July 29, 2022January 23, 2023 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

SolidRun introduces SolidWAN software-defined edge network hardware with NXP LX 16-core Cortex-A72 SoCs

SolidRun has launched two SolidWAN Linux-based system-level solutions for software-defined wide area networks and network security applications with the SolidWAN Single LX2162 based on NXP LX2162 16-core Cortex-A72 SoC designed for small offices (SoHo) and SMBs, and the SolidWAN Dual LX2160 equipped with two NXP LX2160A 16-core Cortex-A72 networking processors targetting enterprise and edge data center applications. SolidWAN Single LX2162 Hardware specifications: SoC – NXP Layerscape LX2162A 16-core Arm Cortex A72 processor @ up to 2GHz System Memory – Up to 32GB DDR4 Storage – 8GB eMMC flash, MicroSD card slot Networking 8x dedicated Gigabit Ethernet ports 2x SFP 10GbE cages 2x SFP 25GbE cages USB – 1x USB 3.0 port Expansion card I/Os Mini PCIe socket with SIM holder for 4G LTE cellular connectivity Mini PCIe socket for WiFi AP mPCIe module Management USB to STM32 for remote management RunBMC compliant socket Development and Debug interfaces – Mini USB, […]

June 22, 2022 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

SolidRun RZ/G2LC SOM is powered by Renesas RZ/G2LC processor for AI-enhanced HMI applications

SolidRun RZ/G2LC SOM is a system-on-module based on Renesas RZ/G2LC single or dual-core Cortex-A55/M33 processor and designed for AI-enhanced human-machine-interface (HMI) applications, industrial and building automation, video surveillance, IoT, etc… The module is also equipped with 1GB DDR4 RAM, 8GB eMMC flash, and a wireless module with dual-band WiFi 4 and with Bluetooth 4.2 all packed into a tiny footprint measuring just 47 x 30mm that makes it suitable for space-constrained devices such as video doorbells and compact IP cameras. SolidRun RZ/G2LC SOM specifications: SoC – Renesas RZ/G2LC single or dual-core Arm Cortex-A55 processor @ up to 1.2 GHz with, 1x Cortex-M33 real-time core, Arm Mali-G31 GPU, H.264 video decoder System Memory – 1GB DDR4 with inline ECC (up to 2GB) Storage – 8GB eMMC flash (up to 64GB), QSPI Networking Wired – Analog Devices ADIN1200 10/100 Mbps Ethernet PHY (CNXSoft remark: As shown in the block diagram below, but […]

April 30, 2022April 30, 2022 by Jean-Luc Aufranc (CNXSoft) - 8 Comments

DIY SBC cases and SBC Case Builder tool based on OpenSCAD

Since you can’t always rely on single board computer (SBC) vendors to provide a case to match your needs, some went the DIY route. Willy Tarreau designed some laser-cut enclosures with Inkscape for various SBCs, while hominoids went a step further by developing the “SBC Case Builder” tool to automatically generate various types of 3D printable enclosures using OpenSCAD. Willy designed five similar enclosures for Khadas VIM3/VIM3L, FriendlyELEC NanoPi Fire3, SolidRun Clearfog Base networking SBC, Libre Computer AML-S805X-AC (aka “La Frite”), and AAEON UP Board. All cases are available in Inkscape SVG format, and Willy accepts contributions for other boards. You’ll need a laser engraver or CNC router to cut out those enclosures. Hominoids’ SBC Case Builder project attempt to automatize enclosure generation for SBCs using SBC Model Framework written in OpenSCAD. Work has focused on ODROID boards so far, but it should work for other vendors too. The parameters […]

April 11, 2022April 26, 2022 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

SolidRun launches 16-core LX2162A LX2-Lite SOM and ClearFog LX2-Lite development board

SolidRun has launched the LX2-Lite SOM based on NXP Layerscape LX2-Lite SoC with up to 16 Arm Cortex-A72 cores, together with ClearFog LX2-Lite development platform equipped with two SFP28 cages up to 25Gbps each, two SFP+ cage up to 10Gbps each, and eight Gigabit Ethernet RJ45 ports for networking applications. With a footprint measuring just 58 x 48mm, or about 25% the size of a standard COM Express 7 module, the company claims the LX2-Lite Mini SOM, based on LX2162A, is the smallest 16-core SOM platform in the world, and the module and development board target high-performance SD-WAN, network security, and industrial control solutions. SolidRun LX2-Lite SOM Specifications: SoC (one of the other) NXP Layerscape LX2082A with 8x Cortex A72 cores @ 2.0 GHz NXP Layerscape LX2122A with 12x Cortex A72 cores @ 2.0 GHz NXP Layerscape LX2162A with 16x Cortex A72 cores @ 2.0 GHz System Memory – Up […]

December 8, 2021December 8, 2021 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

SolidRun unveils Sitara AM6442 SoM, HummingBoard-T AM64x carrier boards

When we first wrote about Texas Instruments AM64x 7-core processor for PLCs, motor drives, industrial robots, we noted SolidRun, TQ Embedded, and PHYTEC were working on system-on-modules based on the processor with availability scheduled for Q4 2021 or Q1 2022. SolidRun has now formally announced two TI Sitara AM6442 systems-on-module – Sitara AM6442R SOM and Sitara AM6442A SOM – as well as HummingBoard-T AM64x Base and Pro carrier boards for evaluation and development. SolidRun Sitara AM6442 SOM Both variants of the module share most of the same specifications: SoC – Texas Instruments Sitara AM6442 7-core processor with 2x Cortex A53 application cores @ 1.0 GHz, 4x Cortex R5 real-time cores @ 800 MHz, 1x Cortex M4 isolated core @ 400 MHz System Memory – 1GB DDR4 with inline ECC Storage 8GB eMMC AM6442A only – Optional QSPI flash Networking AM6442R 1x 10/100/1000 Mbps (PRU ICSSG, Supporting: TSN, EtherCAT, PROFINET, EtherNET/IP) […]

October 29, 2021 by Jean-Luc Aufranc (CNXSoft) - No Comments

SolidRun i.MX 8XLite SoM embeds DSRC modem, GPS for V2X automotive applications

The GPU-less NXP i.MX 8XLite Cortex-A35/M4 SoC was just announced earlier this month for V2X and IIoT applications, and now SolidRun unveiled the first module based on the new processor with the “i.MX 8XLite System-on-Module”. Also equipped with a RoadLINK SAF5400 safety modem, SolidRun’s Mini SoM targets vehicle telematics, vehicle-to-vehicle (V2V) and vehicle-to-infrastructure (V2I) communications, road infrastructure connectivity, and industrial equipment. SolidRun i.MX 8XLite specifications: SoC – NXP i.MX 8XLite single or dual-cire Cortex-A35 processor @ 1.2 GHz, with Cortex-M4F real-time core System Memory – 1GB LPDDR4 with inline ECC Storage – 8GB eMMC flash Ethernet – NXP TJA1100 100BASE-T1 Automotive Ethernet transceiver Wireless NXP RoadLink SAF5400 DSRC/802.11p (V2X) single modem dual antenna (u.FL connectors) GNSS module for GPS 2x Hirose DF40 board-to-board connectors with: Storage – SD/MMC card, PCIe SSD Ethernet – 100BASE-T1 Automotive Ethernet USB – 2x USB 2.0 PCIe – 1x PCIe Low-speed interfaces – 2x I2C, […]

September 24, 2021April 26, 2022 by Jean-Luc Aufranc (CNXSoft) - No Comments

SolidSense N8 IoT Compact gateway supports Wirepas Massive

SolidRun “SolidSense N8 IoT Compact” is a Linux Edge gateway based on NXP i.MX 8M Nano Solo processor that offers Gigabit Ethernet, WiFi 5, Bluetooth 5.0, and optional 4G LTE Cat 4 & GPS connectivity, plus Wirepas Massive (previously Wirepas Mesh networking) via a module based on Nordic Semi nRF52832 wireless Cortex-M4 microcontroller. The gateway comes with 1GB RAM, 8GB storage, offers optional RS485 and CAN interfaces, and targets IoT applications such as smart metering, automation, asset tracking, safety & security, and smart buildings. SolidSense N8 IoT Compact gateway SolidSense N8 IoT Compact specifications: SoC – NXP i.MX8M Nano single core Arm Cortex A53 @ 1500MHz + Cortex M7 @ 650MHz System Memory – 1GB DDR3 Storage – 8GB eMMC flash, MIcroSD card slot Connectivity Gigabit Ethernet RJ45 port with optional PoE support 802.11 a/b/g/n/ac WiFi 5 and Bluetooth 5.0 Optional 4G LTE Cat 4 (Global) + GPS with fallback […]

September 2, 2021December 18, 2022 by Jean-Luc Aufranc (CNXSoft) - 16 Comments

Windows 11 can run on Arm SystemReady ES platforms like Raspberry Pi 4, Solidrun SBC’s, etc…

While Windows 11 may have some problems running some x86 machines, I previously saw Windows 11 Arm on Raspberry Pi 4 with instructions telling you to download the images from UUP Dump and flash the ISO with Windows on Raspberry Pi Imager. At the time, I did not look into details, and it seemed was some hack involved, but I’ve just been told Windows 11 could also run without modification on some SolidRun’s single board computers, namely MacchiatoBin and CN913x CEx7 evaluation board. Marcin Wojtas explains Windows 11 Pro (version 22000.168) could be installed unmodified on an Arm computer based on MacchiatoBin mini-ITX board equipped with an NVIDIA Geforce GT630 GPU (using EFI Frame Buffer), a SATA SSD, connected through Ethernet (via USB2ETH), plus a mouse and keyboard. So what’s the trick, and what do Raspberry Pi 4 and a board like MacchiatoBin have in common? Answer: Arm SystemReady ES […]
