June 4, 2016 by TLS - 5 Comments

Innodisk shows off M2DOM’s at Computex 2016

DOM’s or Disks on Module are quite popular with embedded system makers, but they’ve traditionally used slow interfaces like PATA or USB 2.0, with some more recent models using SATA or USB 3.0. At Computex, Innodisk was showing off an entirely new entry which should hopefully become the new standards for motherboard DOM’s. By using a horizontally mounted M.2 connector (B keyed) with a screw hole on each side, Innodisk has created a compact connector for DOM’s that build on industry standards. The great news here is that the same connector can be used for USB 3.0, SATA and even PCI Express based DOM’s. Innodisk does of course offer a full range of compatible products, starting with the M2DOM U30 featuring a USB 3.0 interface. This is the “slowest” product in the range with speeds of up to 100MB/s and available in capacities from 8-64GB. Next up is the M2DOM […]

June 1, 2016June 1, 2016 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

Cavium introduces 54 cores 64-bit ARMv8 ThunderX2 SoC for Servers with 100GbE, SATA 3, PCIe Gen3 Interfaces

Cavium announced their first 64-bit ARM Server SoCs with the 48-core ThunderX at Computex 2014. Two years later, the company has now introduced the second generation, aptly named ThunderX2, with 54 64-bit ARM cores @ up to 3.0 GHz and promising two to three times more performance than the previous generation. Key features of the new server processor include: 2nd generation of full custom Cavium ARM core; Multi-Issue, Fully OOO; 2.4 to 2.8 GHz in normal mode, Up to 3 GHz in Turbo mode. Up to 54 cores per socket delivering > 2-3X socket level performance compared to ThunderX Cache – 64K I-Cache and 40K D-Cache, highly associative; 32MB shared Last Level Cache (LLC). Single and dual socket configuration support using 2nd generation of Cavium Coherent Interconnect with > 2.5X coherent bandwidth compared to ThunderX System Memory 6x DDR4 memory controllers per socket supporting up to 3 TB RAM in […]

May 30, 2016May 12, 2017 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

Sunhed S3 Android TV Box is Powered by Hisilicon Hi3798C V200 Processor

HiSilicon Hi3798C V200 processor is designed for high-end TV boxes and media centers with a a quad core Cortex A53 processor, 4K 10-bit H.265 and VP9 video decoding at 60 fps, built-in SATA, Gigabit Ethernet, USB 3.0, and so on. One of the first model to hit the shelves was Himedia Q10 Pro, but I’ve received an engineering sample for Sunhed S3 based on the processor, so let’s have a closer look starting with the specifications and pictures of the device. Sunhed S3 specifications: SoC – HiSilicon Hi3798CV200 quad-core ARM Cortex A53 processor with ARM Mali-T720 GPU System Memory – 2GB DDR3 Storage – 8GB eMMC + SD card slot + external SATA interface Video Output – HDMI 2.0 up to 3840×2160 @ 60 Hz and CVBS output (RCA) Video Codecs – H.265/HEVC 4Kx2K@60fps, MVC, MPEG1/2/4, VC-1, WMV Video Containers – TS, MKV, FLV, MOV, AVI, RM, MP4, ISO Blue-ray […]

May 23, 2016 by Jean-Luc Aufranc (CNXSoft) - 21 Comments

Popcorn Hour A500 4K Linux Media Player Specifications, Unboxing, and Teardown

CloudMedia introduced Popcorn Hour A500 Pro last summer on Kickstarter, and as the company is about the ship rewards to backers, they has now recently introduced a lower cost version, called Popcorn Hour A500, based on the same processor but overall lower specs to bring the price down to $269. The company has sent me a review sample, so I’ll start by listing the hardware specifications, and post pictures of the device and its internals, before testing media playback capabilities later on. Popcorn Hour A500 Specifications The “non-PRO” version has less RAM, dropped the XLR connectors, and uses a cheaper audio DAC: SoC – Sigma Designs SMP8758 dual core ARM Cortex A9 processor @ 1.2 GHz with ARM Mali-400 GPU and VXP image processing engine System Memory – 1GB DDR3 Storage – 512 MB SLC NAND Flash for firmware, 1x SD card reader, internal SATA bay for 2.5″ and 3.5″ […]

May 8, 2016 by Jean-Luc Aufranc (CNXSoft) - 11 Comments

Qualcomm DragonBoard 600c 96Boards Development Board Includes Ethernet and SATA

A few weeks ago, I was informed that some code about DB600c board powered by Qualcomm Snapdragon 600 processor (APQ8064T) was making it into mainline Linux, and more recently I found a website listing DragonBoard 600c with a low resolution picture of the board. While we don’t have the complete specifications yet, the form factor of the board is quite interesting, as we’ll find the typical 96Boards CE form factor on the right, and some extra interfaces on the left with Ethernet and SATA. It turns out, as we’ll see below, it’s perfectly compliant (hardware wise) with 96Boards CE “Extended Version” specifications. Preliminary specifications of DragonBoard 600c board: SoC- Qualcomm Snapdragon 600 (APQ8064 Fusion 3) quad-core Krait processor @ 1.7 GHz with Adreno 320 GPU @ 400MHz System Memory – 1GB or more RAM (TBD) Storage – eMMC Flash + micro SD slot + SATA port Video Output – HDMI […]

May 4, 2016May 29, 2017 by Jean-Luc Aufranc (CNXSoft) - 11 Comments

Olimex A20-OLinuXino-LIME2-eMMC Board Replaces NAND by eMMC Flash for Better Performance & Reliability

A20-OLinuXino-LIME boards are the most popular development board sold by Olimex, likely thanks to reasonable pricing, and Allwinner A20 is one of the rare low cost processor to features an actual SATA interface and Gigabit Ethernet support. The company has now launched a new version A20-OLinuXino-LIME2-eMMC, based on A20-OLinuXino-LIME2-4GB, but replacing the NAND flash by an eMMC flash that should offer both better performance and reliability. A20-OLinuXino-LIME2-eMMC specifications: SoC – Allwinner A20 dual-core ARM Cortex-A7 CPU @ 1.0 GHz with dual-core Mali 400 GPU System Memory – 1GB DDR3 Storage – 4GB eMMC flash (Micron), SATA data and power connectors, micro SD slot, 2KB EEPROM for MAC address and custom data Connectivity – Gigabit Ethernet Video Output – HDMI up to 1080p60 USB – 2x USB 2.0 host ports with power control and current limiter, 1x micro USB-OTG with power control and current limiter Expansion – 160 GPIOs on four […]

April 22, 2016 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Boardcon’s Rockchip RK3288 Single Board Computer Runs Android 4.4/5.1, Supports 3G, GPS, 5 Display Interfaces and More

Rockchip RK3288 is back in the news this month, and after the announced of MiQi low cost board a few days ago, an high-end Rockchip RK3288 SBC has come to market with Boardcon EM3288 comprise of MINI3288 CPU module, and a features-packed baseboard with multiple ports and connectivity options, including SATA and a 3G modem. EM3288 board specifications: SoC – Rockchip RK3288 quad core ARM Cortex A17 processor up to 1.8 GHz with Mali-T764 GPU System Memory – 2G DDR3 Storage – 8 GB eMMC flash, SATA, and micro SD slot Video I/O HDMI 2.0 up to 3840×2160@60p (provided your TV/monitor support YUV444) VGA 1x 26-pin MIPI connector, 1x 40-pin LVDS (multiplexed with VGA), 1x 40-pin TTL LCD connector Audio Output / Input – HDMI, Line IN and OUT 3.5mm jacks, and built-in MIC Connectivity Gigabit Ethernet Optional 8021.11b/g/n and Bluetooth4.0 via Ampak AP6212 module Optional 3G via ZTE MF210 […]

April 14, 2016April 14, 2016 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

NEXBOX T11 Cherry Trail Mini PC Includes a 2.5″ SATA Bay, Supports HDMI and VGA Output

It’s always possible to connect a USB hard drive to a mini PC, but it’s not quite as neat as having an internal drive, and it may not pass the wife test. NEXBOX T11 mini PC powered by Intel Atom x5-Z8300 processor addresses this issue by including a 2.5″ SATA bay on the bottom for the case of a SSD or HDD with up to 2 TB capacity. NEXBOX T11 specifications: SoC – Intel Atom x5-Z8300 “Cherry Trail” quad core processor @ 1.44 GHz/1.84 GHz (turbo) with Intel Gen8 HD graphics System Memory – 2 GB DDR3 Storage – 32 GB flash, 2.5″ SATA drive support, and micro SD slot Video Output – HDMI and VGA Audio Output – HDMI and 3.5mm audio jack Connectivity – 10/100M Ethernet port, 802.11 b/g/n/ac Wi-Fi, and Bluetooth 4.0 USB – 3x USB 2.0 host ports, 1x USB 3.0 port, 1x micro USB OTG […]
