November 15, 2023November 15, 2023 by Jean-Luc Aufranc (CNXSoft) - 11 Comments

Giveaway Week 2023 winners announced!

CNX Software’s Giveaway Week 2023 is now over and we’re ready to announce the winners. We offered some of the review samples we tested (or not) in the last year, and like the last two years, we were also joined by RAKwireless who offered two IoT development kits. All items given away are shown in the photo below, minus some accessories, and if you count more than seven you’d be right, as some are kits with multiple items like the GL.iNet GL-S200 Thread Border router which comes with three development boards, and more importantly, we also organized Giveaway Week on CNX Software Thailand for the second year running. We had seven winners on CNX Software: VOIPAC iMX8M industrial development kit – Kraingsak, Thailand TBS7901 mini PCIe DVB-S2X/S2 module – Frank, Singapore RAKWireless WisBlock IoT Starter Kit – Andy, Russia GL.iNet GL-S200 Thread Border router kit – Augustin, Argentina WCH CH583M-R0-1v1 […]

November 7, 2023November 9, 2023 by Jean-Luc Aufranc (CNXSoft) - 77 Comments

Giveaway Week 2023 – TBS7901 mini PCIe DVB-S2X/S2 module

The second prize of Giveaway Week 2023 is a TBS7901 mini PCIe DVB-S2X/S2 module designed to be connected to a PC or board with a mini PCIe socket in order to watch, record, or broadcast free-to-air video received from a satellite dish. I received both M.2 and mPCIe DVB-S2X modules last August, but I haven’t had time to test any of those yet. So I’m keeping the M.2 module for my own testing once time permits and will be giving away the mini PCIe module to one of CNX Software readers. The module comes with a coaxial antenna cable, as well as a TBS-7901PW power board and SATA power cable since DVB-S/S2/S2X satellite TV requires 13V and 18V DC as well which will be outputted won’t the power board using the 12V from a PSU. You’ll probably need a Windows machine too since TBS provides Windows drivers for the TBS7901 […]

August 17, 2023August 18, 2023 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

M.2/mini PCIe card adds DVB-S2X/S2 tuner to desktop PCs and (some) SBC’s

TBS has designed two small DVB-S2X/S2/S tuner cards with the TBS7230 M.2 module and TBS7901 mini PCIe module designed to easily add DTB support to a desktop PC or even a single board computer with the right interfaces. Both models are based on a Lattice Semi LFE3-17EA-6FTN256C FPGA and Montage LZ M88RS6060 single-chip DVB-S2X/S2/S receiver with a tuner, a demodulator, and an LNB controller, but as I understand it, the mPCIe module relies on a USB PCIe (see comments section) interface, while the M.2 module features a PCIe interface and you can even install more than one in a PC through a PCIe card for NVMe drives. TBS7901 specifications: Host interface – Mini PCIe edge connector Tuner DVB-S2X/S2/S DVB-S2 QPSK – 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 8PSK – 3/5, 2/3, 3/4, 5/6, 8/9, 9/10 16APSK – 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 32APSK – 3/4, 4/5, 5/6, […]

November 16, 2018November 22, 2018 by Jean-Luc Aufranc (CNXSoft) - 23 Comments

Black Friday 2018 – International Deals

November 11.11 is now behind us, but that means Black Friday and Cyber Monday are soon approaching and as usual I’ve gathered some deals or events geared towards an International audience, mostly through various China based online shopping websites. GearBest Black Friday activity has already started with the run-up stage on November 14-21 with deposit expansion and lucky draw, followed by the main event taking place on November 21-26 with $100-$200 coupons and 24-hour flash sale, and finally Cyber Monday event from November 26-31 with activity details to be determined. There’s also a Black Friday coupon that works sitewide: BlackFriday-GB. The coupon provides 10% discount on order of $10 or more on items located in the Chinese (CN-099) warehouse, and not yet discounted. The coupon is valid until November 26, 0:00 UTC+8 Beijing Time (unless more than 20,000 units are sold with the coupon) GeekBuying’s promise of up to 80% […]

September 22, 2016October 10, 2016 by Ray - 29 Comments

Review of Xtream-Codes IPTV Panel Professional Edition – Part 1: Introduction, Initial Setup, Adding Streams…

Today I’ll start the review of one of the streaming software available on the market, with version 2.2.0 EVO of IPTV Panel Professional Edition developed by Xtream-codes. The Software is mainly used for the so-called IPTV broadcasting, but also with great potential for all kind of other content delivery applications such as audio and business streaming, cloud video transcoding, and all other kind of global streams. What is IPTV? Wikipedia definition: Internet Protocol television (IPTV) is a system through which television services are delivered using the Internet protocol suite over a packet-switched network such as a LAN or the Internet, instead of being delivered through traditional terrestrial, satellite signal, and cable television formats. Unlike downloaded media, IPTV offers the ability to stream the media in smaller batches, directly from the source. As a result, a client media player can begin playing the data (such as a movie) before the entire […]

November 14, 2015December 5, 2015 by Jean-Luc Aufranc (CNXSoft) - 31 Comments

TBS5520 Multi-Standard Tuner Box and Linux Drivers

TBS Technologies is a company that specializes in digital TV tuner cards for PC, and recently they’ve also worked on ARM based boards or devices such as the Matrix 2. The company has sent me one of their TBS5520 USB tuner board and box supporting DVB-T2, DVB-S2, DVB-C and ISDB-T for evaluation, as well as some Linux drivers. Today, I’ll provide some specifications, take some pictures, and show how I compiled and installed the drivers in my Ubuntu 14.04 computer. TBS 5520 Tuner Box specifications TBS5520 is a multi-standard USB tuner with the following features: USB – USB 2.0 device port Antenna connectors – 1x LNB IN, 1x RF IN Standards DVB-S2/S Symbol rate: 1~45Msps; FEC DVB-S2: 8PSK: 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10; DVB-S: QPSK: 1/2, 2/3, 3/4, 5/6, 7/8 DVB-T2/T Receiving channel: VHF band, UHF band; Bandwidth: 1.7,5, 6, 7, 8 MHz; FEC: QPSK, 16QAM, 64QAM, 256QAM […]

August 30, 2015 by Jean-Luc Aufranc (CNXSoft) - 14 Comments

MOI Pro AMD IPTV Streaming Server Supports Up to 16 Tuners

TBS Technologies is a company specializing in digital TV tuners, with their catalog includes various DVB-T2, DVB-C, DVB-S2 and ATSC tuner cards. They also happen to be the designer of Matrix board and Matrix 2 Android set-top box, both of which run Android or Linux and support some of the company’s tuners. But they also have higher end products such as MOI Pro AMD IPTV streamer based on an AMD Embedded G-Series processor, and supporting up to 4 tuner cards with up to 4 tuners each. TBS MOI Pro AMD specifications: SoC – AMD GX-412HC quad core processor @ 1.2GHz with AMD Radeon HD GPU @ 300MHz (7W TDP) System Memory – 4GB DDR3-1333 Storage – 30GB mSATA SSD, 1x SATA @ 6.0Gb/s, Video Output – 1x HDMI, 1x VGA (reserved connection?) Connectivity – 2x Gigabit Ethernet Tuners – Up to 4 PCIe TV tuner cards (DVB-S2 or DVB-T2/T/C) for […]

April 23, 2015May 29, 2017 by Jean-Luc Aufranc (CNXSoft) - 11 Comments

TBS 2980 Matrix 2 AllWinner A80 Android TV Box Will Support USB Tuners

TBS launched their Matrix 2910 media player based on Freescale i.MX6 Quad processor in 2013, and what made the platform especially interesting was support for the company’s USB DVB tuners in their Android and Ubuntu images. The company has now unveiled its successor with TBS 2980 Matrix 2 powered by Allwinner A80 octa core processor that will also support USB DVB-T2, DVB-C & DVB-S2 tuners. TBS Matrix 2 specifications: SoC – AllWinner A80 4x Cortex 15, 4x Cortex A7 big.LITTLE processor with PowerVR GC6230 GPU System Memory – 2GB DDR3 Storage – 8GB eMMC + micro SD card slot Video Output – HDMI + AV port Audio – HDMI, AV, and optical S/PDIF Connectivity – Gigabit Ethernet, dual band Wi-Fi 802.11 a/b/g/n, Bluetooth 4.0 USB – 1x USB 3.0 port, 2x USB 2.0 host ports Misc – IR receiver, reset button Power Supply – 5V/3A Dimensions – 101 x 101 […]
