Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Socionext 24 GHz Radar Sensor for IoT Measures Distance and Angle (Video)

Socionext 24 GHz Radar Sensor for IoT Measures Distance and Angle (Video)

24 GHz Radar Location Distance Demo

Last year, we wrote about Socionext MN87900 24 GHz radio wave radar module for IoT with Rx & Tx antennas and a crytal unit that measured just 12×7 mm. The module is made for IoT equipments, security systems, smart home appliances, autonomous vehicles and drones, medical devices, and more. Basically any application that requires distance measurement up to 8 meters (expandable to 30 meters with a radome horn), rough location, or motion detection may leverage the technology. The company has now uploaded a video showing a demo of their 24 GHz radar sensor. Socionext did not explain which exact solution they used, and it’s probably not the full module above, but either one of their sensors based on the link provided in the video description: SC1232AR3 – All-in-one RADAR sensor for Entry Motion & Distance Detection SC1233AR3 – All-in-one RADAR sensor for Entry Motion & 2D Detection I suspect SC1232AR3 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 14 Comments on Socionext HV5 Series HDMI 2.1 Video Processing ICs Enable 8K TVs and STBs

Socionext HV5 Series HDMI 2.1 Video Processing ICs Enable 8K TVs and STBs

SocioNext HV5 Series HDMI 2.1 Processor

HDMI 2.1 specification was released late last year with the main benefit being the support of 8K videos at up to 120 Hz, and a small downside with the requirement for new 48G cables.  Samsung Q900R is one of the first 8K TV on the market, but according to the product page HDMI 2.1 is not supported just yet: Will provide complimentary upgrade for HDMI 2.1 support when available. Please contact customer support for more details So it looks like the Quantum Processor 8K processor found in the TV will be firmware upgradable to support HDMI 2.1. Anyway for 8K video equipment to be useful we’ll need video equipment to support HDMI 2.1 Tx & Rx, and SocioNext has launched what it claims are the first HDMI 2.1 compliant video processor ICs with their HV5 series. The processor family comes with HDMI Tx and Rx with two main series: Interface […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 15 Comments on Edge Server SynQuacer E-Series 24-Core Arm PC is Now Available for $1,250 with 4GB RAM, 1TB HDD, Geforce GT 710 Video Card

Edge Server SynQuacer E-Series 24-Core Arm PC is Now Available for $1,250 with 4GB RAM, 1TB HDD, Geforce GT 710 Video Card

Right before Linaro Connect San Francisco 2017, GIGABYTE, Socionext and Linaro unveiled a development platform / PC based on Socionext SC2A11 24-core Arm Cortex A53 processor, and whose motherboard complies with 96Boards Enterprise Edition (EE) specifications. I called the platform GIGABYTE Synquacer at the time, because GIGABYTE helped with the design, and the platform was called Synquacer, even during the demo at Linaro Connect. George Grey, Linaro CEO, talked about Synquacer against during Linaro Connect HK 2018 opening keynote, notably to demo the platform combined with Gyrfalcon Light-speeur PCIe card delivering 93TOPS at relatively low power for artificial intelligence applications. I wanted to find out if there were now updates with regards to software support, availability,  and pricing.  While searching for the product page, I found out it was now called “Edge Server SynQuacer E-Series“, and while GIGABYTE designed the board, they will probably not use their brand for this […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on SocioNext MN87900 is a Really Tiny 24 GHz Radio Wave Radar Module for the Internet of Things

SocioNext MN87900 is a Really Tiny 24 GHz Radio Wave Radar Module for the Internet of Things

In the past, we covered tiny microwave radar modules operating at 5.8 GHz and measuring just 32 x 23 mm. Those modules are normally used to detect motion, distance, and/or direction of movement. Socionext has now introduced MN87900, a single low-power single-chip 24 GHz radio wave IoT sensor solution that even smaller at just 12x7mm with the chip, Tx and Rx antennas, crystal, and 40-pin to solder the module to your board. The solution targets IoT equipments, security systems, smart home appliances, autonomous vehicles and drones, medical devices, and more. SocioNext MN87900 key specifications: Sensor Type – CW, FSKCW, FMCW (moving or stationary) Detection Motion direction – approaching or leaving Motion speed – up to 200 km/h Range – 0.15 to 8 meters 80°@-3dB, expandable to 30 meters  with a radome horn, a metal shield that narrows the field of view. Variable frequency width –  24.15±0.1 GHz Transmission Power – […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on Socionext S8 Media Player Supports 8K HEVC Videos, 22.2 Channels Audio

Socionext S8 Media Player Supports 8K HEVC Videos, 22.2 Channels Audio

4K still feels like a new technology, but 8K is also coming as HDMI 2.1, superMHL, and DisplayPort 1.4 all support 8K QUHD (Quad Ultra HD) resolutions up to 60 or 120 fps. So at some points will need some SoC, media players, and TVs support the new higher resolution. Socionext is working on this with their S8 media player powered by the company’s proprietary 8K HEVC SC1400A decoder chip, and that will be offered to “operators and service providers of video streaming for various applications including public viewing and digital signage”, starting in March 2018. Socionext S8 8K media player specifications: Video Codec – 8K H.265/HEVC 4:2:0 10bit, 4K H.264/MPEG-4 4:2:0 10bit Audio Codec – 2ch / 5.1ch / 22.2ch AAC-LC 16bit 48kHz Container TS/MP4/MMT (Optional) Resolution – 8K (7680 x 4320)/60p, 4K (3840 x 2160)/60p Video Output – 4x ch HDMI2.0; Up-conversion of 4K to 8K supported Audio […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 23 Comments on GIGABYTE SynQuacer 96Boards Enterprise Platform is Powered by SocioNext SC2A11 24-core ARMv8 SoC

GIGABYTE SynQuacer 96Boards Enterprise Platform is Powered by SocioNext SC2A11 24-core ARMv8 SoC

GIGABYTE, Socionext and Linaro have partnered to design a software development platform compliant with 96Boards Enterprise specifications, with GIGABYTE taking care of manufacturing the hardware based on Socionext SC2A11 processor, while Linaro will provide support via 96Boards community. GIGABYTE SynQuacer platform preliminary specifications (based on photos and SC2A11 specifications): SoC – Socionext SynQuacer SC2A11 24x ARM Cortex-A53 MPCore cores @ up to 1GHz, with 32KB/32KB I/D L1 cache, 256 KB L2 cache, and 4MB L3 cache (5W power consumption) System Memory – 4x DIMM slots for 64-bit DDR4-2133Mbps with ECC up to 64GB Storage – 32GB Samsung KLMBG2JENB-B041 eMMC 5.1 flash + 2x SATA interfaces Connectivity – 2x Gigabit Ethernet (RJ45) with IPSec Network Offload Engine USB – 2x USB 3.0 ports on motherboard (via Renesas D720201), 4x USB ports on front panel via expansion board Audio – 1x microphone input, 1x speaker output on front panel Expansion – 1x PCie […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 7 Comments on Socionext SC2A11 Low Power Server Processor Comes with 24 Cortex-A53 Cores, Scales up to 1536 Cores via PCIe

Socionext SC2A11 Low Power Server Processor Comes with 24 Cortex-A53 Cores, Scales up to 1536 Cores via PCIe

Socionext SC2A11 is an 24-core (tetracosa) ARM Cortex-A53 processor designed for low-power server system suitable for edge computing, web server & indexing, cloud computing, and any applications that do not require high single thread peak performance. The company also designed SC2A20 switch SoC that allows up to 64 SC2A11 processors (1536 cores) to communicate over PCI Express using Socionext DDT (Direct Data Transaction). SC2A11 SoC specifications: Processor – 24x ARM Cortex-A53 MPCore cores @ up to 1GHz, with 32KB/32KB I/D L1 cache, 256 KB L2 cache, and 4MB L3 cache Memory I/F – DDR4-2133Mbps 64-bit + ECC Flash I/F – HSSPI, eMMC PCIe – PCI Express Gen2, Root/Endpoint select, 4 lanes (2 systems/ for SoC IF) LAN – 2x 1Gbps with IPSec Network Offload Engine (wire-speed) Serial I/F – UART, I2C, GPIO The company did not provide any info about software, but it’s safe to assume it’s running Linux. There’s […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on Linaro 15.05 Release with Linux 4.1 and Android 5.1

Linaro 15.05 Release with Linux 4.1 and Android 5.1

Linaro 15.04 has been released with Linux 4.1-rc4, Linux 3.10.79 and 3.14.42 (LSK), and Android 5.1_r3. The Ubuntu image is now based on Vivid instead of Utopic. Android and Debian builds/images have been released for Hikey’s 96boards, Ubuntu Vivid and Android builds have been setup for Qualcomm’s Dragonboard 410c. A new platform, Socionext M8M, has also show in Linaro changelog. I could not find details about M8M, but Socionext is a “new company that designs, develops and delivers System-on-Chip products” and focuses on “imaging, networking and other dynamic technologies”. Their latest press release mentions a 4K media processor with build-in HDMI 2.0 Tx and Rx, so maybe M8M is based on that processor, but I can’t know for sure as they have several chips. Highlights of this release: Linux Linaro 4.1-rc4-2015.05 GATOR updated to version 5.21.1 updated integration-linaro-vexpress64 topic by ARM LT: PCI support added – for Juno r1. Linaro […]
