NXP i.MX 8M Plus 2.5-inch Pico-ITX SBC supports UIO40-Express expansion modules

With NXP i.MX 8M Plus AI processor nearing mass production, we’ve seen many companies introduce i.MX 8M Plus systems-on-module at Embedded World 2021. But as one would come to expect, there should also be single board computers based on the new processor, and Advantech has unveiled the RSB-3720 2.5-inch SBC (aka Pico-ITX SBC) compatible with the company’s UIO40-Express expansion boards. RSB-3720 specifications: SoC – NXP i.MX8M Plus dual or quad-core Arm Cortex-A53 processor up to 1.8GHz (1.6 GHz for industrial temperature range) with Cortex-M7 real-time core, Vivante GC7000UL 3D GPU, 1080p60 H.265/H.264/VP9 decoder, 1080p60 H.265/H.264 encoder, 2.3 TOP/s Neural Network Accelerator System Memory – 4GB or 6GB LPDDR4 4000MT/s Storage – 16 GB eMMC Flash for OS, 8 MB QSPI NOR Flash for board information, microSD socket Video Output – HDMI 2.0a up to 3840 x 2160 at 30Hz Single or dual-channel 24 Bit LVDS with backlight power, 5/12V, Max. […]

February 22, 2021 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

STM32MP1 Linux SoM fits into Pico-ITX carrier board

DH electronics DHCOM STM32MP1 is an STMicro STM32MP1 Cortex-A7/M4 system-on-module (SoM) following the company’s SO-DIMM-based DHCOM standard, and capable of running Linux with Etnaviv GPU drivers. The SoM is compatible with two DHCOM carrier boards from the company, namely DH PDK (Premium Developer Kit) for development, and DH PicoITX2 Pico-ITX board for direct integration into products. DHCOM STM32MP1 SoM DHCOM STM32MP1 specifications: SoC – STMicro STM32MP15x with up to two Arm Cortex-A7 core up to 650 MHz, one Arm Cortex-M4 up to 209 MHz, Vivante 3D GPU @ up to 533 MHz with OpenGL ES 2.0 support System Memory – 256, 512, or 1024 MB 32-bit DDR3 DRAM Storage 4, 8, or 16 GB eMMC flash 2 MB boot flash 256 bytes EEPROM MicroSD card socket on module Connectivity – WiFi 4 IEEE 802.11 a/b/g/n, 802.11j (hosted mode) with dual band, Bluetooth 5.0 (BR/EDR/BLE), PCB antenna and U.FL antenna connector […]

February 10, 2021February 10, 2021 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

Ready! Model 100 is a retro computer shell for Raspberry Pi, SBCs, Nano/Pico-ITX boards (Crowdfunding)

Ready Model 100 Raspberry Pi SBC Computer Shell

We recently wrote about Devterm, a modular, retro-looking portable computer that looks like a typewriter with an extra-wide display, and takes Raspberry Pi CM3-series modules, or other compatible modules made by Clockwork based on Rockchip RK3399 or Allwinner H6. If you’re into this kind of device, but would like to use your own Raspberry Pi, another SBC, an Intel NUC motherboard, a Nano/Pico-ITX board, or even your smartphone, Ready! Model 100 single board computer expansion system may be worth looking into. Ready! Model 100 key features and specifications: Compatibility – Accommodates any hardware using 5V or 12V power input including smartphones, or arm or x86 SBCs such as Raspberry Pi 4, and compact motherboard following NUC, 4×4, 5×5, or Nano/Pico ITX form factors. Storage – Space for SSD Display – 8.8-inch 1920×480 “3xVGA” HDMI Touchscreen Video Output – HDMI (if dual HDMI supported on SBC) Audio – 10W stereo speaker […]

January 25, 2021January 25, 2021 by Sponsored Post - Comments Off

Edge computing boards with new Intel Atom x6000E processors (Elkhart Lake) – Sponsored

A highly reliable performance boost for the edge The new Intel Atom® x6000E Series, Intel Celeron®, and Pentium® N & J processors (code name Elkhart Lake) impress with twice the graphics speed of their predecessors and 50% more multi-thread performance on up to 4 cores. congatec is now making these processors available on the 2.5-inch Pico-ITX form factor, leveraging their industrial quality for the most reliable performance boost possible. With growing digitization and the IoT trend, even the smallest edge computers are expected to meet high-reliability requirements today. Start-ups, makers, and spin-offs from big industrial companies increasingly deploy them in massively distributed applications to implement their new business models and IoT-supported services. They all face a similar challenge: Their apps are approaching market-readiness but their hardware platforms, which often originate from the maker board scene, lack reliability since they were not designed for large series and harsh environments. Industrial edge […]

January 12, 2021 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

2.5-inch “Industrial Pi” Pico-ITX SBC offers PoE , mini DP++ port

Taiwan based DFI has launched the AL05P “Industrial Pi + PoE” 2.5-inch Pico-ITX SBC powered by an Apollo Lake processor that reminds me of last year’s DFI GHF51 SBC based on AMD Ryzen Embedded R1606G processor but with a larger, and more standard form factor that’s also part of the “Industrial Pi” family. The board also comes with 4GB RAM, up to 64GB eMMC, a mini DisplayPort video output, two USB 3.1 ports, Gigabit Ethernet with isolated PoE, a mini-PCIe, and more. DFI AL05P SBC specifications: SoC (one or the other) Intel Atom x5-E3940 quad-core processor @ 1.6/1.8 GHz with 2MB cache, Intel HD Graphics; 9.5W TDP Intel Atom x5-E3930 dual-core processor @ 1.3/1.8 GHz with 2MB cache, Intel HD Graphics; 6.5W TDP Intel Pentium N4200 quad-core processor @ 1.1/2.5 GHz with 2MB cache, Intel HD Graphics; 6W TDP Intel Celeron N3350 dual-core processor @ 1.1/2.4 GHz with 2MB cache, […]

September 24, 2020September 24, 2020 by Jean-Luc Aufranc (CNXSoft) - No Comments

Congatec Unveils Atom x6000E Elkhart Lake Powered Pico-ITX SBC, Qseven, SMARC, COM Express Modules

With the announcement of Intel Elkhart Lake IoT-optimized processors, we should expect embedded systems companies to unveil their own Atom x6000E and Celeron/Pentium Elkhart Lake powered products, and one of the first to do so is Congatec with the introduction of four different Elkhart Lake computers-on-module (CoM) following Qseven, SMARC, and COM Express standards, as well as a Pico-ITX SBC. conga-PA7 Atom x6000E SBC (with Celeron/Pentium J optional) Detailed specifications: SoC – Choice of eight different Elkhart Lake processors from the 6W Atom x6211E dual-core processor to the 10W Intel Pentium J6425 quad-core processor up to 3.0 GHz, all with 10th Gen Intel UHD graphics System Memory – Up to 16GB quad-channel onboard LPDDR4x Storage 32GB or 64GB UFS 2.0 flash (optional up to 512GB) M.2 SATA/PCIe SSD support (see expansion) 32 MB serial flash for AMI Aptio UEFI firmware Video DisplayPort DP++ video output up to 4Kp60 1x USB-C […]

February 12, 2020 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

AAEON PICO-WHU4 Whiskey Lake Pico-ITX Board is Designed for AI and Edge Computing

AAEON has just launched a Whiskey Lake Pico-ITX SBC made for AI and edge computing with PICO-WH4 featuring a 15W Intel Core i3/i5/i7 or Celeron processor combined with up to 16GB DDR4 memory, The board offers dual Gigabit Ethernet connectivity, dual display support with HDMI connectors, USB 3.2 ports, SATA storage, as well as mPCIe and M.2 expansion slots. AAEON PICO-WHU4 specifications: SoC (one or the other; all Whiskey Lake U-series processors) Intel Celeron 4305UE dual-core processor @ 2.00 GHz (no turbo frequency) with Intel UHD Graphics 610 @ 300 MHz / 1.0 GHz (Turbo); 15W TDP Intel Core i3-8145UE dual-core/quad-thread processor @ 2.2 GHz / 3.9 GHz (Turbo) with Intel UHD Graphics 620 @ 300 MHz / 1.0 GHz (Turbo); 15 TDP Intel Core i5-8365UE quad-core/octa-thread processor @ 1.6GHz / 4.1GHz (Turbo) with Intel UHD Graphics 620 @ 300 MHz / 1.05 GHz (Turbo); 15 TDP Intel Core i7-8665UE […]

October 23, 2019October 23, 2019 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

GIGABYTE GA-PICO3350 Apollo Lake Pico-ITX Board Comes with SO-DIMM RAM Slot, SATA and mSATA Storage

GIGABYTE GA-PICO3350 may be the smallest motherboard from the company so far. The Pico-ITX board comes with an Intel Celeron N3350 dual-core Apollo Lake processor with a SO-DIMM slot, SATA port, and mSATA socket that give you more options will selecting RAM and storage. GA-PICO3350 specifications: SoC – Intel Celeron N3350 dual-core Apollo Lake processor @ up to 2.4 GHz with 2 MB cache, Intel HD graphics; 6W TDP System Memory – 1 x DDR3L SO-DIMM socket supporting up to 8 GB DDR3L 1866/1600 MHz Storage- 1x SATA 6Gb/s connector, 1x mSATA connector (multiplexed with mPCIe), 128 Mbit flash for BIOS/UEFI Video Output HDMI 1.4 up to 3840×2160 @ 30 Hz 1x LVDS header 1x flat panel display header Audio – Realtek ALC887 codec, 1x front panel audio header Connectivity – Gigabit Ethernet port via Realtek PHY USB – 2x USB 3.0/2.0 ports on the back panel, 2x USB 2.0/1.1 […]
