Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Mekotronics A58 – A 7-inch display with Rockchip RK3588 SoC and a DSLR camera mount for live streaming

Mekotronics A58 – A 7-inch display with Rockchip RK3588 SoC and a DSLR camera mount for live streaming

7-inch RK3588 display attached to a DSLR camera

Mekotronics A58 7-inch smart display is powered by a Rockchip RK3588 SoC with up to 16GB RAM and 128GB eMMC flash, and ships with a DSLR camera mount to enable video broadcasting and live streaming on social platforms. In the past, we’ve covered several Rockchip RK3588-powered Arm mini PCs by Mekotronics such as the R58, R58X, and more recently the R58X-Pro and R58X-HDD models, but the company has now leveraged its experience with the platform by launching a 7-inch smart display that can be used for live-streaming, but as we’ll see from the specifications below can also find many other uses. Mekotronics A58 specifications: SoC – Rockchip RK3588 octa-core processor with four Cortex-A76 cores @ 2.4 GHz, four Cortex-A55 cores @ 1.8 GHz, an Arm Mali-G610 MP4 GPU, a 6TOPS NPU, 8K 10-bit decoder, 8K encoder System Memory – 4GB, 8GB, or 16GB LPDDR4X Storage 32GB, 64GB, or 128GB eMMC […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Winmate IQ30 Snapdragon 660 SBC Runs Android 9.0 for HMI Touch Panels

Winmate IQ30 Snapdragon 660 SBC Runs Android 9.0 for HMI Touch Panels

Winmate IQ30 Snapdragon 660 SBC

Winmate, a company specializing in rugged computing technology headquartered in Taiwan, has recently launched Winmate IQ30 SBC powered by a Qualcomm Snapdragon 660 octa-core coupled with up to 4GB LPDDR4, and 32GB flash storage. The single board computer also comes with a Fast Ethernet port with optional PoE, WiFI 5, and optional cellular connectivity thanks to an an M.2 card socket and SIM card slot, as two video interfaces for Android-powered touch screen displays. Winmate IQ30 specifications: SoC – Qualcomm Snapdragon 660 octa-core processor with 4x Kryo 260 cores @ 2.2GHz, 4x Kryo 260 cores @ 1.8GHz, Adreno 512 GPU, and Hexagon DSP System Memory – 3GB or 4GB LPDDR4 RAM Storage – 32GB MLC flash, MicroSD card slot Display I/F 1x eDP via MIPI to eDP chip 1x LVDS via MIPI to LVDS chip 2x USB Touch FFC connector 2x backlight headers Audio PM660L audio codec 2x speaker headers, […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Comfile Launches 15-inch Industrial Raspberry Pi Touch Panel PC Powered by RPi CM3 Module

Comfile Launches 15-inch Industrial Raspberry Pi Touch Panel PC Powered by RPi CM3 Module

15-inch Raspberry Pi Touch Panel PC

Three years ago, we noted Comfile has made 7-inch and 10.2-inch touch panel PC’s powered by Raspberry Pi 3 Compute Module. The company has recently introduced a new model with a very similar design except for a larger 15-inch touchscreen display with 1024×768 resolution. ComfilePi CPi-A150WR 15-inch industrial Raspberry Pi touch panel PC still features the CM3 module, and the same ports including Ethernet, USB ports, RS232, RS485, and I2C interfaces accessible via terminal blocks, and a 40-pin I/O header. ComfilePi CPi-A150WR specifications: SoM – Raspberry Pi Compute Module 3 Lite (CM3L) with Broadcom BCM2837 quad-core Arm Cortex-A53 processor @ 1.2 GHz with VideoCore IV GPU, and 1GB RAM Display – 15″ LCD with 1024 × 768 resolution, 16.7 million colors, pressure-sensitive touch screen (resistive type) Audio – Stereo Audio Output Connectivity – 10/100M Ethernet, optional WiFi via USB dongle USB – 3x USB 2.0 ports Serial – 1x RS232C […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on ComfilePi Industrial Touch Panel PCs are Based on Raspberry Pi CM3 Module

ComfilePi Industrial Touch Panel PCs are Based on Raspberry Pi CM3 Module

ComfilePi CPi-A070WR & CPi-A102WR are industrial IP65 panel PCs powered by Raspberry Pi CM3 compute module, with respectively 7″ and 10.2″ resistive touchscreen displays, and that run modified version of Raspbian OS. ComfilePi CPi touch panel computers specifications: SoC – Broadcom BMC2837 quad core Cortex A53 processor @ up to 1.2GHz with Broadcom VideoCore IV GPU System Memory – 1 GB Storage – 1x micro SD Slot Display 7“ 800×480 Touchscreen Pressure-sensitive (Resistive Film Type) LCD display OR 10.2” 800×480 Touchscreen Pressure-sensitive (Resistive Film Type) LCD display Audio – 3.5mm audio out port I/Os 40-pin header socket based on Raspberry Pi 40-pin header pinout with 22x GPIO with ESD protection circuit 2x RS-232 terminal blocks 1x I2C terminal block USB – 3x USB 2.0 ports Connectivity – 10/100M Ethernet, optional WiFi via USB dongle Misc – 1x Piezzo buzzer Power Supply – 12~24V DC via 3-pin terminal block Dimensions (housing […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on MASS RPI 07 is a 7″ Industrial Touch Panel PC Based on Raspberry Pi 3

MASS RPI 07 is a 7″ Industrial Touch Panel PC Based on Raspberry Pi 3

MASS GmbH has launched RPI 07, a touch panel PC with a 7″ 800×480 display powered by a Raspberry Pi 3 board, and designed for industrial applications thanks to a 12V to 24V variable power input, aluminum housing, DIO with optocouplers, an optional CAN Bus and more. MASS RPI-07 specifications: SoC – Broadcom BCM2837 quad core ARM Cortex A53 processor @ up to 1.2 GHz with VideoCore IV GPU System Memory – 1GB LPDDR2 Storage – 16GB micro SD SDHC Class 10 Display – 7″ WVGA 800×480 touchscreen display with 250cd/m² brightness, 500:1 contrast, 10-point touch Connectivity – 1x 10/100Mbps Ethernet, 802.11 b/g/n WiFi and Bluetooth 4.2 LE USB – 4x USB 2.0 Optional Interfaces – Real-time clock (RTC), DIO with optocouplers, I²C, CAN, RS232 Power supply – 12 to 24V DC (15W max) via 2-pin terminal with on/off switch Dimensions – 200 x 118 x 48mm (powder coated metal […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Faytech FTA20 Allwinner A20 Industrial SBC Works with Touch Panels

Faytech FTA20 Allwinner A20 Industrial SBC Works with Touch Panels

Faytech is a company specializing in touch monitors and touch pc, but recently they started to develop embedded boards, and their latest FTA20 single board computer is powered by Allwinner A20 SoC, and offer various optional wireless options like Bluetooth, WiFi, 3G, and GPS. The board also supports the company’s 9.7”, 10.1”, 15” and 21.5” capacitive displays. FTA20 Specifications (to be confirmed): SoC – Allwinner A20 dua lcore Cortex A7 processor @ 1GHz with Mali-400MP2 GPU @ 500MHz System Memory – 1GB DDR3 Storage – 8GB NAND Flash, 1x SD card slot, 1x SATA port (via headers) Video Output – 1x HDMI, 1x VGA, 18/24Bit LVDS Audio – Audio-Chip Integrated HI-FI 100dB Audio Codec, 2x3W amplifier; 5.1 Channel High Definition Audio Codec; 1x Line-In, 1x Line-Out Connectivity 1x 10/100/1000Mbit RJ45 Ports with connector for POE WiFi Optional Bluetooth 4.0 and GPS 1x SIM-card (to be used with mPCIe modem???) USB […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Microsoft Unveils Windows 8 Consumer Preview at MWC 2012

Microsoft Unveils Windows 8 Consumer Preview at MWC 2012

Earlier this month, Microsoft announced they would be releasing Windows 8 Consumer Preview at the end of February, and they have done so yesterday with an official announcement at Mobile World Congress 2012, in Barcelona, Spain. During the event, they showcased ARM tablets based on Nvidia Tegra 3, Qualcomm Snapdragon S4 and Texas Instruments OMAP 4/5, as well as tablets, ultrabooks, laptops and touch PCs based on Intel meldfield and clove trail.  All those devices are reference platform for developers and not actual products although Microsoft expect manufacturers to use those reference designs to build their products. The Touch PC used a an interesting screen which could be positioned vertically (like a normal screen). horizontally (like a surface PC) and at an angle for use cases such as an architecture reading a plan or an artist drawing a painting. They also showcased a very large touchscreen that could be used by […]
