June 1, 2019February 16, 2020 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

Shuttle EN01J is a Tiny Apollo Lake Mini PC Topped with a Large Heatsink

Many people don’t want heatsink, but in some case fanless designs do not allow for maximum sustained performance. This should not be a problem for Shuttle EN01J mini PC with a choice of 10W Apollo Lake processors, and a rugged design completed with a large heatsink topping the enclosure used to make sure the processor runs optimally for the target applications, which include digital signage, industrial automation, and visual recognition applications as reported by FanlessTech. Shuttle EN01J specifications: SoC (One or the other) – Intel Celeron J3355 dual core, Celeron J3455 quad core, or Pentium J4200 quad core processor with Intel HD graphic; 10W TDP System Memory – Up to 8GB LPDDR4 2,400 MHz Storage – Up to 64GB eMMC flash, microSD card slot Video Output – HDMI 1.4 up to 3840z2160 @ 30 Hz Connectivity – Gigabit Ethernet (Intel) with optional POE-PD or POE-PSE, nano SIM slot for M.2 […]

February 7, 2018June 15, 2018 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

Shuttle DL10J Fanless Gemini Lake Mini PC Features Intel Celeron J4005 Dual Core Processor, 3 Video Outputs

Several mini PCs based on Intel Gemini Lake processors were unveiled at CES 2018, including Zotac PICO PI226, MeLE PCG63-APL4, and ECS LIVA Gemini Lake models all of which slated to launch in Q2 2018. ASRock and GIGABYTE also announced Gemini Lake motherboards a few weeks later. Most of the products above are for the consumer market, but if you’re after a Gemini Lake mini PC more geared towards business use cases like digital signage and multi-display solutions, Shuttle is now showcasing their DL10J mini PC powered by an Intel Celeron J4055 Gemini Lake dual core processor, and offering 3 video output ports at Integrated Systems Europe 2018 (ISE 2018). Shuttle DL10J mini PC specifications: SoC – Intel Celeron J4005 dual core GLK processor @ 2.00/2.70 GHz with 12EU Intel UHD Graphics 600; 10W TDP System Memory – 2x DDR4 slots @ 2133 MHz up to 8GB Storage – 1x […]

April 28, 2017April 28, 2017 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

Shuttle NS02E Rockchip RK3368 Android mini PC Supports PoE for Digital Signage and Thin Clients

The market is flooded of octa-core Android mini PCs or TV boxes for the consumer market, but Rockchip RK3368 powered Shuttle NS02E Android mini PC targets a different mark, specifically digital signage and thin clients as it’s been designed for 24/7 nonstop operation, and supports features such as PoE (Power over Ethernet). Shuttle XPC nano NS02E specifications: SoC – Rockchip RK3368 ARM Cortex A53 processor @ up to 1.5 GHz with Imagination PowerVR G6110 “Rogue” GPU System Memory – 2GB RAM Storage – 16GB eMMC flash, 2.5″ SATA bay for 7″ drives (requires one extra optional accessory), SD card reader Video Output – HDMI 2.0 Audio Output – Via HDMI, 3.5mm Line OUT audio jack Connectivity – Gigabit Ethernet (RTL8211-CG transceiver) with PoE support, 802.11 b/g/n WiFi and Bluetooth 4.0 (RTL8723BS module) USB – 3x USB 2.0 host ports Misc – Kensington lock hole, power button, power LED, HDD LED, […]

August 22, 2014August 22, 2014 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Shuttle DSA2LS Fanless Android Mini PC with Dual Display Support for Digital Signage Applications

Shuttle is a company making small form factor PCs, and I’ve recently mentioned their Intel Celeron J1900 based mini PCs. The company has now launched its first ARM based mini PC, called DSA2LS, powered by Freescale i.MX6 Duallite processor, and running Android 4.2. This computer is mainly destined to be used as a digital signage player with features such as VESA mounts, dual screen support, protective operation, and has been designed for 24/7 operation at 0 to 45 C. Other applications include kiosk, thin clients, and vending machines. SoC – Freescale i.MX6 DualLite dual core processor @ 1GHz with Vivante GPU System Memory – 1GB DDR3 Storage – 4GB eMMC + SD card slot up to 64 GB protected by anti-theft (or anti-troll) cover Video Output – HDMI and VGA, supporting dual displays (but maybe not independent displays). Audio – HDMI, Line OUT Connectivity – 10/100/1000M Ethernet (470Mbps max) with […]

June 27, 2014June 28, 2014 by Jean-Luc Aufranc (CNXSoft) - 12 Comments

Shuttle Fanless mini PCs Powered by Intel Celeron J1900 Quad Core Bay Trail SoC Sell for $200 and Up

A little while ago, Bay Trail-D (Desktop) motherboards started to show up for about $60 to $70, and I estimated a complete system with RAM, enclosure, and 1TB storage would cost around $250. Thanks to Shuttle XS35V4 and XS36V4, you can now buy such quad core system pre-assembled for well under $300, or just around $200 for a barebone system without RAM or storage. Shuttle XS35V4 / XS36V4 specifications: SoC – Intel Celeron J1900 Quad core processor (Bay Trail-D) @ with Intel 7th generation graphics. System Memory – 1x DDR3L SO-DIMM, up to 8GB DDR3 1333 MHz Storage – 1x 2.5″ SATA HDD / SSD bay, 1x SD card reader. XS35V4 only: optical drive. Connectivity – 10/100/1000M Ethernet (Realtek RTL8411), 802.11b/g/n WLAN support (1T1R), Audio – Realtek ALC269, 2.1 channel High Definition Audio Front panel Power button Power & HDD LEDs SD Card reader 1x USB 2.0 port XS36V4 only […]
