Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Mini-ITX motherboard combines AMD Ryzen Embedded R2314 SoC with two InferX X1 AI accelerators

Mini-ITX motherboard combines AMD Ryzen Embedded R2314 SoC with two InferX X1 AI accelerators

InferX Hawk Mini-ITX motherboard AMD AI accelerators

Flex Logix has just announced the InferX Hawk mini-ITX motherboard equipped with an AMD Ryzen Embedded R2314 SoC and two InferX X1 AI accelerators from the company in order to help customers customize, build and deploy edge and embedded AI systems easily and quickly. The motherboard features up to 32GB RAM, supports SATA and M.2 MVMe/SATA storage, provides dual Gigabit Ethernet and optional WiFi/4F LTE connectivity, plus the usual USB 3.2, DisplayPort, and serial interfaces, and is meant to compete directly against solutions based on NVIDIA Jetson AGX Xavier.   InferX Hawk specifications: SoC – AMD Ryzen Embedded R2314 quad-core processor @ 2.1/3.5 GHz (Turbo) with hexa-core Radeon Vega graphics; TDP: 12 to 35W AI accelerators – 2x InferX X1 accelerators System Memory – 2x DDR4 SO-DIMM up to 32GB capacity Storage M.2 M Key socket for NVMe or SATA SSD SATA 3.0 connector Video Output – 2x DisplayPort Networking […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 19 Comments on Thin Mini-ITX networking board features six 2.5GbE ports, Celeron J6412 Elkhart Lake SoC

Thin Mini-ITX networking board features six 2.5GbE ports, Celeron J6412 Elkhart Lake SoC

Thin Mini-ITX networking board with 6x 2.5GbE

Powered by an Intel Celeron J6412 quad-core Elkhart Lake processor, the Jetway MI05-0XK thin mini-ITX networking board is equipped with six 2.5GbE ports, up to 16GB RAM via a single SO-DIMM socket, as well as M.2 sockets for storage, WiFi and/or cellular connectivity, some serial ports, and an optional HDMI port for video output. Four variants are offered: the standard MI05-00K model without eMMC flash nor TPM, the MI05-02K with a TPM 2.0 chip, the MI05-03K with a 32GB eMMC flash, and finally the MI05-07K with both the TPM 2.0 security chip and 32GB eMMC flash. Jetway MI05-0XK specifications: SoC – Intel Celeron J6412 quad-core Elkhart Lake processor @ 2.0 GHz / 2.6GHz (Burst frequency) with 1.5MB cache, 16 EU Intel UHD Graphics; 10W TDP System Memory – Up to 16GB DDR4-3200 via SO-DIMM socket Storage 1x SATA III (6 Gb/s) port 1x M.2 M-key 2242 SATA/PCIe Gen.3 x2 interface […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Acromag XMC-7A50-AP323 – An XMC module based on AMD Xilinx Artix-7 FPGA

Acromag XMC-7A50-AP323 – An XMC module based on AMD Xilinx Artix-7 FPGA

XMC Module Artix-7 FPGA

Acromag XMC-7A50-AP323 is an XMC (Switched Mezzanine Card) module based on a Xilinx Artix-7 FPGA with 48 TTL I/O channels plus a 16-bit ADC for 20 differential or 40 single-ended analog inputs. Designed for commercial off-the-shelf (COSTS) applications, Acromag XMC modules are RoHS compliant, and suitable for automation applications, scientific development labs, as well as aerospace and military applications. Acromag XMC-7A50-AP323 module specifications: FPGA – AMD Xilinx Artix-7 (XC7A050) FPGA with 52,160 logic cells, 65,200 Flip flops, 2,700 kb block RAM, 120 DSP slices Storage – 32Mbit QSPI flash memory FPGA Digital I/O 48x I/O channels controlled in groups of eight channels, 5V tolerant TTL, RS485, and LVDS interface options: Build Option A: 24x EIA-485/422 channels Build Option B: 24x TTL and 12x EIA-485/422 channels Build Option C: 24x LVDS channels Analog Input 20 differential or 40 single-ended inputs Flexible scan control 16-bit A/D resolution 8μs conversion time FIFO buffer […]

Posted on by Sponsored Post - Comments Off on How to repair a corrupted excel file in Microsoft Office 2007 and 2010 (Sponsored)

How to repair a corrupted excel file in Microsoft Office 2007 and 2010 (Sponsored)

Recovery Toolbox for Excel

Microsoft Excel comes with an already built-in repair tool called Open and Repair… The major and only task of the Recovery Toolbox for Excel is to fix and recover corrupted Excel files like the Open and Repair… function in Office 2007/2010. How To Manually Repair Microsoft Excel 2010 Files Here’s a well-detailed method on how to open and repair your Excel 2010 file: Select the file in the main menu Click on open Search for the damaged Excel 2010 file in the dialog section Click on the arrow beside the open button and select open and repair in the dropdown. Click on the Repair button to restore all the data. Wait for it to get restored. Perhaps the algorithm wasn’t able to get the damaged file fixed; click on extract data and formulae. The Excel file algorithm encourages you as a user to ‘convert to value’ or ‘Recover Formulas.’ If […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 21 Comments on Turing Smart Screen – A low-cost 3.5-inch USB Type-C information display

Turing Smart Screen – A low-cost 3.5-inch USB Type-C information display

Turing Smart Display

“Turing Smart Screen” is a low-cost 3.5-inch USB-C display that connects to systems with a USB port, and works with Windows, Linux (including Raspberry Pi), MacOS, and other operating systems that support Python3. But contrary to my initial assumptions, it does not exactly act as a second monitor, and instead, it is an information display, originally designed to show resource utilization, e.g. CPU and memory usage, in Windows, and controlled through commands send to the USB port. Turing Smart Screen specifications: 3.5-inch IPS display with 480×320 resolution, portrait and landscape support MCU – WCH CH552T 8-bit E8051 core MCU for USB devices Host interface – USB Type-C interface Auto start on power on Dimensions Product: 85 x 55 x 8 mm Display area: 74 x 49 mm The manufacturer says it works with Windows only using its own software, and not AIDA64. The Windows software features functions to change the […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 7 Comments on Arm SystemReady SR-certified Ampere Altra Developer Platform launched for $3,999

Arm SystemReady SR-certified Ampere Altra Developer Platform launched for $3,999

Ampere Altra Developer Platform

ADLINK has just announced the availability of the Arm SystemReady SR-certified Ampere Altra Developer Platform equipped with the company’s COM-HPC Ampere Altra module with 32 to 80 64-bit Arm Neoverse N1 cores, 32GB to 128GB RAM. An adaptation to the earlier AVA Developer Platform expected to sell for $5,450, the Ampere Altra Developer Platform got a price cut to $3,999 at launch for a system with a 32-core processor, and 32GB DDR4. The system targets software developers wanting to build cloud-to-edge applications using standardized Arm hardware. Ampere Altra Developer Platform specifications: SoM – COM-HPC Ampere Altra module with Ampere Altra 32 to 80-core 64-bit Arm Neoverse N1 processor up to 1.7/2.2/2.6 GHz (32/64/80 cores, TPD: 60W to 175W), 32 GB to 128GB DDR4 ECC memory Storage – 128 GB NVMe M.2 SSD Mainboard – COM-HPC Server Base carrier board Video – VGA port Audio – 3.5mm audio jack Networking 1x […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on INNOTECH AX-1020 Atom x6000E Elkhart Lake SBC targets fanless equipment

INNOTECH AX-1020 Atom x6000E Elkhart Lake SBC targets fanless equipment

INNOTECH AX-1020

Japan-based INNOTECH has announced the AX-1020 SBC based on Intel Atom x6000E Elkhart Lake processor designed for fanless industrial equipment, medical equipment, surveillance/security, and transportation applications. The board supports up to 16GB of RAM, SATA & NVMe storage, and is equipped with three display interfaces, two Gigabit Ethernet ports, six USB3.0/2.0 interfaces, one RS-485/422, and four RS-232C serial interfaces. INNOTECH AX-1020 specifications: Choice of Atom x6000E Elkhart Lake SoC Intel Atom x6425E quad-core processor @ 2.00 GHz / 3.0 GHz with 32 EU UHD graphics; 12W TDP Intel Atom x6413E quad-core processor @ 1.50 GHz / 3.0 GHz with 16 EU UHD graphics; 9W TDP Intel Atom x6211E dual-core processor @ 1.30 GHz / 3.0 GHz with 16 EU UHD graphics; 6W TDP System Memory – 4GB to 16GB DDR4 SO-DIMM (The company tells customers to contact them first when using 8GB or 16GB RAM) Storage – 1x SATA port, […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Lanner IIoT-I530 machine vision industrial PC comes with 6x PoE+ ports, dual 2.5GbE

Lanner IIoT-I530 machine vision industrial PC comes with 6x PoE+ ports, dual 2.5GbE

machine vision industrial PC

Lanner IIoT-I530 is a fanless machine vision IPC (Industrial PC) powered by a choice of Intel Tiger Lake UP3 processors and equipped with six PoE+ or LAN ports for IP cameras, as well as two 2.5GbE ports. The embedded computer also comes with up to 64GB DDR4 RAM, two COM Ports, four USB 3.0 ports, dual HDMI output, digital inputs and outputs, as well as M.2 sockets for WiFi 6 or/and 5G connectivity, plus NVMe SSD storage. Lanner IIoT-I530 specifications: SoC – 11th Gen Intel Core Tiger Lake UP3 up to Core i7-1185GRE quad-core CPU @ 1.8 GHz / 4.4 GHz (Turbo) with Intel Iris Xe Graphics System Memory – Up to 64GB DDR4 3200 RAM via 2x 260-pin SO-DIMM sockets Storage 1x SATA with 2.5-inch drive bay for SSD/HHD 1x mSATA socket, 1x M.2 M-Key 2280 PCIe Gen4 x4 socket for NVMe SSD 256Mbit SPI Flash for AMI BIOS […]
