January 3, 2024January 2, 2024 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Fanless Intel N100 mini PC supports PoE power input, provides four 2.5GbE ports

‎NEOSMAY is selling a fanless Intel Processor N100 mini PC with support for PoE power input, four 2.5GbE ports, HDMI and DisplayPort video outputs, and a choice of USB ports for $249 (after ticking the $150 coupon code) on Amazon with 8GB RAM and a 128GB SATA SSD. The mini PC also supports 12V DC power input if you don’t use PoE power input, and comes with an additional RJ45 port acting as an RS232 console. There’s no built-in wireless, but the mini PC can take a WiFi and Bluetooth module, as well as a 4G LTE or 5G module, and features a SIM card slot for the latter. Specifications: SoC – Intel Processor N100 quad-core Alder Lake-N processor @ up to 3.4 GHz (Turbo) with 6MB cache, 24EU Intel HD graphics @ 750 MHz; TDP: 6W System Memory – 8GB DDDR4-3200, upgradable to 32GB Storage 128GB M.2 SATA SSD, […]

December 19, 2023December 20, 2023 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

iKOOLCORE R2 (Core i3-N300) system review – Part2: Proxmox VE, Ubuntu 22.04, pfSense

iKOOLCORE R2 Ubuntu Promox VE dual display

In the first part of iKOOLCORE R2 mini PC & router review, I had a look at the hardware with an unboxing and a teardown of the Intel Core i3-N300 Alder Lake-N computer and also noticed the device booted to a UEFI shell. So for the second part of the review, I will report my experience installing Proxmox VE on the iKOOLCORE R2 and setting up and using Ubuntu 22.04, pfSense 2.7.2, and OpenWrt 23.05 virtual machines, making sure I can still use a physical display, keyboard, and mouse with Ubuntu while pfSense firewall is running. As a side note, the previous generation iKOOLCORE R1 mini PC that was sent to Ian for review with Proxmox VE and various virtual machines preinstalled OpenWrt, Debian 11, and Windows 10 Enterprise LTSC set to Chinese language by default. As I understand it, iKOOLCORE still does that for the Chinese market, but not […]

December 17, 2023December 15, 2024 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

How to use a monitor and USB mouse/keyboard in Promox VE on an Intel Alder Lake-N mini PC

Intel Core i3-N300 Alder Lake-N Ubuntu 22.04 Promox VE passthrough

We’ve started to see several Alder Lake-N platforms acting both as a mini PC and a router or network appliance with products such as iKOOLCORE R2 or CWWK x86-P5 which features not only the usual HDMI, USB, and single Ethernet port, but come with multiple Ethernet ports making them ideal to run Proxmox VE to simultaneous run a desktop OS such as Ubuntu 22.04 or Windows 11 and a headless network OS such as pfSense or OpenWrt. I’m currently reviewing iKOOLCORE R2 mini PC that comes with four 2.5GbE ports and I could install Ubuntu 22.04 Desktop, pfSense 2.7.1, and OpenWrt 23.05 relatively easily, but the Ubuntu desktop is only visible in the Proxmox VE dashboard and the HDMI display physically connected to the mini PC only shows Proxmox VE login prompt. So at this point, I learned that I had to enable PCIe passthrough for the GPU in Proxmox […]

December 11, 2023December 11, 2023 by Jean-Luc Aufranc (CNXSoft) - 16 Comments

CWWK x86-P5 fanless mini PC with two 2.5GbE ports ships with up to Intel Core i3-N305 CPU

CWWK x86-P5 is a fanless mini PC powered by an Intel Alder Lake N-series N100 (quad-core) or Core i3-N305 (octa-core) and equipped with two 2.5GbE ports using Intel i226V controllers making it suitable for networking applications such as a firewall or a soft router. But it’s also a standard mini PC with two HDMI 2.0 ports, two USB 3.2 ports, and up to four USB 2.0 ports making it a candidate to run Promox with both a desktop OS like Windows 11 or Ubuntu 22.04 and a networking OS such as pfSense or OpenWrt. CWWK x86-P5 specifications: Alder Lake-N SoC(one or the other) Intel Processor N100 quad-core processor @ up to 3.4 GHz (Turbo) with 6MB cache, 24EU Intel UHD graphics; TDP: 6W Intel Core i3-N305 octa-core processor @ up to 3.8 GHz (Turbo) with 6MB cache, 32EU Intel UHD Graphics; TDP: 15W System Memory – Up to 32GB DDR5 […]

October 25, 2023June 11, 2024 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

AOOSTAR R1 – An Intel N100 2-bay NAS, mini PC, and 2.5GbE router

AOOSTAR R1 Intel N100 mini PC triples as a 2-bay NAS thanks to two bays for 3.5-inch SATA drives and as a router through two 2.5GbE network interfaces. It’s a lower-cost version of the Ryzen 5-powered AOOSTAR N1 Pro that was introduced last June. It ships with up to 16GB DDR4 RAM, an optional 512 GB NVMe SSD, offers WiFi 6 and Bluetooth 5.2 connectivity, supports up to three displays via HDMI, DisplayPort and USB-C ports, and comes with five USB ports. AOOSTAR R1 (also called WTR R1) specifications: SoC – Intel Processor N100 quad-core Alder Lake-N processor @ up to 3.4 GHz (Turbo) with 6MB cache, 24EU Intel HD graphics @ 750 MHz; TDP: 6W System Memory – Optional 16GB DDR4-3200 via SO-DIMM socket Storage Optional 512GB M.2 2280 NVMe SSD 2-bay NAS compatible with 2.5-inch or 3.5-inch SATA drives MicroSD card slot Video Output 4Kp60 video output […]

August 9, 2023August 9, 2023 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Tiny mini PC with four 2.5Gbps Ethernet ports ships with Intel Processor N100/N200 or Core i3-N305 CPU

The “M1 Pocket Mini Soft Router” is a tiny Intel Alder Lake-N OEM mini PC with four 2.5Gbps Ethernet ports that is powered by a Processor N100, Processor N200, or Core i3-N305 CPU and sold by various brands such as Kingnovy or Tuofudun Topton. The pocket-sized computer comes with up to 16GB DDR5 memory, up to 1TB NVMe SSD, and features HDMI 2.0 and DisplayPort USB-C video outputs, two USB 3.0 ports, as well as a microSD card slot and a 3.5mm audio jack. M1 mini PC specifications: Alder Lake-N SoC Intel Processor N100 quad-core processor @ up to 3.4 GHz (Turbo) with 6MB cache, 24EU Intel UHD graphics; TDP: 6W Intel Processor N200 quad-core processor @ up to 3.7 GHz (Turbo) with 6MB cache, 32EU Intel HD graphics; TDP: 6W Intel Core i3-N305 octa-core processor @ up to 3.8 GHz (Turbo) with 6MB cache, 32EU Intel UHD Graphics; TDP: 15W […]

June 26, 2023June 26, 2023 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

Intel soft router offers up to eight 2.5GbE ports, Comet Lake or Whiskey Lake Core processor

Topton is offering a soft router powered by an Intel Whiskey Lake or Comet Lake processor up to the Core i7-10510U quad-core/octa-thread processor with either eight 2.5GbE RJ45 ports or four 2.5GbE RJ45 ports and two 10GbE SFP+ cages. We’ve previously written about the low-cost InuoMicro G4305L8-S2 fanless industrial PC box with eight 2.5GbE interfaces, but it is powered by an Intel Celeron 4305UE dual-core Whiskey Lake processor, and the Topton model should offer more performance with a choice of 8th or 10th generation Intel Core i3/i5/i7 Whiskey Lake or Comet Lake SoC. Specifications: SoC (one or the other) Intel Core i3-8145UE dual-core Whiskey Lake processor up to 3.90 GHz with Intel UHD Graphics 620; 15W TDP Intel Core i5-10210U quad-core/eight-thread Comet Lake processor @ 1.6 GHz / 3.9 GHz (turbo all cores) / 4.2 GHz (turbo one core), 24EU Intel UHD graphics; 6MB Cache; 15W TDP Intel Core i7-10510U […]

May 16, 2023July 8, 2023 by Ian W MORRISON (Linuxium) - 56 Comments

Beelink EQ12 Review – An Intel Processor N100 mini PC tested with Windows 11, TrueNAS, pfSense, Ubuntu, and more

Beelink’s new EQ series of mini PCs form their base product range and feature low-powered Jasper Lake and Alder Lake-N processors with relatively basic port and memory/storage configurations. Perhaps more importantly, they are also the cheapest mini PCs they offer. Having recently announced the EQ12 mini PC featuring an Intel Processor N100 ‘Alder Lake-N’ CPU with up to 16GB RAM, Beelink have now sent one for review. Whilst I’ll cover the basic Windows operation and performance, I’ll also explore how this new mini PC performs when used as an integrated router and NAS. Beelink EQ12 specifications Beelink list the EQ12 specifications as: It is worth noting that the Processor N100 processor only supports a single memory channel and that according to Intel’s specification for the processor, the maximum memory supported is only 16 GB. Intel’s specification for the number of graphical execution units (EUs) also states 24 however software such […]
