Posted on by Jean-Luc Aufranc (CNXSoft) - 8 Comments on UNISOC Unveils T7520 5G SoC Manufactured with 6nm EUV Process Technology

UNISOC Unveils T7520 5G SoC Manufactured with 6nm EUV Process Technology

UNISOC T7520

UNISOC has launched its second-generation 5G mobile SoC with T7520 processor manufactured with a 6nm EUV process technology and equipped with four Arm Cortex-A76 cores, four Arm Cortex-A55 cores, as well as an Arm Mali-G57 GPU, and the company’s Makalu 5G platform. T7520 processor is said to support “coverage enhancement for any application scenario, by allowing carriers to deploy 5G on their existing 4G spectrums” (aka NSA = Non-stand Alone). and is optimized for use on 500 km/h high-speed railway. Highlights of the processor include: Advanced 6nm EUV process technology with extremely high lithographic resolution and a better balance between cost, performance and power consumption. Compared to the previous 7nm process, the new process has an 18% improvement in density of transistors and reduces power consumption by 8%. Lower power consumption made possible by the improved process mentioned above as well as an improved low-power consumption architecture and AI-based power […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 9 Comments on UNISOC V5663 Arm Cortex-M33 AIoT SoC Comes with 802.11 b/g/n/ac WiFi 5, Bluetooth 5.1

UNISOC V5663 Arm Cortex-M33 AIoT SoC Comes with 802.11 b/g/n/ac WiFi 5, Bluetooth 5.1

UNISOC V5663

UNISOC has launched a new processor for AIoT (Artificial Intelligence + IoT) applications with V5663 dual-core Cortex-M33 processor, supports for dual-band WiFi 5, Bluetooth 5.1, and audio features such as a voice activity detector and microphone array support which should make it ideal for smart speakers, and other smart audio applications. UNISOC V5663 WiSoC specifications: CPU Arm Cortex-M33 processor @ 442 MHz with TrustZone, 32KB I-cache, 32KB D-Cache for application code Arm Cortex-M33 processor @ 416 MHz for WiFI and Bluetooth Memory – Built-in SRAM + external PSRAM interface Storage – eMMC, SDXC interfaces Connectivity – Dual-band 802.11 b/g/n/ac WiFi 5 2×2 MIMO Bluetooth 5.1 dual-mode (Classic + LE) Mesh Networking for WiFi and Bluetooth Indoor Positioning – WiFi RTT, Bluetooth direction finding (AoD / AoA) Audio – Voice Activity Detector (VAD), PDM and I2S/PCM interfaces Peripherals: USB 2.0 / 3.0, eMMC I2C, SPI, HS SPI, UART GPIO, PWM IR […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on UNISOC Tiger T710 Processor with NPU for AI Edge Applications Tops AI-Benchmark Leaderboard

UNISOC Tiger T710 Processor with NPU for AI Edge Applications Tops AI-Benchmark Leaderboard

Tiger T710

Last April, UNISOC introduced Tiger T310 quad-core Cortex-A75/A55 processor for 4G Phone, and the company has now added a new member to their Tiger family with T710 octa-core processor with four Cortex-A75 cores, four Cortex-A55 cores, and a dedicated NPU (Neural-network Processing Unit) for artificial intelligence applications at the edge in the industry, commerce, medical care, home, and education sectors. The company did not setup a product page, so information is really limited. Known features & specifications so far: CPU – 4x Arm Cortex-A75 cores at up to 2.0GHz, 4x Arm Cortex-A55 cores @ 1.8GHz NPU – Heterogeneous dual-core architecture NPU delivering 2.5TOPS per watt GPU – Imagination Technologies PowerVR GM9446 GPU also found in MediaTek Helio P90. The processor supports multiple AI framework formats, including TensorFlow, TensorFlow Lite, Caffe, and multiple AI data formats such as quantization (INT4, INT8, INT16) and floating-point (FP16). Tiger T710 also works with Android […]

Posted on by Stephen Vicinanza - No Comments on UniSoC Successfully Tested their IVY510 5G Modem in Collaboration with Huawei

UniSoC Successfully Tested their IVY510 5G Modem in Collaboration with Huawei

UniSoC Communications has announced the completion of testing on its IVY510 5G modem. The testing was performed in partnership with Huawei and finished up in July 2019. The IVY brand platform offers compatibility with IoT products and services and is already being used as a cutting-edge option in some devices. The testing had been performed under the auspices of IMT 2020, the regulatory body in the worldwide telecom industry. In the tests, the IVY510 reached download speeds of 1.38 Gbps at CAICT’s MTNet Lab. The IVY510 was announced in February of this year at MWC. It is a multimode 2G/3G/4G/5G modem, that meets the 3GPP R15 standard, supports Sub-6GHz 5G spectrum and has a channel bandwidth of 100 MHz. Offering high performance, deeply integrated, low power 5G platform, supporting both SA (standalone) and NSA (non-standalone) network arrangements. The ability to move through different network formations allows the IVY510 to grow […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on UNISOC Unveils Tiger T310 Quad Core Cortex-A75/A55 DynamIQ Processor for 4G Phones

UNISOC Unveils Tiger T310 Quad Core Cortex-A75/A55 DynamIQ Processor for 4G Phones

UNISOC Tiger T310

UNISOC, a company born out of the merger between RDA Micro and Spreadtrum Communications, has recently introduced Tiger T310 processor for 4G smartphones. The quad core processor is somewhat unique as it comes with a single Cortex-A75 core coupled with three Cortex-A55 cores using dynamIQ technology. UNISOC Tiger T310 key features include: CPU – 1x Arm Cortex-A75 core @ up to 2.0 GHz, 3x Arm Cortex-A53 cores @ up to 1.8 GHz in dynamIQ configuration GPU – TBD Cellular Connectivity – TDD-LTE, FDD-LTE, TD-SCDMA, WCDMA, CDMA, GSM Camera – Dual and triple camera support Security – TEE, face unlocking Manufacturing Process – TSMC 12-nanometer process UNISOC Tiger T310 is said to deliver a 120% single-core performance improvement over the current mainstream 4-core processor, and a 20%  multi-core performance improvement. The processor’s battery life is said to be 20% better than mainstream 8-core processors, and 15% higher than mainstream 4-core processors […]
