v-by-one

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Tiger Lake embedded Box PC offers V-by-One and eDP Interfaces

Tiger Lake embedded Box PC offers V-by-One and eDP Interfaces

Embedded Box PC V-By-One & eDP

Distec BoxPC Pro NPA-2009 is an embedded Box PC powered by a Celeron 6305E, Intel Core-i3 1115G4E,  Core i5-1145G7E, or Core-i7-1185G7E  Tiger Lake processor that offers both V-by-One and eDP interfaces to connect to high-resolution displays. The system supports up to 64GB RAM, NVMe stoage, dual Gigabit Ethernet, and optional WiFi and cellular connectivity, and is suitable for info terminals, medical equipment, and transportation applications. Distec BoxPC Pro NPA-2009 specifications: Tiger Lake SoC (one or the other) Intel Core i5-1145G7E (default) quad-core/8-thread processor @ 1.50 GHz / 4.10 GHz (Turbo) with 80 EU Intel Iris Xe Graphics; TDP: 12W to 28W Intel Core i7-1185G7E quad-core/8-thread processor @ 1.80 GHz / 4.40 GHz (Turbo) with 96 EU Intel Iris Xe Graphics; TDP: 12W to 28W Intel Core i3-1115G4E  dual-core/4-thread processor @ 2.20 GHz / 3.90 GHz (Turbo) with 48 EU Intel UHD Graphics; TDP: 12W to 28W Intel Celeron 6305E dual-core […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Amlogic T972 multimedia networking SBC supports 4K V-by-One displays

Amlogic T972 multimedia networking SBC supports 4K V-by-One displays

Amlogic T972 board

We’ve seen plenty of Amlogic S-series TV boxes and SBCs over the years, but Amlogic also manufacturer T-series SoCs designed for televisions. Since there are relatively few TV manufacturers compared to TV boxes or board manufacturers we seldom read about those. But a few years ago, we noticed a TV box based on Amlogic T962E quad-core Cortex-A53 processor offering both HDMI input and output ports, and now Shenzhen Tomao just informed me they were offering an Amlogic T972 multimedia network SBC for digital signage applications with multiple HDMI inputs and a V-By-One display interface with support for up to 4K resolutions. Amlogic T972 SBC specifications: SoC – Amlogic T972 (or T962X2) quad-core Arm Cortex-A55 processor @ 1.98 GHz with Arm Mali-G31 MP2
 GPU with support for OpenGL ES 3.2, Vulkan 1.1 and OpenCL 2.0 System memory – 2GB or 4GB DDR4 Storage – 16GB eMMC flash, MicroSD card socket Display […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 5 Comments on Amlogic S922X Digital Signage Board Comes with HDMI, LVDS, V-by-One, and eDP Video Interfaces

Amlogic S922X Digital Signage Board Comes with HDMI, LVDS, V-by-One, and eDP Video Interfaces

Amlogic S922X Digital Signage Board

Thanks to its 4K video playback and output capability and high-speed interfaces such as PCIe, USB 3.0 and Gigabit Ethernet, Amlogic S922X is a suitable processor for 4K digital signage players. One way is to get a TV box optimized for signage applications such as Rikomagic MK25, but if you want to integrate a board into your own display, XYT-6689 SBC may be an interesting option with LVDS, V-by-One and eDP (embedded DisplayPort) display interfaces, as well as many other features. XYT-6689 S922X digital signage board specifications: SoC – Amlogic S922X hexa-core big.LITTLE processor with 4x Arm Cortex A73 cores @ up to 2.0 GHz, 2x Arm Cortex A53 cores, Arm Mali-G52MP6 (6EE) GPU; 12nm manufacturing process System Memory – 2GB or 4GB LPDDR4 Storage – 16GB to 64GB eMMC flash, microSD card slot up to 128 GB; maybe SATA (unsoldered “laptop” SATA interface on the backside of the board) […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 5 Comments on 4K Digital Signage Player Drives up to 4x 4K Displays with AMD Ryzen Embedded V1000 SoC

4K Digital Signage Player Drives up to 4x 4K Displays with AMD Ryzen Embedded V1000 SoC

AMD Ryzen Embedded V1000 Digital Signage

We’ve covered plenty of AMD Ryzen Embedded V1000 SBC‘s, as well as some mini PC‘s, but the processor’s multimedia capabilities make it an ideal candidate for advanced digital signage players capable of driving multiple 4K displays. Axiomtek leveraged those capabilities in DSP600-211 4K digital signage player that offers four HDMI ports driving up to four 4K displays, as well as dual Gigabit Ethernet. Axiomtek DSP600-211 4K digital signage specifications: SoC (one or the other) AMD Ryzen Embedded V1605B quad-core/octa-thread processor @ 2.0GHz / 3.6 GHz (Boost) with AMD Radeon Vega 8 Graphics; 12-25W TDP AMD Ryzen Embedded V1807B quad-core/octa-thread processor @ 3.35GHz / 3.8 GHz with AMD Radeon Vega 11 Graphics; 35-54W TDP System Memory – 2x DDR4-2400 SO-DIMM up to 16GB Storage – 1x M.2 Key M 2280 (SATA) and 1x M.2 Key M 2280 (NVMe) Video Output – 4x HDMI 2.0 ports up to 4K @ 60 Hz […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 16 Comments on Allwinner A-Series Processors 2020-2021 Roadmap – Allwinner A33E, A100 and A200 SoCs

Allwinner A-Series Processors 2020-2021 Roadmap – Allwinner A33E, A100 and A200 SoCs

We previously discussed Allwinner business units where each can share the same silicon (with different a name) but maintains its own software stacks for different target applications. Allwinner A-Series is the most well-known as Allwinner A10 & A20 were very popular SoC for tablets and TV boxes many years ago. CNX Software received two slides that originated from Allwinner this morning. The first one shows the different Allwinner processor families, and the second provides a roadmap for A-Series processors for tablets with A33E, A100, and A200 coming this year and next. Let’s go through the Allwinner processor families first and their main use case: R-Series and MR-Series – Smart home applications A-Series – Tablets VR-Series – Virtual reality H-Series and F-Series- High-performance applications like multimedia (TV boxes) T-Series- Automotive, I suppose mostly infotainment V-Series – Camera SoCs XR/XIN-Series – Wireless chips like the infamous XR819 WiFi chip. AXP – PMIC […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 14 Comments on Socionext HV5 Series HDMI 2.1 Video Processing ICs Enable 8K TVs and STBs

Socionext HV5 Series HDMI 2.1 Video Processing ICs Enable 8K TVs and STBs

SocioNext HV5 Series HDMI 2.1 Processor

HDMI 2.1 specification was released late last year with the main benefit being the support of 8K videos at up to 120 Hz, and a small downside with the requirement for new 48G cables.  Samsung Q900R is one of the first 8K TV on the market, but according to the product page HDMI 2.1 is not supported just yet: Will provide complimentary upgrade for HDMI 2.1 support when available. Please contact customer support for more details So it looks like the Quantum Processor 8K processor found in the TV will be firmware upgradable to support HDMI 2.1. Anyway for 8K video equipment to be useful we’ll need video equipment to support HDMI 2.1 Tx & Rx, and SocioNext has launched what it claims are the first HDMI 2.1 compliant video processor ICs with their HV5 series. The processor family comes with HDMI Tx and Rx with two main series: Interface […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on Amlogic T968 Processor is Designed for Smart 4K UHD TVs and Smart Projectors

Amlogic T968 Processor is Designed for Smart 4K UHD TVs and Smart Projectors

Amlogic T968

Amlogic S-series processors are the most well-known processors by Amlogic with parts like S905X or S912, but the company is also offering other families with the new A-series for smart audio applications, and T-series processor for televisions. The latter have been around for a while, and also include HDMI inputs and digital TV tuners. We hear less about them since they are embedded into more expensive devices like Smart TVs or Android projectors, although in some cases they get into TV boxes with HDMI such as Alfawise H96 mini TV box powered by Amlogic T962E processor. Today, I’ll have at one of the top TV processor from Amlogic: T968 with four Cortex A53 cores clocked at up to 1.8 GHz, and an Arm Mali-T830MP2 GPU. Amlogic T968 processor key features and specifications: CPU – Quad core Arm Cortex-A53 processor clocked at up to 1.8 GHz GPU – Arm Mali-T830MP2 GPU […]
