February 22, 2019February 22, 2019 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

4Kopen UHD Video Development Platform Features STMicro STiH418 Media Processor

Back in 2016, I read news about STMicro exiting the set-top box chipset market, so I just assumed all their STiHxx processors would be phased out, and I was surprised to come across 4Kopen, described as an open 4K UHD video development platform powered by STMicro STiH418 media processor, especially it was just showcased at 2019 Integrated Systems Europe (ISE 2019) at the beginning of the month. The development board comes with 2 GB RAM, HDMI 2.0 output, HDMI 1.4 input, Gigabit Ethernet, USB 3.0, a mini PCIe slot fitted with an 802.11b/g/n WiFi module, an eSATA connector and more. 4Kopen (B2264) hardware specifications: SoC – STMicro STiH418 quad-core Arm Cortex-A9 processor @ 1.2 GHz, quad-core Mali-400 GPU, and 4x ST231 DSP (Each Core Quad issue) @ 650 MHz System Memory – 2 GB DDR3 @ 2133 MHz Storage – micro SD socket, eSATA port Video & Audio I/O Output […]

December 26, 2018December 27, 2018 by Jean-Luc Aufranc (CNXSoft) - 26 Comments

Banana Pi to Launch a 24-Core Arm Server

SinoVoIP has been offering Banana Pi single board computers for several years. Their boards are generally based on Arm processors, offered at a relatively decent price, although not as quite as good value as FriendlyELEC and Orange Pi ones. The company is also known for providing subpar documentation and firmware images, but a fairly active community still formed around their boards 🙂 The company has now demonstrated something a little different with a 24-core Arm server that should eventually be sold as a Banana Pi server board or actual server, as the full details are yet to be known. We did not get a glimpse at the actual hardware, but the blurry photo above gives some clues. We have 24-core Arm Cortex A53 processor with 32GB RAM (29.4GB seen by the OS) running Ubuntu 18.04.1 LTS with MATE desktop. There aren’t that many 24-core Arm Cortex A53 processors, so unless […]

August 28, 2018February 16, 2020 by Jean-Luc Aufranc (CNXSoft) - No Comments

MCC 118 DAQ HAT Enables Up to 64-Channel Voltage Measurement on Raspberry Pi Boards

Measurement Computing Corp. (MCC) has recently introduced their MCC 118 DAQ HAT for Raspberry Pi which includes 8 analog inputs for voltage measurements between +/- 10V at a 100kS/s data rate. You can also perform data acquisition on up to 64 channels by stacking up to 8 MCC-118 DAQ HATs on top of a single Raspberry Pi board. The maximum throughput is limited to 320 kS/s. MCC 118 DAQ HAT key features & specifications: 8x 12-bit voltage inputs 100 kS/s max sample rate (320 kS/s aggregate for stacked boards) ±10 V input range Onboard sample buffers allow for high-speed acquisition External scan clock I/O External digital trigger input Screw terminal connections Up to eight MCC HATs are stackable on top of a Raspberry Pi board The data acquisition / data logger systems based on the add-on board would run Raspbian (Lite) on the Raspberry Pi board, as well as a […]

May 10, 2018May 10, 2018 by Jean-Luc Aufranc (CNXSoft) - No Comments

CrowPi is a Portable Learning Kit for Raspberry Pi 3 B+ / Zero Boards (Crowdfunding)

We have an embarrassment of choices for Raspberry Pi accessories from touchscreen displays, HAT add-ons boards, sensors, breadboard, and so on, as well as good software and support from Raspberry Pi forums. This is all good, but it can be messy with all those jumper cables, and not really portable. Elecrow has a neat solution with the CrowPi learning kit for Raspberry Pi 3 and Raspberry Pi Zero that come with a 7″ display, several sensors, buttons, a breadboard, and more all packed in a small suitcase. Main parts of the kit: 7″ touchscreen display Breadboard with GPIOs status LEDs Input modules – Light sensor, IR receiver, PIR motion sensor, sound sensor, temperature & humidity sensor, touch sensor, ultrasonic sensor, NFC reader, and tilt sensor Output modules – 8×8 LED matrix, 4-digit LED display, I2C LCD1602 display, buzzer, vibration motor, relay module, 9G servo, and stepper motor. Control modules – […]

May 4, 2018 by Jean-Luc Aufranc (CNXSoft) - No Comments

Acme Systems CM3-PANEL Panel PC based on Raspberry Pi Compute Module 3 Sells for 99 Euros and Up

After their first Raspberry Pi Compute Module 3 based board called CM3-Home designed for home automation, Acme Systems has designed a new RPi CM3 carrier board called CM3-PANEL for panel PCs / tablets. They sell four variants of their panel PC built around the board with or without WiFi module and/or 868MHz RF module, and offer customization services for people willing to purchase at least 100 pieces. CM3-PANEL based Panel PC specifications: Socket for Raspberry Pi Compute Module 3 Display – 7″ (800×480 resolution) with 10-point capacitive touch Camera – MIPI connector for Raspberry Pi Camera Up to 24 GPIO lines available for extensions or LCD backlight control Camera led and camera shutdown control SPI bus (5 GPIOs) Hardware PWM lines (2 GPIOs) Serial line PCM line (4 GPIOs) I2C bus Model specific features: CM3-PANEL-W – 802.11 b/g/n WiFi @ 2.4GHz (RaLink RT5370N USB module) CM3-PANEL-U – 1x USB host […]

April 12, 2018April 12, 2018 by Jean-Luc Aufranc (CNXSoft) - 21 Comments

Banana Pi BPI-W2 Multimedia Router / NAS Board Launched for $93

SinoVoIP has really been busy for products launches this month, as Banana Pi BPI-W2 is the fourth board they’ve started selling on Aliexpress. The board is designed for media, storage, and networking application, thanks to its Realtek RTD1296 quad core processor combined with 2GB RAM, dual Gigabit Ethernet, dual SATA interfaces, M.2 slots, USB 3.0/2.0 ports, HDMI 2.0a output and input, and more. Banana Pi BPI-W2 specifications have not changed since the early announcement last fall: SoC – Realtek RTD1296 quad core Cortex A53 processor with ARM Mali-T820 MP3 GPU System Memory – 2GB DDR4 RAM Storage – 8GB eMMC flash (optional 16, 32 or 64GB), 2x SATA 3.0 interfaces, micro SD slot up to 256GB Video Output – HDMI 2.0a up to 4K @ 60 Hz, mini DP Input – HDMI 2.0 input up to 1080p60 Playback – HDR, 10-bit HEVC/H.265 up to 4K @ 60fps, H.264 up to […]

March 14, 2018March 15, 2018 by Jean-Luc Aufranc (CNXSoft) - 81 Comments

$35 Raspberry Pi 3 Model B+ Launched with a Faster Processor, 802.11ac WiFi, Gigabit Ethernet, and Optional PoE

The Raspberry Pi Foundation has just introduced a updated version of their popular Raspberry Pi 3 Model B board with a Model B+ that increases the processor clocked up to 1.4 GHz, adds dual-band 802.11ac WiFi, and Bluetooth 4.2, Gigabit Ethernet (via USB 2.0 to Ethernet bridge), as well as support for PoE (Power-over-Ethernet) via an external HAT add-on board. Raspberry Pi 3B+ specifications: SoC – Broadcom BCM2837B0 64-bit ARMv8 quad core Cortex A53 processor @ 1.4GHz with dual core VideoCore IV GPU System Memory – 1GB LPDDR2 Storage – micro SD slot Video & Audio Output – HDMI 1.4 and 4-pole stereo audio and composite video port Connectivity – Gigabit Ethernet (via Microchip LAN7515 USB 2.0 to GbE bridge), maximum throughput 300 Mbps), WiFi 802.11 b/g/n/ac and Bluetooth 4.2 LE (via Cypress CYW43455 based module) USB – 4x USB 2.0 host ports, 1x micro USB port for power […]

February 13, 2018 by Jean-Luc Aufranc (CNXSoft) - No Comments

BASpi I/O is a Raspberry Pi HAT Expansion Board for Building Automation (BACNet)

BACNet is a data communication protocol for Building Automation and Control Networks that has been developed, supported and maintained by ASHRAE (American Society of Heating, Refrigerating and Air-Conditioning Engineers) Standing Standard Project Committee since 1987, and used as building automation standard in the US, Europe, and more than 30 other countries. It’s used for HVACs, lightings, elevators, fire safety, and other systems used in buildings. It’s also known as ISO 16484-6 standard. I had never heard of it, but this afternoon, I’ve come across Contemporary Controls BASPi I/O, a Raspberry Pi add-on specifically designed for BACNet, and providing 12 physical I/O points including 6 Universal Inputs and 6 Relay Outputs. BASPi I/O specifications and features: BACnet/IP Server – 12 physical points and 24 virtual points BACnet/IP over Ethernet or Wi-Fi Resident Sedona Virtual Machine (SVM) Input/Output — 12-points of physical I/O 6x configurable Universal Inputs: Analog Input, Binary Input, Resistance, […]
