Posted on by Jean-Luc Aufranc (CNXSoft) - 8 Comments on Waxberry Pi3 Rockchip RK3188 Development Board Includes a SATA Port

Waxberry Pi3 Rockchip RK3188 Development Board Includes a SATA Port

Development boards based on Rockchip RK3188 are a rarity, and until today, I only knew about Radxa Rock boards. Waxberry, a Chinese based company, already made some development boards such as Waxberry Pi2 based on Rockchip RK3066, and recently they’ve launched Waxberry Pi3 development board powered by Rockchip RK3188 processor, with 1 GB RAM, 8 GB flash, a SATA port, expansion headers and more. Waxberry Pi3 (aka WB-RK3188) specifications: SoC – Rockchip RK3188 ARM Cortex-A9 quad core @ 1.6Ghz + Mali-400 MP4 GPU System Memory – 1GB RAM Storage – 8GB NAND Flash (SK Hynix H27UCG8TETR) + micro-SD slot + SATA port Video Output – HDMI, LVDS connector, and AV output (TBC) Connectivity – 10/100M Ethernet port, 802.11b/g/n WiFi Audio I/O – HDMI, AV?, mic IN Camera – 24-pin CSI connector USB – 2x USB 2.0 host ports, 1x micro USB OTG Misc – IR sensor, RTC with battery slot […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 18 Comments on Waxberry Pi2 Development Board Based on Rockchip RK3066

Waxberry Pi2 Development Board Based on Rockchip RK3066

The other days I announced CubieTech and Olimex were working on low cost Rockchip development boards, but it turns out there’s already one on the market called Waxberrry Pi2, or WB-RK3066, made by Waxberry, a Chinese company. Here are the specifications of this development board: SoC – Rockchip RK3066 dual core Cortex-A9 processor @ 1.6GHz with Mali-400 MP4 GPU System Memory – 1GB DDR3 RAM Storage – 8GB NAND Flash + micro SD card slot USB – Standard USB OTG + Micro USB OTG; Connectivity: 10/100M Ethernet; WIFI 802.11b/g/n (MediaTek MT5931) Bluetoothv2.1+EDR (MediaTek MT6622) Video Output –  HDMI + AV Debugging – Serial port Misc – IR Sensor Dimensions – 72mm x72mm The board comes with a Mini HDMI cable, a 5V/2A power supply, a USB Data cable, and a USB-serial board for debug. There’s also a CD with the board schematics, Android 4.1.1 SDK and Linux Kernel 3.x source […]
