Rockchip RK3066 Android 4.2.2 HDMI TV Stick SDK Leaked

About 10 days ago, Android 4.2.2 SDK for MK908 (RK3188) HDMI TV Stick was leaked, and now, I’m reporting another leak, this time for the Android 4.2.2 SDK for the Android TV Boxes based on the older Rockchip RK3066 dual core processor. The files were first found on an FTP server, but one of Freaktab members uploaded a compressed image of all files, RK3066_R-BOX.7z (3.2GB) to MEGA.co.nz. The content of the SDK directory comes with a bit of documentation, AVC and VP8 encoding and decoding demos, and the SDK itself as a 3.2GB tar. I’ve haven’t download the file yet. If you switch to the parent directory, you’ll find more documentation such as several datasheets and RK3066 technical reference manual, hardware files (Schematics, PCB layout, BoM), and some manufacturing files. If you go up to the parent directory, you’ll also find an A20 directory with AllWinner A20 Android SDK (homlet […]

Rockchip SoCs Comparison Table, RK32xx Quad Core Cortex A12 Coming Up in 2014

They guys at Linux Rockchip have setup a comparison table between Rockchip processors, but it’s not quite complete yet, and Rockchip noticed it, so they’ve just sent them the most recent Company Presentation that provides more details, including a roadmap. In this documentation, we can see the company targets different types of products with their SoCs: Android OTT dongle/box (aka mini PC, HDMI TV dongles…) – RK2928, RK3066, RK3068, and RK3188 Tablets – RK2926, RK2928, RK3028, RK3066, RK3168, and RK3188 EPD E-Book – RK2818, RK2906 and RK2918 MP3 player – RKnanoC On page 12 of the presentation, they have a convenient comparison table for the SoC used in mini PCs and Tablets. Series RK2926 /RK2928 RK3066 /RK3068 RK3168 RK3188 Process 55nm 40nm 28nm HKGM 28nm HKGM CPU Cortex A9 Dual Cortex A9 Dual Cortex A9 Quad Cortex A9 MAX CPU Frequency 1.0 GHz 1.6 GHz 1.2 GHz 1.6 GHz L1 […]

$10 Rockchip RK2928 Miracast/DLNA Adapter Video Demo

Rockchip showcased an ultra low cost Linux-based Miracast adapter at the Hong Kong Electronics Fair in April, and we learned the device was powered by Rockchip RK2928 with just 16 MB RAM, a small NOR flash, and would just cost around $10. Rockchip demonstrated the device to Charbax at Computex 2013 in early June, and he uploaded the video yesterday. The demo includes showing off Miracast and DLNA support, with the device connected to an HDTV @ 720p. The adapter as a latency as low as 80ms. Rockchip representative explains that as long as it’s below 100ms it’s not noticeable for typical use (but it might be different for games). They used AMOI N828 smartphone for the demo, but Miracast is supposed to work with any Android 4.2 devices supporting Wi-Fi direct, although I’ve read several users’ reports indicating that may not be the case in practice. The price is […]

Waxberry Pi2 Development Board Based on Rockchip RK3066

The other days I announced CubieTech and Olimex were working on low cost Rockchip development boards, but it turns out there’s already one on the market called Waxberrry Pi2, or WB-RK3066, made by Waxberry, a Chinese company. Here are the specifications of this development board: SoC – Rockchip RK3066 dual core Cortex-A9 processor @ 1.6GHz with Mali-400 MP4 GPU System Memory – 1GB DDR3 RAM Storage – 8GB NAND Flash + micro SD card slot USB – Standard USB OTG + Micro USB OTG; Connectivity: 10/100M Ethernet; WIFI 802.11b/g/n (MediaTek MT5931) Bluetoothv2.1+EDR (MediaTek MT6622) Video Output –  HDMI + AV Debugging – Serial port Misc – IR Sensor Dimensions – 72mm x72mm The board comes with a Mini HDMI cable, a 5V/2A power supply, a USB Data cable, and a USB-serial board for debug. There’s also a CD with the board schematics, Android 4.1.1 SDK and Linux Kernel 3.x source […]

Linux-Rockchip Developers Community Up, Rockchip Development Boards Coming Soon?

Companies like Freescale and Texas Instruments provide good software support, and documentation, which is why they can be found in many embedded devices, because without documentation or source code low-level customization is nearly impossible or extremely time consuming. They also usually open most of the documentation and code, because they understand this can foster the use of their chips. On the other hand, Chinese-based SoC manufacturers focus on high-volume platforms such as tablets and smartphones, and usually management don’t understand the advantage to make documentation and GPL source code available, or even may consider it bad for business. Some individuals and small companies do not see it that way however, and they either want to access to the source code to improve existing mobiles devices, or use low cost Chinese SoCs to provide highly customizable hardware and software solutions. So source code and documentation have started to leak, and tools […]

Rockchip RK3066 is Now Part of Mainline Linux Kernel

After AllWinner A10/A13 SoCs, it’s time for another Chinese SoC to be included into mainline kernel, with Rockchip RK3066(a). A few hours ago, Heiko Stuebner’s commit for basic support in Linux kernel 3.11 has been accepted. This is the commit message: This adds a generic devicetree board file and a dtsi for boards based on the RK3066a SoCs from Rockchip. Apart from the generic parts (gic, clocks, pinctrl) the only components currently supported are the timers, uarts and mmc ports (all DesignWare- based). Don’t get too excited though, as it may take a little while until you can actually build a kernel for Rockchip RK3066 or AllWinner A10 from mainline linux source code. But this is definitely another step in the right direction, and hopefully, Chinese SoC companies will eventually get involved, instead of relying on the community, as it is in their best interest. To access the full list […]

List of RK3188 mini PCs / HDMI TV Dongles

The first HDMI TV stick based on Rockchip RK3188 that I noticed was CloudnetGo CR9, and since then many more similar products have hit the market. I did not write about most of them as “it’s just more of the same” most of the time, but listed some in CloudnetGo CR9 post’s comment section. Today, I’ll provide a (non-exhaustive) list of devices, in no particular order, with a summary of the hardware specifications. I won’t mention Android versions since all of them already run Jelly Bean (Android 4.1 or 4.2). Retail price information, which I got from Aliexpress, Geekbuying, W2COMP, and some other sites, is provided for reference, and includes shipping unless otherwise stated. CloudnetGo CR9 – 2GB RAM, 8/16 GB Flash, HDMI male, 1x USB, 1x microUSB – Price Unknown  – See review Tronsmart T428 – 2GB RAM, 8GB Flash, HDMI male,  1x USB, 1x microUSB – $99 Rikomagic MK802 […]

How to Flash Firmware to Rockchip RK3188 HDMI TV Sticks

Yesterday, I’ve received MK908 mini PC featuring Rockchip RK3188, and a new firmware is available, so before further testing I’ll flash the firmware to the device basically using the instructions from Geekbuying. This method use standard Rockchip tools, so it should work for any RK3188 devices. But first a little rant. Those instructions only work on Windows operating systems, so if you’re using Linux or Mac, you’re out of luck until you find a Windows PC, or launch Windows in a virtual machine. This method should just be used in case the device can’t boot, or you have serious issue with the device firmware, but it is also used for firmware upgrade for Rockchip mini PCs. This is just wrong. Typical users should not be asked to install software and drivers, press the recovery button, just to upgrade their firmware. The best very way would be OTA updates, but maybe this […]
