Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Variscite VAR-SOM-6UL System-on-Module Supports NXP i.MX 6UltraLite, i.MX 6ULL, or i.MX 6ULZ ARM Cortex-A7 Processor

Variscite VAR-SOM-6UL System-on-Module Supports NXP i.MX 6UltraLite, i.MX 6ULL, or i.MX 6ULZ ARM Cortex-A7 Processor

VAR-SOM-6UL Development Kit

Variscite has just announced the launch of the VAR-SOM-6UL System-on-Module (SoM) powered by a choice of NXP’s i.MX 6UltraLite / 6ULL / 6ULZ Arm Cortex-A7 processor clocked at up to 900MHz CPU clock and based on the company earlier DART-6UL module while integrating an additional LVDS bridge option, all packed in SO-DIMM200 form factor to fit the VAR-SOM Pin2Pin family. The module is optimized for power, size, and cost, and supports dual Ethernet, dual USB, audio, CAN Bus, camera, optional single or dual-band WiFi, Bluetooth BLE, Touch, ADC, PWM, as well as support for industrial temperature grades with -40 to 85°C range. Variscite VAR-SOM-6UL specifications & key features:  SoC – NXP i.MX 6UltraLite / 6ULL / 6ULZ ARM Cortex-A7 with optional security features up to 900MHz CPU Clock with 2D Pixel acceleration engine System Memory – Up to 1024 MB DDR3L Storage – 512 MB NAND / 64 GB eMMC […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on Variscite DART-MX8M is a Compact NXP i.MX 8M System-on-Module

Variscite DART-MX8M is a Compact NXP i.MX 8M System-on-Module

NXP has recently launched their i.MX 8M evaluation kit and released documentation, so we can expect multiple products based on the family in 2018. The new NXP i.MX 64-bit processors include three families with i.MX 8, i.MX 8X, and i.MX 8M, but so far it looks like many companies are launching products based on the latter. The Embedded World Conference 2018 at the end of February should be the occasion for many product launches, especially systems-on-module and related development kit, but several companies have already posted information about their i.MX 8(M) modules minus pricing, and one of those is Variscite DART MX8M a company (55x30mm) module with i.MX 8M processor, up to 4GB LPDDR4, up to 64GB eMMC flash, as well as 802.11ac WiFi and Bluetooth 4.0. Variscite DART-MX8M specifications: SoC – NXP i.MX8M with dual or quad core Cortex A53 processor @ up to 1.5 GHz, Cortex-M4 real-time core […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 5 Comments on Variscite DART-6UL SoM, an Alternative to Intel Edison Module

Variscite DART-6UL SoM, an Alternative to Intel Edison Module

Intel recently announced it will discontinue manufacturing and selling all SKUs of the Intel® Edison compute modules and developer kits. The initial version of Edison was released in the beginning of 2014, with a second version being released by the end of 2014. It was intended for the IoT market, with dimensions of 35.5x25x3.9mm. The Edison features an Intel Atom processor, consisting of two Atom Silvermont cores running at 500MHz. It includes a fixed configuration of 1GB integrated RAM, and 4GB eMMC flash on-board. Dual-band (2.4GHz and 5GHz) Wi-Fi, Bluetooth 4.0 and USB controllers complete the package. According to Intel’s announcement, the last shipment of Edison family boards is planned for December 2017. This announcement will have a critical impact on companies that already integrated the Edison board in their products, as well as the many companies that engaged in the development process of integrating the Edison board into their products. While some of these companies are rushing to place […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Variscite DART-SD410 Snapdragon 410 SoM Comes with WiFi 802.11 b/g/n, Bluetooth 4.1 & GPS

Variscite DART-SD410 Snapdragon 410 SoM Comes with WiFi 802.11 b/g/n, Bluetooth 4.1 & GPS

Qualcomm Snapdragon 410 is the 64-bit ARM processor used in DragonBoard 410c 96Boards platform, but it’s also found in several phones, some single board computers such as Inforce 6309, and we’ve also seen it in system-on-modules includes Graperain G8916 and Intrinsyc Open-Q 410. Variscite has developed their DART-SD410 system-on-module based on the processor with up to 2GB RAM, up to 16GB storage, and on-board 802.11b/g/n WiFi and Bluetooth 4.1. DART-SD410 module specifications: SoC – Qualcomm Snapdragon 410 quad core Cortex A53 processor @ 1.2GHz with Adreno 306 GPU @ 400 MHz System Memory – 1 to 2GB LPDDR3 @ 533 MHz Storage – 8 to 16 GB eMMC 4.5 flash Connectivity – WiFi 802.11 b/g/n + Bluetooth 4.1 LE (WCN3620), GPS (WGR7640), and two u.FL antenna connectors Audio – PM8916 PMIC/Audio codec I/Os available via 2x 90-pin board-to-board connectors: Display 4-lane DSI up to 720p60/1080p30, 24-bit On-carrier DSI to HDMI […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Variscite DART-MX6 is a Tiny SoM with Freescale i.MX6 SoC, Wi-Fi and Bluetooth

Variscite DART-MX6 is a Tiny SoM with Freescale i.MX6 SoC, Wi-Fi and Bluetooth

Variscite has unveiled what they claim to be the world’s smallest i.MX6 SoM with DART-MX6, a 50x20mm system-on-module featuring Freescale i.MX6 dual or quad processor, up to 1GB RAM, up to 32GB eMMC flash, as well as a wireless module for Wi-Fi and Bluetooth connectivity. Other small i.MX6 modules include TechNexion PICO-iMX6, or SolidRun microSoM found in Hummingbird board, and DART-MX6 has indeed the smallest area among the three. DART-MX6 specifications: SoC- Freescale i.MX6 dual or quad core Cortex A9 processor up to 800 MHz with Vivante GC2000 3D GPU System Memory –  512 to 1024 MB LPDDR2 (PoP) Storage – 4 to 32GB eMMC flash, 4KB I2C EEPROM Connectivity – Wi-Fi 802.11 a/b/g/n + MIMO, Bluetooth 4.0  BLE (TI WL183xMOD WiLink) Audio Codec – Texas Instruments TLV320AIC3106 Interfaces and I/Os via 2x 80-pin and 1x 50-pin board to board connectors Camera Interfaces – 1x CSI, 2x CPI Display – […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Variscite Introduces TI Sitara AM437x SoM with Bluetooth and Wi-Fi

Variscite Introduces TI Sitara AM437x SoM with Bluetooth and Wi-Fi

News about Texas Instruments Sitara AM437x processors first surfaced in 2012, before being officially announced last summer. Beside TI’s own development kits, I had not seen any hardware based on the company’s Cortex A9 industrial processor, but Variscite has now unveiled their VAR-SOM-AM43 systems-on-module (SoM) powered by AM4376 , AM4378, or AM4379 SoCs. VAR-SOM-AM43 specifications: SoC – Texas Instruments AM437x single core ARM Cortex A9 processor @ 1.0GHz: AM4376 – No GPU, 4x PRU @ 200 MHz AM4378 – PowerVR SGX530 GPU, 4x PRU @ 200 MHz AM4379 – PowerVR SGX530 GPU, 4x PRU @ 200 MHz, and EtherCAT slave support System Memory – 256MB to 1GB DDR3 Storage – 0 to 512MB SLC NAND flash, and 4GB to 32GB eMMC flash b module. 3x SD/MMC via edge connector Display Interfaces – 24-bit RGB interface up to 1400×1050 resolution; 4/5-wire resistive touch support Connectivity  – 10/100/1000 Mbps Ethernet PHY + […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Variscite VAR-SOM-SOLO is a Tiny System-on-Module Based on Freescale i.MX6 Solo Processor

Variscite VAR-SOM-SOLO is a Tiny System-on-Module Based on Freescale i.MX6 Solo Processor

Freescale will soon announce i.MX6 SoloX dual core processor with ARM Cortex A9 and M4 cores, and dual-port gigabit Ethernet, but companies still design and manufacture new Freescale i.MX6 Solo/Dual/Quad based hardware for their mostly industrial customers. Variscite has recently launched a smaller version of their VAR-SOM-MX6 system-on-module called VAR-SOM-SOLO powerd by Freescale i.MX6 Solo processor with up to 1GB RAM, up to 512MB NAND flash for boot code, up to 64GB eMMC flash for storage, and TI WiLink8 module with Wi-Fi and Bluetooth Smart. Variscite VAR-SOM-SOLO technical specifications: SoC – Freescale i.MX6 single core ARM Cortex-A9 core @ 1.0GHz with Vivante GC 880 + Vivante GC 320 GPU, and VPU supporting 1080p30 H.264 encode and decode. System Memory – 256MB to 1GB DDR3 RAM Storage – 128MB to 512MB NAND flash for boot code, 4GB to 64GB eMMC flash, and SD/MMC via edge connector Video Output / Display Interfaces: […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Variscite VAR-SOM-SD600 System-on-Module Features Qualcomm Snapdragon APQ8064 SoC

Variscite VAR-SOM-SD600 System-on-Module Features Qualcomm Snapdragon APQ8064 SoC

It turns out Compulab is not the only (Israeli) company to have announced a Qualcomm Snapdradon 600 CoM this month, as Variscite has unveiled VAR-SOM-SD600 system-on-module with Qualcomm APQ8064 quad core SoC, up to 2GB DDR3, up to 64GB eMMC, Wi-Fi and Bluetooth BLE connectivity, and various signals available via  a 314-pin MXM 3.0 connector. VAR-SOM-SD600 / VAR-SOM-APQ8064 specifications: SoC – Qualcomm Snapdragon 600 (APQ8064) quad core Krait 300 processor @ 1.7GHz with Adreno 320 GPU and Hexagon QDSP6 DSP System Memory – Up to 2GB DDR3 (Options: 512 MB , 1024 MB) Storage – Up to 64GB on-board eMMC (Options: 4 GB, 8 GB, 16 GB). 2x SD / MMC and SATA 1.5Gbps interface (via connector) Display HDMI 1.3a, up to 1920 x 1080 LVDS, up to 2048 x 1536 24-bit DSI, up to 2048 x 1535 24-bit Audio – Headphone driver, analog/digital microphone, Line In/Out, I2S interface, WCD9311 audio codec. Camera […]
