Posted on by Debashis Das - No Comments on NXP Trimension SR250 short-range UWB radar supports secure ranging for Smart Homes and Industrial IoT

NXP Trimension SR250 short-range UWB radar supports secure ranging for Smart Homes and Industrial IoT

NXP Trimension SR250 UWB radar

NXP Semiconductors has recently introduced Trimension SR250 UWB radar, which NXP is calling the industry’s first single-chip solution that combines on-chip processing with short-range ultra-wideband (UWB) radar and secure UWB ranging. Operating at 6-8.5 GHz, the SR250 supports features like 3D angle-of-arrival (AoA), time difference of arrival (TDOA), and time of flight (ToF) measurements accurate to within ±5 cm. The integrated on-chip radar processing reduces power consumption, which increases efficiency and it can work with AI/ML algorithms on host processors like NXP’s i.MX, RW61x, and MCX families. The SR250 is supported by firmware, middleware, and sample applications, simplifying development and deployment. Applications for this device include smart home automation (e.g., turning devices on/off based on presence), secure access, and safety monitoring, as well as industrial uses such as worker tracking, collision avoidance, and danger zone detection. Trimension SR250 UWB radar specification 3D secure ranging Fully interoperable with IEEE 802.15.4z HRP […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Sparkfun’s Pulsed Coherent Radar Sensor features Acconeer XM125 60 GHz module, works through walls, offers up to 20-meter range

Sparkfun’s Pulsed Coherent Radar Sensor features Acconeer XM125 60 GHz module, works through walls, offers up to 20-meter range

SparkFun Pulsed Coherent Radar Sensor Acconeer XM125 Qwiic

SparkFun has launched a new Qwiic breakout board for the Acconeer XM125 60 GHz pulsed coherent radar sensor that can measure distance to humans even through walls and works at a distance of up to 20 meters. We’ve seen tiny 24GHz or 60GHz radar modules for several years now, and Supachai even reviewed the Seeed Studio mmWave sensor using ESPHome and Home Assistant late last year with the solution relying on Frequency-Modulated Continuous Wave (FMCW) technology. The Acconneer XM125 is a Pulse-radar module that emits electromagnetic waves in short bursts instead of continuously like FMCW radars and allows longer measurement ranges potentially at the cost of lower accuracy. Sparkfun Pulse Coherent Radar Sensor specifications: Acconeer XM125 Module A121  60GHz Pulsed Coherent Radar (PCR) Integrated baseband, RF front-end, and antenna in package Detects distance, speed, motion, and objects up to 20 meters away Millimeter precise readings Low power consumption STMicro STM32L431CBY6 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on STMicro ST60A3H0 and ST60A3H1 60 GHz transceiver ICs aim to replace USB cables

STMicro ST60A3H0 and ST60A3H1 60 GHz transceiver ICs aim to replace USB cables

ST60A3H0 ST60A3H1 60 GHz transceivers

STMicro ST60A3H0 and ST60A3H1 are short-range 60 GHz transceiver ICs that tunnel eUSB2, I2C, SPI, UART, and GPIO signals and aim to replace USB and other cables in consumer devices such as digital cameras, wearables, portable hard drives, and small gaming terminals. They should also find their way into industrial applications such as rotating machinery where cable use may be challenging. The smaller ST60A3H0 chip provides more flexibility and requires an external antenna, while the ST60A3H1 chip is a fully integrated solution with a built-in linear antenna. Both are capable of USB 2.0 speeds of up to 480 Mbps and support UART, GPIO, and/or I2C signals so they are not limited to USB cables and can be used in a range of applications. ST60A3H0 and ST60A3H1 key features and specifications: 60 GHz V-Band transceiver for short-range contactless connectivity up to 480 Mbit/s eUSB2, UART, GPIO, or I2C RF tunneling Low […]

Posted on by Supachai Vorapojpisut - 9 Comments on Seeed Studio mmWave sensor kit – Part 1: unboxing and first impression with ESPHome and Home Assistant

Seeed Studio mmWave sensor kit – Part 1: unboxing and first impression with ESPHome and Home Assistant

mmWave Human Detection Sensor Kit Review Home Assistant

Excited to share my first review, written for CNX Software! This time, we’re diving into the Seeed Studio mmWave Human Detection Sensor Kit, which harnesses the power of mmWave radar. The technology I’m particularly interested in for its smart home potential. Therefore, I jumped at the chance when CNX Software offered a product review opportunity. The kit arrived promptly at my doorstep just one week after accepting CNX Software’s offer. Here are my initial findings of the product and its capabilities to replace existing motion detection products.  Unboxing the mmWave sensor kit I opened the DHL box and found the neatly bubble-wrapped mmWave Human Detection Sensor Kit. Alongside the kit, I discovered a bonus: the MR60FDA1 60GHz mmWave Sensor – Fall Detection Module Pro. This higher-frequency module boasts better resolution and even adds a fall detection feature compared to the kit’s included module, the MR24HPC1. However, the MR24HPC1 24GHz mmWave Sensor […]

Posted on by Tomisin Olujinmi - No Comments on RoomSense IQ – An ESP32-S3 modular room monitor with mmWave radar presence detection (Crowdfunding)

RoomSense IQ – An ESP32-S3 modular room monitor with mmWave radar presence detection (Crowdfunding)

roomsense iq mount rotation v2

RoomSense IQ is a modular room monitor for presence-based home automation based on the ESP32-S3 module with Bluetooth Wi-Fi connectivity. It uses physical presence detection to automate your smart home devices. It comes with multiple sensors that can be used to detect human activity and track ambient light, temperature, and humidity levels. It uses mmWave radar technology to determine when rooms are empty and when they are occupied. It also features built-in temperature, humidity, and light sensors for indoor climate monitoring and control. Rather than relying on schedules, or voice detection, RoomSense IQ triggers automations or alerts based on whether people are in a room or not. It is therefore possible to set it to automatically turn off lights or air conditioning in rooms that are empty to save on energy. In addition, the device offers distance to target measurement that can be adjusted to trigger certain actions. RoomSense IQ […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on SONOFF SNZB-06P Zigbee human presence sensor is based on a 5.8GHz microwave radar

SONOFF SNZB-06P Zigbee human presence sensor is based on a 5.8GHz microwave radar

SONOFF SNZB-06B human presence detection sensor

ITEAD has launched a new Zigbee sensor with the SONOFF SNZB-06P designed to detect human presence using a 5.8GHz microwave radar whose main advantage over a traditional PIR motion sensor is the ability to detect stationary persons since this type of sensor can detect breathing. You’ll need a Zigbee Hub from SONOFF such as the NSPanel Pro or SONOFF iHost, or from other manufacturers, for instance, the Amazon Echo Plus 2nd generation, or simply use a Zigbee USB dongle such as the SONOFF ZBDongle-E connected to a host like a Raspberry Pi. Configuration and control is done through the usual eWelink app for Android or iOS. SONOFF SNZB-06P specifications: MCU – Silicon Labs EFR32MG22 wireless microcontroller Human presence sensor 5.8GHz microwave radar Sensitivity configurable from 2.5 meters to 4 meters Wireless – Zigbee 3.0 (router type) up to 30 meters Misc – Red LED, magnetic base, button Power Supply – […]

Posted on by Saumitra Jagdale - 5 Comments on Tiny mmWave radar sensor embeds Cortex-R4F core for object tracking, classification

Tiny mmWave radar sensor embeds Cortex-R4F core for object tracking, classification

tiny mmwave radar sensor

The 1″ cube mmWave RS-6843AOPUA radar sensor, announced by D3 Engineering, is a miniature radar device that enables easy integration of radar algorithms for industrial applications. The RS-6843AOPUA radar sensor is an AECQ-100-qualified 60 GHz device that integrates a Texas Instruments C674x DSP for algorithms and an Arm Cortex-R4F microcontroller unit for decision-making and interfacing. It also has a radar accelerator and an “on-package antenna array.” The RS-6843AOPUA radar sensor features a 1-inch cube form factor, heat-spreading metal body, mounting tabs, and a USB-Serial interface. The USB-Serial interface could be used to test and evaluate the radar sensor. Functions and Applications of the Radar Sensor TI C674x DSP: FMCW (Frequency Modulated Continuous Wave) signal processing, Implementation of algorithms Radar Accelerator: Radar data processing Arm Cortex-R4F MCU: Object tracking, Classification, Communications “The RF front end integrates a PLL, three transmitters, four receivers, and baseband ADC, and allows the sensor to cover […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Socionext 24 GHz Radar Sensor for IoT Measures Distance and Angle (Video)

Socionext 24 GHz Radar Sensor for IoT Measures Distance and Angle (Video)

24 GHz Radar Location Distance Demo

Last year, we wrote about Socionext MN87900 24 GHz radio wave radar module for IoT with Rx & Tx antennas and a crytal unit that measured just 12×7 mm. The module is made for IoT equipments, security systems, smart home appliances, autonomous vehicles and drones, medical devices, and more. Basically any application that requires distance measurement up to 8 meters (expandable to 30 meters with a radome horn), rough location, or motion detection may leverage the technology. The company has now uploaded a video showing a demo of their 24 GHz radar sensor. Socionext did not explain which exact solution they used, and it’s probably not the full module above, but either one of their sensors based on the link provided in the video description: SC1232AR3 – All-in-one RADAR sensor for Entry Motion & Distance Detection SC1233AR3 – All-in-one RADAR sensor for Entry Motion & 2D Detection I suspect SC1232AR3 […]
