July 17, 2017July 17, 2017 by Nanik Tolaram - No Comments

Getting Started with MediaTek X20 Android Development Board

Thanks to CNX for helping me get a hand on the 96Boards compliant Mediatek X20 board that was generously donated by Seeed Studio. In this article, I will walk through the steps to get the board up and running and also compile Android from the source code. The current Android is version 6. Unboxing the Beast First Boot Up The board boots up from the eMMC, and the first time you boot up you will get Android screen as shown in Figure-9. This is the default Android image from the factory, which surprisingly looks like it was setup for a phone screen mode, which is not sufficient for a HDMI monitor. It would be better to install the images that are made available at Linaro website or build your own. See the other section to flash the board with different images. Switching to Fastboot Mode Flashing image files are done […]

June 11, 2017 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

Review of Wio Tracker with GPS, Bluetooth 3.0 and GSM Connectivity

Wio GPS – also called Wio Tracker – is an Arduino compatible board based on Microchip Atmel SAMD21 MCU with GPS, Bluetooth, GSM/GPRS connectivity, as well as several Grove connectors to connect sensors and modules for your IoT project. SeeedStudio sent me a sample for evaluation, so I’ve tested it, and reported my experience below by testing some of the Arduino sketches. Wio Tracker Unboxing All I got in the package was Wio GPS tracker v1.1 board. The top includes the Atmel MCU, an RGB LED, a microphone and 3.5mm AUX jack to make phone calls, a user and power button, a micro USB port for power and programming, a small 2-pin connector for a battery, and 6 Grove connectors for digital, serial, I2C and analog modules. The other side of the board comes with Quectel MC20 module that handles Bluetooth, GPS and GSM, a dual use micro SD card […]

April 26, 2017 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

$14 LinkIt 7697 Bluetooth 4.2 LE and WiFi IoT Board is Powered by Mediatek MT7697 ARM Cortex-M4 MCU

Mediatek Labs has launched a new IoT development, which on the surface looks similar to LinkIt Smart 7688 board, but the internal design is quite different as the MIPS processor and Linux OS, have been replaced by Mediatek MT7697 ARM Cortex-M4 processor running FreeRTOS, and beside WiFi, also includes support for Bluetooth 4.2 LE. LinkIt 7697 board specifications: Wireless SoC – Mediatek MT7697 ARM Cortex M4F MCU @ 192 MHz with 352KB RAM, 4MB flash, 802.11 b/g/n WiFi, Bluetooth 4.2 LE and a PMU Expansion – 2x 14-pin header with 18x GPIO, 2x UART, 1x I2C, 1x SPI, 18x PWM, 4x EINT, 4x ADC (0 to 2.5V), 1x IrDA, 1x I2S Debugging – 1x SWD, CP2102 UART to USB chipset Misc – Reset and user buttons; power and user LEDs Power Supply – 5V via micro USB port Dimensions – 48 x 26 mm The board can be programmed with […]

April 21, 2017June 7, 2017 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Wio GPS is a $40 Grove & Arduino Compatible Bluetooth 3.0 + GSM/GPRS + GPS Tracker Board

After Wio Link and Wio Node boards, Seeed Studio has added a new board to their Wio (Wireless Input Output) family with Wio GPS board based on Microchip SAMD21 Cortex M0+ MCU for Arduino compatibility, and Mediatek MT2503 ARM7 processor for GPS, Bluetooth 3.0, and 2G (GPRS) connectivity. Wio GPS board specifications: MCU – Microchip ATSAMD21G18A-MU ARM Cortex M0+ MCU @ 48 MHz with 256KB flash, 32KB SRAM Wireless SoC – Mediatek MT2503 ARM7EJ-S processor @ 260 MHz Storage – micro SD slot (shared with nano SIM slot) Connectivity (built-in MT2503 in Quectel MC20 module) Bluetooth 2.1 + EDR, 3.0 with SPP Profile and HFP-AG Profile; u.FL connector for external antenna Quad band 2G GSM/GPRS with u.FL connector for external antenna and nano SIM card slot GNSS – GPS + BeiDou + QZSS with u.FL connector for external antenna Audio – Speaker footprint (+/-), 3.5mm AUX jack with mic and stereo audio […]

April 12, 2017April 12, 2017 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

ESP8266, Mongoose OS & Grove Sensors – An Alternative Solution for Hackathons

CNXSoft: This is a guest post by Cesanta If you walked into any Hardware hackathon over the last year, you would see they are about innovation and bringing new ideas to this world and most of them are centered around the connected devices nowadays. However, just walk the floor, talk to the teams and you can quickly see an elephant in the room. The Hackathons are about connected devices, but with the ‘recommended’ and frequently sponsored hardware distributed to the teams such as Intel Galileo, Raspberry Pi, etc…. developers may struggle for a long time to even connect it to the cloud! Not to mention the innovation is usually hindered by a tedious environment setup which takes hours, things to learn about the specific hardware and how it can be programmed using low level languages. So many teams spent most of the time fighting with those issues and oftentimes still […]

September 27, 2016 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

BLE Carbon 96Boards IoT Edition Board Runs Zephyr OS

Linaro Connect Las Vegas 2016 is taking place right now, and the organization has some very interesting development, with a new focus on the Internet of Things thanks to the creation of LITE (Linaro IoT and Embedded) segment group that will work on “delivering end to end open source reference software for more secure connected products, ranging from sensors and connected controllers to smart devices and gateways, for the industrial and consumer markets”. The first LITE IoT Reference Platform release to be made in December 2016, but in the meantime, Linaro introduced 96Board IoT specifications, as well as the first compliant board with the launch of Carbon board (aka BLE Carbon) running Zephyr OS. Carbon 96Boards IoT Edition board specifications: MCU – STMicro STM32F401 ARM Cortex M4 microcontroller @ up to 84 MHz with 512kB Flash, 96kB ram Connectivity – Bluetooth 4.0 LE via Nordic Semi nRF51822 SoC + chip […]

September 21, 2016 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

HICAT.Livera Machine Vision Board and Robot Kit Feature HiSilicon Hi3518 SoC (Crowdfunding)

HiSilicon Hi3518 ARM9 processor is mostly being used in IP cameras, but Hicat startup decided to combined the camera processor with an Atmel MCU and a MT7601 WiFi module to create a wireless camera board to be used with OpenCV, and even provide a complete affordable robot kit with the board. Hicat.livera board specifications: Vision Core – Hisilicon Hi3518 ARM9 processor @ 440 MHz Storage – 16MB flash + micro SD card MCU – Atmel ATmega32U4 AVR micro-controller Connectivity – 802.11 b/g/n WiFi via Mediatek MT7601 module + u.FL antenna connector Camera interface with provided 140 deg. camera using Omnivision OV9712 720p (1280×720) sensor USB – 1x micro USB port for power and programming Audio – Built-in microphone, speaker header Sensors – MPU6050 accelerometer and gyro Expansion – 2x GPIO headers with GPIOs, I2C, SPI, serial, PWM, digital, analog and power signals. Misc – MCU reset and Linux reset buttons, […]

September 5, 2016September 6, 2016 by Jean-Luc Aufranc (CNXSoft) - 28 Comments

You Can Now Buy ESP3212 ESP32 WiFi + Bluetooth Module for $6.95

After the official launch of ESP32 processor for less than $3, it did not take long before ESP32 modules hit the market, and Seeed Studio has already listed ESP3212, one of the first modules based on Espressif ESP32 Bluetooth LE + WiFi SoC, for $6.95 with shipping scheduled to start on September 23, 2016. ESP3212 module specifications: SoC – Espressif ESP32 dual core Xtensa LX6 processor @ up to 240 MHz with 448 KB flash, 520 KB SRAM, 16 KB SRAM in RTC, WiFi and Bluetooth LE connectivity Storage – 4MB Winbond SPI flash Connectivity 802.11 b/g/n/e/i WiFi (HT40) up to 150 Mbps Bluetooth 4.2 BR/EDR and BLE 3 dBi PCB antenna Headers – 22x GPIOs (multiplexed with ADC, Touch, DAC, SPI, UART, CAN, ETH, IR, PWM, and I2S), 1x UART, Sense VP/Sense VN, EN pin. 3.3V and GND Power Supply – 3.0 – 3.6V Dimensions – 24 x 16 […]
