come with up to 16GB RAM, 128GB flash, two Gigabit Ethernet ports to receive the video streams, one HDMI output up to 1080p30 for monitoring,  as well as RS232 and RS485 DB9 connectors, and a few USB ports. Firefly EC-A1684JD4 FD and EC-A1684XJD4 FD specifications: SoC – SOPHGO SOPHON BM1684/BM1684X CPU – Octa-core Arm Cortex-A53 processor @ up to 2.3GHz TPU BM1684 64 NPU arithmetic units with each NPU containing 16 EU arithmetic units, or 1,024 EU in total Up to 17.6 TOPS (INT8), […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Metal enclosures for the Raspberry Pi Compute Module 4 IO board

Metal enclosures for the Raspberry Pi Compute Module 4 IO board

Waveshare metal box for Raspberry Pi Compute Module 4 IO Board

I was informed about the “CM4 IO Computer” based on the official Raspberry Pi Compute Module 4 IO board housing in a metal enclosure along with the Raspberry Pi CM4 module. I initially thought it was new, but it’s been out at least since 2021. Nevertheless, it turns out there are at least two of this type of metal enclosures for the CM4 IO board, and when buying full systems, they may provide a way to source Raspberry Pi CM4 system-on-modules since individual modules are so hard to purchase if you are not a company with some minimum monthly production volume. As a development platform, the Raspberry Pi Compute Module 4 IO board is not optimized for cost or size, but there’s apparently enough demand that at least two companies – EDATEC and Waveshare – decided to make metal enclosures for them. EDATEC metal enclosure for the Compute Module 4 […]

ArmSoM RK3588 AIModule7 NVIDIA Jetson Nano-compatible SOM
Posted on by Jean-Luc Aufranc (CNXSoft) - 7 Comments on SONOFF TX Ultimate “T5” smart touch wall switch support gestures, custom covers

SONOFF TX Ultimate “T5” smart touch wall switch support gestures, custom covers

Sonoff TX Utimate TX Smart Touch Wall Switch

SONOFF TX Ultimate smart touch wall switch, also known as the SONOFF T5, is another wireless switch from the company with up to 3 gangs, RGB color edge lights around the 86x86mm switch, as well as support for gestures and custom covers. Gestures like swipe left or right are possible because the full area of the SONOFF T5 switch acts as a touch sensor, and the RGB LEDs around the device enable ambient lights in the room at night. The switch can also provide haptic feedback to the user during use with a built-in speaker and vibration motor. SONOFF TX Ultimate specifications: Model numbers – T5-1C-86, T5-2C-86, T5-3C-86 depending on the number of buttons Wireless – 2.4 GHz Wi-Fi Input and Output power 1-gang: 100-240V~50/60 Hz up to 5A 2-gang: 100-240V~50/60Hz up to 10A (5A per gang max) 3-gang: 100-240V-50/60 Hz up to 15A (5A per gang max) Dimensions – […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Cincoze P1201 – A slim Atom x6000E Elkhart Lake PC for embedded and panel PC applications with a CDS connector

Cincoze P1201 – A slim Atom x6000E Elkhart Lake PC for embedded and panel PC applications with a CDS connector

Elkhart Lake Embedded PC Panel PC

Cincoze P1201 is a slim embedded computer based on an Atom x6000E Elkhart Lake processor and mostly designed for panel PC applications thanks to the company’s patented CDS (Convertible Display System) connector that allows the mini PC to slide into the back of a display for easy installation. Equipped with up to 32GB RAM, SATA and/or mSATA storage, the P1201 can also be used for generic embedded and industrial applications thanks to DisplayPort and VGA video interfaces, two Gigabit Ethernet ports, optional wireless modules for WiFi, Bluetooth, and cellular, terminal blocks for RS232, RS485, and digital I/Os, as well as support for a wide supply voltage up 48V, and a -40°C to 70°C operating temperature range. Cincoze P1201 specifications: Elkhart Lake SoC (one or the other) Intel Atom x6425E quad-core processor @ 2.00 GHz / 3.0 GHz with 1.5MB cache, 32 EU UHD graphics; 12W TDP Intel Atom x6211E dual-core […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 8 Comments on ACEMAGICIAN T8PLUS – Processor N95 mini PC comes with three HDMI ports, dual GbE

ACEMAGICIAN T8PLUS – Processor N95 mini PC comes with three HDMI ports, dual GbE

ACEMAGICIAN T8PLUS

ACEMAGICIAN T8PLUS is an ultra-compact mini PC based on the latest Intel Processor N95 “Alder Lake N-Series” processor with three HDMI video outputs and dual gigabit Ethernet ports. The 8.9 x 8.9 x 4.3cm computer ships with 8GB LPDDR5 memory, a 256GB M.2 NVMe SSD, and is also equipped with three USB 3.0 ports, a WiFi 5 and Bluetooth 4.2 wireless module, and a 3.5mm audio jack, plus a Kensington lock slot.   ACEMAGICIAN T8PLUS specifications: SoC – Intel Processor N95 quad-core Alder Lake-N processor @ up to 3.4 GHz (Turbo) with 6MB cache, 16EU Intel HD graphics @ 1.2 GHz; TDP: 15W System Memory – 8GB LPDDR5 @ 4800MHz Storage – 256GB M.2 NVMe SSD Video Output – 3x HDMI 2.0b ports up to 4Kp60; triple independent display support Audio – 3.5mm audio jack, digital audio output via HDMI ports Networking 2x Gigabit Ethernet RJ45 ports Wi-Fi 5 and […]

Posted on by Sponsored Post - No Comments on Arylic BK501/651 bookshelf speakers integrate high-end AMT tweeters (Sponsored)

Arylic BK501/651 bookshelf speakers integrate high-end AMT tweeters (Sponsored)

Arylic Bookshelf Speakers

Arylic is better known for its connected audio devices such as the Arylic A50+ wireless amplifier or S50 Pro+ wireless stereo pre-amplifier, but the company has now launched its first passive speakers with the Arylic BK501 and BK651 bookshelf speakers that integrate high-end Heil AMT (Air Motion Transformer) tweeters. The BK501 is a pair of 5-inch speakers with 80W peak power, while the BK651 is a pair of 6.5-inch stereo speakers delivering up to 100W peak power. The specifications table below shows how both models compare. Both speakers support Treble up to 40kHz to feel detailed treble clarity and brightness, 180° wide soundstage, feature a fiberglass mid-woofer and received FSC Environmental Certification. Both designs include an MDF (medium-density fiberboard) cabinet with 15mm thick walls for the KB501 and 18mm thick walls for the BK651. Arylic says the Heil AMT tweeter found in its speakers uses a folded Kapton ribbon diaphragm […]

Rockchip RK3568, RK3588 and Intel x86 SBCs and SoMs in 2025
Posted on by Ian W MORRISON (Linuxium) - 9 Comments on iKOOLCORE R1 review – A quad 2.5GbE mini PC tested with Windows 11, Ubuntu 22.04, Proxmox

iKOOLCORE R1 review – A quad 2.5GbE mini PC tested with Windows 11, Ubuntu 22.04, Proxmox

iKOOLCORE R1 review

When I first saw the iKOOLCORE R1 I was fascinated that a mini PC of similar size to the smallest fully functional ones available (think Chuwi LarkBox, GMK NucBox or ECS LIVA Q Series) could be equipped with four 2.5 gigabit Ethernet (2.5GbE) ports. I approached iKOOLCORE who kindly provided an R1 for review and I’ve looked at performance running both Windows 11 and Ubuntu 22.04 and dabbled with using hypervisors on this mini PC through Proxmox virtual environment. iKOOLCORE R1 specifications iKOOLCORE list the R1 specifications on their website as: Of note are the ‘EC, FCC, RoHS’ certifications indicating both European conformity and approval for use in the US. Technically ‘EC’ refers to an ‘EC declaration of conformity’ which is not a certificate, however, the ‘EC declaration of conformity’ is called a ‘CE statement’ or ‘CE certificate’ which is why you often see this abbreviated as ‘CE’. The rest […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Rockchip RK3588 embedded PCs support PoE, 4G LTE, 10GbE, 2.5-inch SATA HDD, and more

Rockchip RK3588 embedded PCs support PoE, 4G LTE, 10GbE, 2.5-inch SATA HDD, and more

Mekotronics R58X-Pro embedded PC

Mekotronics R58X-Pro and R58X-HDD Rockchip RK3588 embedded PCs are updates to the company’s earlier R58X and R58X-4G mini PCs with features such as built-in PoE module, 4G LTE module, optional 10GbE M.2 PCIe 3.0 module, and a microSD card slot. The R58X-HDD also adds a 2.5-inch SATA bay for HDD or SSD, and the R58X-Pro implements a volume knob and a front panel display. Both R58X-Pro and R58X-HDD embedded PCs still come with up to 16GB RAM, 128GB eMMC flash, support dual 8K video output through HDMI and DisplayPort outputs, feature one HDMI 2.0 video input, two GbE ports, RS485 and RS232 interfaces, a few USB ports and more. Mekotronics R58X-Pro/R58X-HDD specifications: SoC – Rockchip RK3588 octa-core processor with four Cortex-A76 cores @ 2.4 GHz, four Cortex-A55 cores @ 1.8 GHz, an Arm Mali-G610 MP4 GPU, a 6TOPS NPU, 8K 10-bit decoder, 8K encoder System Memory – 4GB, 8GB, or […]
