Intel Core Ultra 200S/200U/200H-powered COM-HPC Client modules support up to 192GB DDR5 memory, PCIe Gen5

Portwell COM HPC client modules PCOM B887 and PCOM B886

Portwell PCOM-B887 and PCOM-B886 are two new COM-HPC client modules built around Intel Core Ultra 200S/200U/200H processors delivering high-performance computing and AI acceleration for industrial, edge, and AI-driven applications. The Portwell PCOM-B887 (Size C) module is built around the 200S Series, offers up to 36 TOPS, supports 192GB DDR5 memory, and features 42 PCIe lanes up to Gen5. The PCOM-B886 (Size B) module supports 200H/200U Series processors, which deliver up to 99 TOPS, support 96GB DDR5 memory, and include 24 PCIe lanes. Both modules feature various I/O options, including USB4, USB3.2 Gen2, and multiple display outputs. Portwell PCOM-B887 – COM-HPC Client Type Size C module The PCOM-B887 COM-HPC Client Type Size C module is powered by Intel Core Ultra 200S Series processors, which feature up to 36 TOPS of AI performance via an integrated neural processing unit (NPU). It supports up to 192GB of DDR5 memory at 4800MT/s with 42 […]

Posted on by Sayantan Nandy - No Comments on Portwell PJAI-100-ON rugged Edge AI embedded system features NVIDIA Jetson Orin Nano for industrial quality control

Portwell PJAI-100-ON rugged Edge AI embedded system features NVIDIA Jetson Orin Nano for industrial quality control

Portwell PJAI-100-ON

Portwell has launched the PJAI-100-ON, a rugged and compact embedded system powered by the NVIDIA Jetson Orin Nano SOM and designed for demanding industrial environments. It operates reliably across a wide temperature range of -20°C to 60°C with a fanless, quiet design that requires minimal maintenance. Equipped with dual Gigabit Ethernet LAN ports and M.2 slots for wireless connectivity, the PJAI-100-ON is tailored for Edge AI applications. This system enhances quality control in manufacturing by using advanced optical inspection technology to detect defects, improving quality assurance and reducing production errors. Previously, we covered other Jetson Orin Nano embedded systems, including Aetina’s AIE-KO21, AIE-KO31, AIE-KN31, and AIE-KN41 and DFI X6-MTH-ORN fanless Edge AI Box computer, as well as Portwell’s WEBS-21J0-ASL another rugged embedded system built around an Intel Atom x7000RE Amstom Lake Nano-ITX motherboard and equipped with an Hailo-8 AI accelerator. Portwell PJAI-100-ON specifications: SoM – NVIDIA Jetson Orin Nano CPU […]

Posted on by Sayantan Nandy - 1 Comment on Portwell WEBS-21J0-ASL – A rugged embedded system with Intel Atom x7000RE Nano-ITX motherboard and Hailo-8 AI accelerator

Portwell WEBS-21J0-ASL – A rugged embedded system with Intel Atom x7000RE Nano-ITX motherboard and Hailo-8 AI accelerator

WEBS-21J0-ASL Nano-ITX embedded system

Portwell’s WEBS-21J0-ASL is a fanless, rugged embedded system with a Nano-ITX motherboard powered by an Intel Atom x7000RE Series processor and optimized for industrial IoT applications. It features two 2.5Gbps Ethernet ports, dual 4K display support (DP/HDMI), and a serial port as well as M.2 E and B Key sockets for wireless and storage expansion. Designed for harsh environments, the WEBS-21J0-ASL operates in temperatures ranging from -20°C to 60°C. The system is equipped with DDR4 SO-DIMM memory (up to 16GB and 10Gbps USB 3.2 Gen 2 ports. It has passed vibration and shock tests for durability in rugged applications making it suitable for a wide range of industrial and automation systems. The WEBS-21J0-ASL also supports optional integration with the Hailo-8 AI acceleration module delivering up to 26 TOPS of AI performance for applications requiring advanced AI capabilities. This makes it an ideal solution for robotics, medical equipment, outdoor gateways, and […]

Posted on by Debashis Das - No Comments on Portwell PEB-2274 3.5-inch fanless Intel Atom x6425E SBC offers triple display support, dual GbE, three M.2 sockets, and more

Portwell PEB-2274 3.5-inch fanless Intel Atom x6425E SBC offers triple display support, dual GbE, three M.2 sockets, and more

PEB 2274 3.5 Inch Elkhart Lake SBC

Portwell has recently launched PEB-2274, a 3.5-inch fanless SBC built around Intel Atom x6425E Elkhart Lake SoC. Key features include up to 32GB DDR4 memory, two Gigabit Ethernet ports, three M.2 sockets for storage and expansion, and a wide 9V to 36V DC power input. Additionally, it has various display interfaces (HDMI, DP, LVDS), multiple serial ports, USB, and audio options. We have already covered several other 3.5-inch inch Elkhart Lake SBCs with dual Ethernet ports including the Avalue ECM-EHL 3.5-inch SBC, Congatec Conga-PA7 Pico-ITX board, the iBase IB836 3.5-inch SBC, and the AAEON GENE-EHL5 SBC. All these boards support dual Ethernet and some of them have support for triple ethernet ports. But what’s unique about the PEB-2274 is that it has dual GbE ethernet, triple display, and a design specifically for industrial applications. Portwell PEB-2274 specifications: SoC – Intel Atom x6425E quad-core processor @ 2.00 GHz / 3.00 GHz […]

Posted on by Debashis Das - No Comments on Nano-ITX motherboard is powered by Intel Atom x7000RE Series “Amston Lake” SoC

Nano-ITX motherboard is powered by Intel Atom x7000RE Series “Amston Lake” SoC

NANO 6064 ASL An Intel Atom x7000RE Series SoC based NANO ITX Board with Triple Display, 2.5GbE LAN, USB 3.2 Gen2, M.2, SATA III

Portwell NANO-6064-ASL is an Intel Atom “Amston Lake” x7000RE-powered Nano-ITX motherboard. The board looks very similar to the Portwell Nano-6062 and features an operating temperature of -40°C to 85°C. The motherboard can support a max of 16GB DDR4 memory and features triple display output, dual 2.5Gbps Ethernet, USB, M.2, SATA, GPIO, and more, and takes power from a 12V external power input. Previously, we’ve written about a range of Nano-ITX boards and SoMs with Amston Lake SoCs, including the ASRock SBC-262M-WT, conga-SA8 SMARC modules, ADLINK Atom x7000RE & x7000C COM Express and SMARC 2.1 modules and others. If you’re looking for similar options, feel free to check out those articles. Portwell NANO-6064-ASL Specifications SoC (one or the other) Amstom Lake Intel Atom x7211RE dual-core processor with 6MB cache, 16EU Intel UHD graphics; 6W TDP Intel Atom x7213RE dual-core processor with 6MB cache, 16EU Intel UHD graphics; 9W TDP Intel Atom x7433RE […]

Posted on by Tomisin Olujinmi - No Comments on The PCOM-B65A COM Express module is powered by Intel Core Ultra Processors

The PCOM-B65A COM Express module is powered by Intel Core Ultra Processors

PCOM B65A front

Taiwan-based embedded systems manufacturer, Portwell, has announced a new COM Express Type 6 Basic module based on the Intel Core Ultra processor platform. The Portwell PCOM-B65A module is a minimal COM Express module that comes with either one of the H-series or U-series processors in the Core Ultra series. The Intel Core Ultra series (formerly known as Meteor Lake) uses Intel’s 3D performance hybrid architecture (two core microarchitectures on a chip) to optimize performance and distribute workloads efficiently. It also features an integrated neural processing unit that offers low-power AI acceleration and hardware offloading.The I/O and artificial intelligence feature set on the PCOM-B65A COM Express module suits several embedded applications such as medical devices, automation, IoT, and industrial control. We have already covered other products based on the newly released 14th Gen Intel Core Ultra (Meteor Lake) series with the ADLINK’s cExpress-MTL Type 6 Compact module and the ASRock Industrial’s […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Portwell COM Express Tiger Lake-H module supports 2.5GbE, PCIe Gen 4, 8K, up to 64GB DDR4

Portwell COM Express Tiger Lake-H module supports 2.5GbE, PCIe Gen 4, 8K, up to 64GB DDR4

Portwell PCOM-B657VGL COM Express TIger Lake-H

Portwell PCOM-B657VGL joins other COM Express and COM HPC modules based on Intel Tiger Lake-H Xeon, Core, and Celeron embeddded processors such as ADLINK Express-TL and Congatec conga-HPC/cTLH. Just like its competitors, the Portwell COM Express Type 6 Basic module offers 8K video output, PCIe x16 Gen 4, up to 64GB DDR4, USB 3.2 Gen 2, and 2.5GbE networking for a wide range of higher-end embedded applications such as industrial automation, medical equipment, graphics-intensive applications, and artificial intelligence. Portwell PCOM-B657VGL specifications: SoC (one or the other) General Embedded Intel Celeron 6600HE dual-core processor @ 2.6GHz with 8MB L3 Cache, 16EU Intel UHD graphics, 35W TDP Intel Core i3-11100HE processor with 4 cores / 8 threads @ 2.4GHz (up to 4.4GHz in Turbo Boost) with 8MB L3 Cache, 16EU Intel UHD graphics, 45/35W cTDP Intel Core i5-11500HE processor with 6 cores / 12 threads @ 2.6GHz (up to 4.1GHz in Turbo […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Portwell Nano-6062 Nano-ITX Apollo Lake Board is Powered by Intel Atom E3900 Series Processors

Portwell Nano-6062 Nano-ITX Apollo Lake Board is Powered by Intel Atom E3900 Series Processors

We’ve seen a series of announcements of Intel Apollo Lake based boards and modules in the last couple of weeks, with community boards such as UP Squared to ASRock IMB-157 mini-ITX board, and industrial system-on-modules and carrier boards such as the ones offered by Congatec, Seco, and Adlinktech. One more embedded systems company has now unveiled their Apollo Lake solutions with Portwell Nano-6062 Nano-ITX motherboard powered by Intel Atom E3900 “Apollo Lake” SoCs. Portwell Nano-6062 Nano-ITX board support either of the new new Apollo Lake SoCs: SoC Intel Atom x5-E3930 dual core processor @ 1.3 / 1.8 GHz with 2MB L2 cache 1MB, 12 EU Intel Gen 9 HD Graphics (6.5W TDP) Intel Atom x5-E3940 quad core processor @ 1.6 / 1.8 GHz with 2MB L2 cache, 12 EU Intel Gen 9 HD Graphics (9W TDP) Intel Atom x7-E3950 quad core processor @ 1.6 / 2.0 GHz with 2MB L2 […]
