RISC-V or Arm? This tiny 4x4cm Linux board with WiFi offers both options

Last fall, we wrote about Allwinner D1s/F133-A RISC-V processor and the upcoming MangoPi MQ1, a tiny 4x4cm board based on the processor. The board is not for sale, but we have more details, and the company is also working on an Arm version equipped with Allwinner T113-S3 dual-core Cortex-A7 processor that is pin-to-pin compatible with F133-A SoC. The Allwinner F133-A board will finally be called MangoPi Nezha-MQ, or MangoPi MQ for shorts, and come with 64MB on-chip RAM while the Allwinner T113-S3 board, with 128MB on-chip RAM, will be named MangoPi MQ-Dual. Both are fitted with a Realtek RTL8189-based Wi-Fi module, offer display and camera interfaces, two USB-C interfaces, and headers for GPIOs. MangoPi MQ RISC-V or Arm Linux board MangoPi MQ/MQ-Dual specifications: SoC (one or the other) MangoPi MQ – Allwinner D1s/F133-A 64-bit RISC-V processor @ 1 GHz with 64 MB DDR2 MangoPi MQ-Dual – Allwinner T113-S3 32-bit dual-core […]

February 3, 2022February 3, 2022 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

More Allwinner F1C200s ARM9 boards: MangoPi R3 and CherryPi-F1C200S

I wrote about the Widora TINY200 board based on Allwinner F1C200s ARM9 processor with 64MB built-in RAM, up to 512MB NAND flash, LCD and camera interfaces in April 2020. I was just informed more similar Allwinner F1C200s boards had recently shown up with Widora MangoPi R3 that’s basically the same as TINY200, and CherryPi-F1C200S with similar dimensions and features, but a different ports arrangement. Let’s have a look at both. MangoPi R3 MangoPi R3 specifications are the same as the ones for Tiny200 board, but they selected the 128MB NAND flash storage option, and changed the USB-TTL chip: SoC – Allwinner F1C200s ARM926EJS processor @ 420 MHz (overclockable to 700 MHz) with 64MB DDR RAM Storage – 128MB NAND flash and MicroSD card slot Display I/F – 40-pin RGB565 display interface and 6-wire touch interface Camera I/F – 24-pin DVP camera interface compatible with OV2640, GC0328, etc. Audio – Onboard […]

April 4, 2020May 16, 2020 by Jean-Luc Aufranc (CNXSoft) - 19 Comments

Widora TINY200 Allwinner F1C200s ARM9 Development Board Supports DVP Camera, Up to 512MB SD NAND Flash

Widora TINY200 is a tiny ARM9 development board equipped with Allwinner F1C200s with a DVP camera interface compatible with OV2640 / 5640 sensor, an audio amplifier, and various storage options from a 16MB SPI flash to a 512MB SD NAND flash. I first heard about the processor when I wrote about Microchip SAM9X60 ARM9 SoC last month, and some people noted there were other fairly new ARM9 SoCs around such as Allwinner F1C200s that also includes 64MB RAM so you can run Linux without having to connect external memory chips. Widora TINY200 V2 specifications: SoC – Allwinner F1C200s ARM926EJS processor @ 400-600 MHz (Overclockable to 900 MHz) with 64MB DDR1 RAM Storage – 16MB SPI NOR flash or 128MB NAND flash and MicroSD card slot or 512MB SD NAND flash. Display I/F – 40-pin RGB FPC cable for resistive touch screens; additional 6-pin FPC cable for capacitive touch support Camera […]

October 29, 2016October 29, 2016 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

ESP32 Updates – ESP32-S Module Replaces ESP3212, ESP32 DevBoards for Sale, Arduino & NodeMCU Support

There have been some developments with regards to Espressif ESP32 in the last month since my post about upcoming ESP32 development boards. First ESP3212 module is no more, and has been replaced with ESP32-S module with about the same features, but it’s not pin-to-pin compatible, so the new module won’t work with older breakout boards made for ESP3212. ESP32-S is now out of stock on Seeed Studio, but you’ll find it on IC Station, Banggood, and others shops. One good news is that it’s now easier to buy – or at least pre-order – ESP32 development boards, although stock may still be an issue, as the platform is very popular. If you live in the US, you can now backorder “Sparkfun ESP32 Thing” for $19.95. ESP32 board can be powered by either a micro USB power supply or a LiPo battery, and exposes close to 30 I/O pins. ESP32 developer […]

September 24, 2016 by Jean-Luc Aufranc (CNXSoft) - 16 Comments

Some ESP32 Development Boards to Look Out For: NodeMCU, Widora-air, Nano32, Noduino Quantum, and Wemos

Espressif ESP32 WiFi + BLE SoC launched at the very beginning of the month, shortly followed by ESP3212 module, and while Adafruit sold a few breadboard-friendly ESP32 development boards to developers for $15 a few days ago, stock was limited, and it’s not possible to easily purchase ESP32 boards today, and that’s OK because firmware and software support is still in progress. Several companies are working on such ESP32 boards however, and they tend to show the development progress on social networks, so I thought it would be fun to look at what’s coming… Amica (NodeMCU) ESP32 Board The current NodeMCU board is one of the most popular ESP8266 development platform, and that’s not surprising they are working on an ESP32 version. I don’t have pictures nor full specs of the board yet, but the company showcased their early work on ESP32 last June. Widora-air I only discovered Widora recently […]

September 14, 2016July 31, 2020 by Jean-Luc Aufranc (CNXSoft) - 12 Comments

Widora-NEO OpenWrt WiFi IoT & Audio Board is Based on Mediatek MT7688 SoC, WM8960 Audio DAC

A couple of weeks ago, I reviewed ReSpeaker board combining MediaTek MT7688 WiFi SoC with WM8960 audio DAC, running OpenWrt, and allowing you to perform tasks using text-to-speech and speech-to-text thanks to the built-in microphone (or optional microphone array), and a 3.5mm audio jack to connect speakers, as well as several I/O pins. It turns out there’s been board with similar features, minus the built-in microphone, available in China for a while. Meet Widora-NEO. Widora-NEO board specifications: SoC – Mediatek MT7688AN MIPS SoC @ 580 MHz with built-in WiFi System Memory – 128 MB RAM Storage – 16MB SPI flash, micro SD card Connectivity – 10/100M Ethernet, 802.11 b/g/n WiFi 1T1R up to 150 Mbps with PCB antenna, or IPEX connector Audio – 3.5mm jack for stereo headphone and mono microphone, WM8960G audio codec USB – 1x micro USB port for programming via CP2104 chip, 1x micro USB host (or […]
