September 6, 2016 by Jean-Luc Aufranc (CNXSoft) - 10 Comments

MinnowBoard Turbot SBC Gets a Quad Core Atom E3845 Processor, Better Ethernet, and a Fansink

MinnowBoard Turbot open source hardware SBC was released in 2015 with an Intel Atom E3826 dual core Bay Trail-I processor, 2GB RAM, SATA and Gigabit Ethernet support, and a new version – MinnowBoard Turbot Quad – with a more powerful quad core processor, an heatsink and fan, and better Ethernet connectivity will be launched in December. MinnowBoard Turbot Quad “MBT-4210” board specifications: SoC – Intel Atom E3845 quad core Bay Trail-I processor @ 1.92 GHz with Intel HD graphics @ 542 / 792 MHz (10W TDP) System Memory – 2GB DDR3L 1067 MT/s (Soldered) Storage – 1x SATA2 3Gbs, 1x micro SD card slot, , 8 MB SPI Flash for firmware (Tianocore UEFI, Coreboot, SeaBIOS) Video & Audio Output – 1x micro HDMI connector Connectivity – 10/100/1000M Ethernet RJ-45 connector (Intel i211 instead of Realtek NIC on first board) USB – 1x USB 3.0 host, 1x USB 2.0 host Debugging […]

December 31, 2015January 29, 2016 by Jean-Luc Aufranc (CNXSoft) - 18 Comments

Ten Most Popular Posts of 2015 and Statistics on CNX Software

In the second part of 2014, we saw a big jump in performance thanks to Cortex A15 and A17 based SoCs, and higher clocked Cortex A9 processors such as Rockchip RK3288 and Amlogic S812, but in 2015, TV box companies have focused on lowering the price and adding features such as HDMI 2.0, instead of looking for higher and higher CPU and GPU performance, and they’ve also moved to 64-bit ARM platform. Intel also continued its foray into low cost HDMI sticks and mini PCbased on Bay Trail, and later on Cherry Trail based devices. The development boards story was also very much about lower cosst with the $15 Orange Pi PC, follow a few months later by the $5 Raspberry Pi Zero, although people looking for performance at any price still saw the release of Nvidia Jetson TX1 board. It’s was also a big year for IoT with the […]

August 25, 2015 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

ECS LIVA X2 Braswell Mini PC Features Up to 4GB RAM, 64GB eMMC, Sells for $170 and Up

ECS LIVA was one of the first low power Intel mini PC that included both RAM and storage for less than $200 when it was first announced in March 2014. Since then there’s been a tidal wave of Bay Trail mini PCs hitting the market, and now that it’s time for Braswell and Cherry Trail lower system, ECS released LIVA X2 mini PC powered by Intel Braswell N3050 processor, that’s available for $169.99 on Newegg with 2GB RAM and 32GB storage, or $239.99 with 4GB RAM and 64GB storage. ECS LIVA X2 specifications: SoC – Intel Celeron N3050 “Braswell” dual core processor @ 1.6 GHz / 2.16GHz (Turbo) and Intel HD Graphics (6W TDP) System Memory – 2 or 4GB DDR3L (soldered) Storage – 32GB / 64GB eMMC flash, 1x M.2 for SSD (Up to 1TB) Connectivity – Gigabit Ethernet, WiFi 802.11ac and Bluetooth 4.0 Video Output – HDMI and […]

August 20, 2015August 20, 2015 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

MinnowBoard Turbot SBC Gets an Intel Atom E3826 Dual Core Processor, FCC & CE Certification

MinnowBoard MAX launched las year as a low cost board based on Intel Bay Trail-I single or dual core processor, and was mostly targeting developers of embedded systems and hobbyists, but could not be used by OEMs as it lacked FCC & CE certifications. ADI Engineering designed a MinnowBoard compatible board named MinnowBoard Turbot with a faster Intel Atom E3826 dual core processor, FCC & CE certifications, and various other hardware modifications bringing improved HDMI, a better voltage regulator, and populating several connectors. MinnowBoard Turbot specifications: SoC – Intel Atom E3826 dual-core processor @ 1.46 GHz (7W TDP) System Memory – 2GB DDR3L 1333 MT/s (Soldered) – Options: 1GB, or 4GB DDR3L Storage – 1x Micro SD card slot, 1x SATA2 3Gb/sec, 8 MB SPI Flash for firmware (Tianocore UEFI, Coreboot / SeaBIOS) Video & Audio Output – micro HDMI connector Connectivity – 10/100/1000M Ethernet RJ-45 connector USB – 1x […]

August 10, 2015September 22, 2015 by Jean-Luc Aufranc (CNXSoft) - 9 Comments

MeegoPad T04 Cherry Trail mini PC Sells for $136

Right after writing about MeegoPad T03 TV stick, I noticed another product on Amazon, namely MeegoPad T04 which for once is not based on a Bay Trail processor, but instead the newer Intel Atom x5-Z8300 Cherry Trail quad core processor, and which sells for $139 on Aliexpress or $136 on Amazon US. [Update: T04 is now sold on Gearbest for $123.99 with MGT04 coupon] Since the descriptions on Amazon and Aliexpress can’t be fully trusted, these are only tentative specifications for MeegoPad T04, which are quite similar to the ones listed for Tronsmart Ara x5: SoC – Intel Atom x5-Z8300 “Cherry Trail” quad core processor @ 1.44 GHz (Bust freq: 1.84 GHz) with Intel Gen8 HD graphics (2W SDP) System Memory – 2 GB Storage – 32 GB eMMC + micro SD slot Video Output – HDMI Audio I/O – HDMI, 3.5mm microphone jack Connectivity – Ethernet, 802.11 b/g/n Wi-Fi, […]

August 5, 2015August 5, 2015 by Jean-Luc Aufranc (CNXSoft) - 10 Comments

Mini Review of MeLE PCG01 Intel HDMI TV Stick

I reviewed MeLE PCG03 mini PC powered by Intel Atom Z3735F processor at the beginning of the year, and there are now many different models from manufacturer which all come with the same processor, 2GB RAM, and 32GB storage either in box or stick form factor. MeLE also released their own Bay Trail stick, similar to Intel Compute Stick, called MeLE PCG01, which they sent me for review. Most of these products are very similar, and all run Windows 8.1 by default, so the main differentiating factor between companies being price, whether they use a properly licensed version of Windows or not, and the thermal design of the enclosure, which may also impact performance as a good design will prevent CPU throttling. So in this review, after quickly checking the mini PC and accessories, I’ll take apart the device to check in more details what has been done to cool […]

July 6, 2015July 6, 2015 by Jean-Luc Aufranc (CNXSoft) - 17 Comments

$134 Voyo V2 mini PC Comes with 96GB Storage, a Larger Built-in Battery

Most low cost Windows mini PCs based on Intel Bay Trail-T processors ship with 32GB internal storage, but as I found out with MeLE PCG03 mini PC it gets filled pretty quickly. So a few mini PCs have started to increase capacity to 64GB, as was the case with Voyo mini PC, which also included a small battery, but with version 2 of Voyo the company has decided to go with a 32 eMMC combined with a 64GB SSD, and a 4,500 or 8,000 mAh battery. Voyo V2 specifications (Bold highlights show differences with Voyo V1): SoC – Intel Atom Z3735F “Bay Trail” quad core processor @ 1.33 GHz (Bust freq: 1.83 GHz) with Intel HD graphics System Memory – 2 GB DDR3 Storage – 32 GB eMMC + optional 64 GB SSD (depends on model) Video Output – standard HDMI 1.4b Audio Output – HDMI, and 3.5mm audio jack […]

June 1, 2015 by Jean-Luc Aufranc (CNXSoft) - 9 Comments

Dell Inspiron Micro Desktop with Intel Celeron J1800 or Pentium J2900 Starts at $180

We’ve already seen Chinese mini PCs based on Intel Bay Trail-D processors for less than $200, even with a 500 GB HDD as found in VX2 mini PC, but if you’d like to buy from a more established brand, Dell has launched two models of Inspiron 3050 Micro Desktop with Intel Celeron J1800 (dual core) and Pentium J2900 (quad core) selling respectively for $179.99 and $229.99 direct from Dell US, and they also have built-in Gigabit Ethernet and 802.11ac that you may not always find in the cheaper Chinese models. Beside the different processors, but models share the same specifications: SoC Intel Celeron J800 dual core processor @ up to 2.58GHz with Intel HD graphics Intel Pentium J2900 quad core processor @ up to 2.67 with Intel HD graphics System Memory – 2GB DDR3L @ 1600MHz (SO-DIMM slot, up to 8GB supported) Storage – 32GB SSD, SATA 3Gbps (up to […]
