May 13, 2022May 13, 2022 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

Allwinner T507 industrial processor powers automotive single board computer and module

Forlinx OKT507-C single board computer for automotive applications is powered by FETT507-C system-in-module equipped with Allwinner T507 industrial processor, 2GB RAM, and 8GB eMMC flash. Allwinner T507 offers the same features as Allwinner H616 for TV boxes with a quad-core Cortex-A53 CPU, a Mali G31 MP2 GPU, and the same I/Os, but the processor is AEC-Q100 certified, supports -40°C to +85°C temperature range, and Allwinner promises over 10 years of longevity. OKT507-C single board computer specifications: FETT507-C System on Module SoC – Allwinner T507 quad-core Cortex-A53 @ 1.5GHz with Arm Mali-G31 MP2 GPU with support for OpenGL ES 3.2/2.0/1.0, Vulkan1.1, OpenCL 2.0; (“2.25W power consumption under load”) System Memory – 2GB DDR3L Storage – 8GB eMMC flash Board-to-board connectors for carrier board connection Supply Voltage- 5 V Dimensions – 70 x 40 mm Temperature Range – -40°C to +85°C Carrier board Storage – MicroSD card slot Display I/F 1x LCD […]

April 17, 2022 by Jean-Luc Aufranc (CNXSoft) - No Comments

EC-R3568PC is a compact rugged mini PC based on Rockchip RK3568 SoC

Firefly EC-R3568PC is a compact rugged mini PC powered by Rockchip RK3568 SoC with a built-in 1 TOPS AI accelerator, up to 8GB RAM, 128GB flash, M.2 NVMe and SATA 3.0 storage, dual Gigabit Ethernet, HDMI 2.0 output, RS232 and RS485 interfaces through an RJ45 socket, and more. The fanless embedded computer is designed to be wall-mounted, and operates in a wide -20°C – 60°C temperature range making it suitable for smart NVR, cloud terminal, IoT gateway, and industrial control applications. EC-R3568PC specifications: SoC – Rockchip RK3568 quad-core Cortex-A55 processor @ up to 2.0GHz with Arm Mali-G52 2EE GPU with support for OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1. 1 TOPS NPU, VPU with 4Kp60 H.265/H.264/VP9 video decoding, 1080p60 H.265/H.264 video encoding System Memory – 2GB, 4GB, or 8GB LPDDR4 Storage 16GB, 32GB, 64GB, or 128GB eMMC flash 16MB SPI Flash M.2 PCIe 3.0 socket for 2242 / 2280 NVMe […]

March 17, 2022 by Jean-Luc Aufranc (CNXSoft) - No Comments

OK3568-C SBC provides dual GbE, WiFi 5, 4G/5G connectivity, multiple display interfaces

Taking a break from the recent RK3588 news, let’s check out a board based on Rockchip RK3568 quad-core Arm Cortex-A55 processor with the Forlinx OK3568-C single board computer equipped with up to 8GB RAM and 64 GB storage. The board is comprised of the company’s FET3568-C system-on-module and OK3568-C carrier board offering multiple display interfaces, plenty of connectivity options with dual Gigabit Ethernet, WiFI 5, Bluetooth 5.0, as well as optional 4G or 5G cellular connectivity, and PCIe slots. OK3568-C specifications: FET3568-C SoM SoC – Rockchip RK3568 quad-core Cortex-A55 processor @ up to 2.0 GHz with Mali-G52-2EE GPU supporting OpenGL ES 1.1, 2.0, 3.2, Vulkan 1.0,1.1, OpenCL 2.0, 1 TOPS NPU, 4K H.264, H.265, VP9 VPU System Memory – 2GB (default), 4GB, or /8GB DDR4 Storage – 16GB eMMC flash 4x 80-pin board-to-board connectors with I/Os and power signals Supply Voltage – DC5V Dimensions – 70 x 45mm Temperature range […]

October 23, 2021May 30, 2022 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

Rockchip RK3566/RK3568 SoM’s feature board-to-board connectors or castellated holes

RK3566 & RK3568 SoM with board-to-board connectors

Rongpin Electronics has designed RK3566 and RK3568 systems-on-modules (SoM) with either board-to-board connectors or castellated holes for direct soldering to the carrier board, which adds competition to the Firefly Core-3568J AI Core Rockchip RK3568 system-on-module offered in a SO-DIMM form factor with an edge connector. The Rongpin Pro-RK3566 and Pro-RK3568 core boards are equipped with four high-speed Hirose connectors, while the RP-RK3568 Core board exposes I/Os through castellated holes around the four sides of the CPU module. Rongpin Pro-RK356x system-on-module & devkit Specifications: SoC – Rockchip RK3566/RK3568 quad-core Cortex-A55 processor @ 2.0 GHz with Arm Mali-G52 2EE GPU with support for OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1, 0.8 TOPS NPU for AI acceleration, 4Kp60 H.265/H.264/VP9 video decoding, and 1080p100 H.265/H.264 video encoding System Memory – 2GB DDR4 (option for 4GB) Storage – 8GB eMMC 5.1 flash (option for 16GB to 128GB) 4x Hirose board-to-board connectors with Storage 1x SATA […]

August 27, 2021September 25, 2021 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Feature-packed i.MX 8M Plus SBC offers dual GbE, PCIe, RS485, CAN Bus, 4G & 5G modems, and more

We’ve already covered plenty of NXP i.MX 8M Plus systems-on-module and carrier boards, but here’s another solution with Forlinx OKMX8MP-C SBC single board computer based on FETMX8MP-C SoM with 4GB LPDDR4 and 16GB eMMC flash. The feature-packed board also offers dual Gigabit Ethernet, 4G and 5G cellular connectivity support via mPCIe and M.2 sockets, multiple display and camera interfaces, RS485 and CAN Bus connector, USB interfaces, various expansion headers, and more… Forlinx OKMX8MP-C specifications: Forlinx FETMX8MP-C System-on-Module SoC – NXP i.MX8M Plus with quad-core Cortex-A53 processor @ up to 1.6 GHz, Arm Cortex-M7 real-time core, Vivante 2D/3D GPUs, 1080p60 video decoder/encoder, 2.3 TOPS AI accelerator System Memory – 2GB, 4GB (default), 6GB, or 8GB LPDDR4 Storage – 16GB eMMC flash Ultra-thin board-to-board connector (4x 80-pin connector with 0.5mm pitch) Supply Voltage – 5V Temperature Range – -40°C to +85°C Dimensions – 62 x 36 mm (8-layer ENIG PCB) Storage – […]

July 25, 2021July 28, 2021 by Jean-Luc Aufranc (CNXSoft) - 13 Comments

Zidoo M6 RK3566 mini PC & SBC supports GbE, WiFi 6, 5G connectivity

Zidoo M6 is both a complete mini PC and a single board computer based on Rockchip RK3566 processor with up to 8GB RAM with plenty of peripherals connectivity options including built-in Gigabit Ethernet, WiFi 6, Bluetooth 5, and support for 5G modems. Several years ago, Zidoo used to serve the TV box market, but they’ve now veered towards higher-end media players, digital signage players, and industrial applications. While we’ve already seen some RK3566 TV boxes on the market, using the AIoT processor does not make much sense in this type of product, and instead, Zidoo M6 targets AI Edge gateways, digital signage, and other AIoT products. Zidoo M6 specifications: SoC – Rockchip RK3566 with a quad-core Cortex-A55 processor @ up to 1.8GHz, Arm Mali-G52 2EE GPU with support for OpenGL ES 1.1/2.0/3.2. OpenCL 2.0. Vulkan 1.1, 0.8 TOPS AI accelerator, 4K H.265/H.265/VP9 video decoder, 1080p100 H.265/H.264 video encoder. System Memory […]

October 21, 2020October 21, 2020 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Forlinx OK1028A-C networking SBC supports LVDS displays, 4G/5G modules

Forlinx released two networking SBC’s with 10Gbps Ethernet powered by NXP LS1043A and LS1046A processor nearly exactly one year ago. Like many other networking SBCs they do not come with video output so configuration is done via a computer or laptop either through a UART interface or a web interface. But in some cases, such boards may be integrated into machines that require a display for human-machine interaction. That’s why Forlinx has now released a new networking board – OK1028A-C – powered by NXP QorIQ Layerscape LS1028A dual-core Cortex-A72 processor that natively supports video output up to 4K UHD resolution via an eDP/DisplayPort interface which the company used to provide an LVDS header. The board also offers 5 Gigabit Ethernet ports, as well as optional WiFi, Bluetooth, and 4G or 5G cellular connectivity via M.2 and mPCIe modules. Forlinx OK1028A-C specifications: FET1028A-C system-on-module SoC – NXP LS1028A dual-core Cortex-A72 processor […]

April 23, 2020April 23, 2020 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Qt for MCUs 1.1 Adds Support for more STM32 and NXP i.MX RT Boards, FreeRTOS

The first stable version of Qt for MCUs was released in August 2019 in order to bring Qt graphical toolkit to microcontrollers such as STMicro STM32F7, Renesas RH850, or NXP i.MX RT1050. Qt for MCUs would run bare metal on supported boards, and software engineers would develop graphical interface using QML and C++. Qt for MCUs 1.1 has just been released with the addition of more STM32 and i.MX RT boards, support for FreeRTOS real-time operating system, and more. Qt for MCUs 1.1 highlights: Five new supported boards: NXP i.MX RT 1064 EVK, STM32 H750B-DK, STM32 F469i-disco, STM32 L4R9i-disco, and STM32 L4R9i-eval Asset management Optional PNG compressions for assets to lower storage footprint Option to read data directly from flash memory for lower RAM consumption, or copy to RAM for better performance, at the cost of higher RAM consumption. FreeRTOS support (technology preview) to run background tasks without blocking the […]
