Rockchip RK3066/RK30xx Processors Documentation, Source Code and Tools

Rockchip RK3066 (part of RK30xx family) is a Chinese dual ARM Cortex A9 SoC targeting multimedia products such as tablets (e.g. Cube U30GT), mini PC (e.g UG802, MK808) and in theory set-top boxes, but I can’t find any products based on this Rockchip processor. It seems mini PCs/ HDMI TV sticks have taken over this market. RK3066 Processor The processor features two ARM Cortex A9 clocked at up to 1.6 Ghz with a quad core Mali-400MP GPU. It can support 1080p (3D) encoding/decoding, provides HDMI 1.4a, VGA, composite, component and LVDS video outputs (Dual display support),  USB 2.0 Host and OTG ports, a MAC interface (Ethernet), and much more… Here are the key features of Rockchip RK3066 processor: Dual Core A9 + Quad Core Mali-400MP GPU 2 banks, 8/16 bit Nor flash / SRAM interface 8 banks, 8/16 bit async NAND flash, LBA NAND flash and 8-bit sync ONFI NAND […]

How to Root UG802 Rockchip RK3066 mini PC

If you follow this blog (and others), you should already know there’s a new dual core Cortex A9 Android mini PC in town based on Rockchip RK3066. Deadhp1, a reader of this blog, bought one and left a short review about the device, including his first impressions and an Antutu benchmark (6801). He also noticed that the device is not rooted by default, and followed the instructions for Window N90 II tablet (source: Slatedroid) to root the device: Download Moborobo Download a modified version of SuperOneClick – Short Fuse (Originally found in Slatedroid link above). Install Moborobo and start the program Make sure USB Debugging is enabled on your mini PC(Settings –> Developer Options) Connect your UG802 mini PC (using the microUSB port) to your PC Wait for Moborobo to detect the device Extract the contents of SuperOneClick Run SuperOneClick.exe Click on Root It will says the device is already […]

$60 Rockchip RK2906 (Cortex A8) Android 4.0 Tablets

About 2 months ago, I received a 7″ capacitive tablet powered by WonderMedia WM8850 Cortex A9 processor and running Android 4.0. The WM8850-MID tablet cost me $76 at the time, and was available for as low as $72, which I found extremely cheap for a tablet with those specs. Since then AllWinner A13 processors have started to be used in tablets with similar specs – but without HDMI output – that sell for as low as $55. At the Hong Kong electronics Fair in April 2012, Rockchip announced several processors including the RK2906, which I was led to believe would be a cut-down version of ARM Cortex A8 RK2918 without HDMI, but it appears not to be the case. And today, I received a “Deal Alert” for an RK2906 Android 4.0 tablet that sells for $59.99 including shipping on Focalprice and could be an alternative to A13 tablets, especially if […]

$89 Rockchip RK3066 Dual Core Cortex A9 mini-PC Coming to Market

Liliputing has just reported that a $89 dual core Cortex A9 mini PC may be available soon from a South African company/individual. The SoC would be clocked at 1.6Ghz, come with 1GB RAM, 4GB flash, and destroy all other low cost mini PC in terms of performance. Here are the announced specifications: Operation System – Android 4.0.4 ICS SoC – Dual ARM Cortex-A9 processor up to 1.6GHZ with Mali-400MP4 Quad-core GPU RAM – 1GB DDR3 Storage –  4GB Nand Flash , microSD card slot (up to 32 GB) Connectivity – Built-in WiFi 802.11b/g/n USB – 1 x USB 2.0 Host,  1 X micro usb host Video out – HDMI Video Codecs – Mpeg1/2/4.H.264,VC-1,Divx,Xvid,RM8/9/10,VP6 Video Containers – MKV,TS,TP,M2TS,RM/RMVB,BD-ISO,AVI,MPG,VOB,DAT,ASF,TRP,FLV etc full formats Audio Codec – DTS,AC3,LPCM,FLAC,HE-AAC Audio Formats – MP3,OGG,WMA,WMAPRO Power – 90-230V, 50/60Hz input, max. power: 30W, Output: 5V/2A Dimensions – 10.1 x 3.8 x 1.3cm Weight – 38g The device […]

Cube U30GT Android 4.0 10.1″ Tablet Powered by Rockchip RK3066

Alldocube Technology and Science will manufacture one of the first Android 4.0 tablet based on the new Rockchip RK3066 Dual Cortex A9 Processor: the Cube U30GT which will sell under 51cube.com brand. Here are the specs of the device: CPU – RK3066, Cortex-A9 Dual Core processor 1.6 GHz GPU – Quad Core Mali 400 with OpenGL ES 2.0/1.1, OpenVG1.1 RAM – 1GB DDR3 Storage – 16 GB NAND FAST / microSD Card slot (Support up to 32G) Display – 10.1″ capacitive touch screen (1280×800) Camera: 2.0 MPixel front camera 2.0 MPixel rear camera Sensors – 4-way G-sensor Connectivity – Wi-Fi b/g, Bluetooth and 3G (via external 3G dongle). Battery – Up to 4 hours movie playback,up to 12 hours music playback and up to 6 hours web page browsing. Weight – 450 grams Charbax discovered this tablet last month in Hong Kong. You can watch the video below to have a closer […]

Rockchip Unveils RK3066 Dual Core Cortex A9 Processor

Rockchip announced the RK3066 processor featuring a dual core Cortex A9 with a quad-core Mali-400 GPU and the company is currently showcasing tablets, e-Readers and set-top boxes powered by RK3066 at Hong Kong Electronics Fair on 13-16 April, 2012. Information is sparse, but I managed to find more information on Engadget China website which shows the key features of RK3066: Dual Core A9 + Quad Core GPU 2 banks, 8/16 bit Nor flash / SRAM interface 8 banks, 8/16 bit async NAND flash, LBA NAND flash and 8-bit sync ONFI NAND flash, all up to 60-bit hardware ECC 2 GB space for 2 ranks, 16-bit / 32-bit DDR3-800, LPDDR2-800 and LVDDR3-800 3 channels SD/MMC interface to support MMC 4.1 and SD3.0 2 channels TFT LCD interface with 5 layers and 3D display with resolution up to 1920×1080 HDMI 1.4 to support 1080p@30 3D video 2 channels 8-bit CCiR656 interface and […]

Rockchip Introduces RK30xx Dual Core Cortex A9 Processors for Low Cost Tablets

Rockchip announced their next generation mobile processor at Mobile World Congress, in Barcelona, Spain. The Rockchip RK30xx series (RK3018?) features a dual core Cortex A9 clocked up to 1.4 GHz coupled with an ARM Mali-400 GPU and targets low cost Android 4.0 tablets. The Rockchip RK30xx platform features: Dual-core ARM Cortex-A9 processor with up to 1.4GHz speed, implemented with Artisan Processor Optimization Pack (POP) Quad-core ARM Mali-400 MP GPU, supporting OpenGL ES 1.1/2.0 and OpenVG 1.1 Full memory support, including DDRIII, DDRII, and LPDDRII High performance dedicated 2D processor 1080P multi-format video decoder 1080P video encoding for H.264 and vp8  Stereoscopic 3D H.264 MVC video codec  Embedded HDMI 1.4a, supporting 3D display Embedded 60bit/s ECC, supporting MLC NAND, E-MMC, i-NAND and booting Support of dual panel display and dual camera Rockchip also said the complete BSP is already available for the chip. This company does not usually release BSP publicly […]

X10 AirPad: 200 USD Android 2.3 Tablet powered by Rockchip RK2918

X10 has started to sell its own android tablet for 199.99 USD. The X10 AirPad is powered by Rockchip RK2918, a 1.2GHz, Cortex-A8-based processor, 512 MB RAM and 4GB of flash storage, and runs Android 2.3 (gingerbread). It features a seven-inch, 800 x 480 pixel capacitive display, a 2 MP camera and an HMDI output supporting 1080p. Its specifications are similar to Arnova 7 G2 also powered by RK 2918 @ 1 Ghz, the second version of Arnova 7 that runs Android 2.3 and features a 7″ capacitive display and is said to be sold in Hong Kong for around 215 USD. Here are the X10 AirPad 7″ Android Tablet Specifications: CPU: 1.2 Ghz Rockchip 2918 Cortex A8 processor + 600 Mhz DSP Display: 7″ 800×480 resolution TFT LCD screen Touch-screen: Capacitive multi-touch, 5 point touch OS: Android 2.3, with Flash 10.1 Camera: 2 Megapixel camera with video recording and […]
