March 3, 2021March 3, 2021 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

It’s raining i.MX 8M Plus systems-on-module at Embedded World 2021

NXP introduced i.MX 8M Plus AI SoC with a built-in 2.3 TOPS neural processing unit (NPU) last year, and we’ve already covered several early announcements about i.MX 8M Plus systems-on-module (SoM) with Variscite VAR-SOM-MX8M-PLUS and DART-MX8M-PLUS, TechNexion EDM-G-IMX8M-PLUS and AXON-E-IMX8M-PLUS respectively using SO-DIMM edge connectors and board-to-board connectors, as well as SolidRun i.MX 8M Plus SoM that was announced together with the HummindBoard Mate carrier board with dual Gigabit Ethernet. But as Embedded World 2021 Digital is taking place virtually until Friday, other companies have now made their own announcements of i.MX 8M Plus SoMs as the processor enters mass production this month, and since as far as I know, it’s pin-to-pin and software compatible with earlier i.MX 8M Nano/Mini SoCs, the update must have been easy. That means we’ve got a longish list of modules, and I have probably missed some. Supported operating systems are basically the same across […]

November 25, 2019 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

Linux 5.4 Release – Main Changes, Arm, MIPS & RISC-V Architectures

Linus Torvalds has just announced the release of Linux 5.4: Not a lot happened this last week, which is just how I like it. And as expected, most of the pull requests I got were for the 5.5 merge window, which I’ll obviously start working through tomorrow. What little there is here is mostly some networking updates (mix of network drivers and core networking), and some minor GPU driver updates. Other than that it’s a small collection of random other things all over. The appended shortlog is small enough that you might as well just scroll through it. Anyway, this obviously opens the merge window for 5.5. It’s not ideal timing with Thanksgiving week coming up, but it hopefully shouldn’t be too much of an issue. If I fall behind (not because I’m all that big of a fan of the indiscriminate and relentless turkey-killing holiday) it’s because we’ve got […]

December 6, 2018December 6, 2018 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

PHYTEC phyCORE-AM65x SoM Features TI Sitara AM654x Processor

We already knew Texas Instruments was working on AM654 processor, the first 64-bit Arm SoC from the company, featuring four Cortex A53 cores, a PowerVR SGX544 GPU, dual lock-step capable Cortex R5F cores, and interfaces targeting industrial applications. Now at least one company has announced a system-on-module based on the solution. PHYTEC phyCORE-AM65x is equipped with AM654x processor, DDR4 and ECC DDR4 memory, up to 32GB eMMC flash, as well as built-in Ethernet, WiFi, and Bluetooth connectivity. phyCORE-AM65x specifications: SoC – Texas Instruments Sitara AM65x with 4x Arm Cortex-A53 cores, dual-core Arm Cortex-R5F MCU subsystem, PowerVR SGX544 GPU, 6x PRU-ICSSG System Memory – DDR4 with support for discrete DDR4 ECC Storage – Up to 32GB eMMC Connectivity Optional 2.4 or 5GHz Certified WiFi Solution 10/100/1000 Mbit/s Ethernet PHY on SOM Board-to-board connectors – 2x “high-density PCB interconnects” Dimensions – 65 x 55 mm The company provides Linux (Yocto Project), Android, […]

March 20, 2018March 20, 2018 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

PHYTEC Introduces phyCORE SoMs & Devkits Based on NXP i.MX8, i.MX 8M, or i.MX 8X Processors

PHYTEC, an embedded systems company headquartered in Germany with global offices, has updated their phyCORE systems-on-module family with 3 sub-families of modules based on NXP i.MX 8, i.MX 8X, or i.MX 8M dual or quad core processors for a total of 9 modules. phyCORE-i.MX 8 Specifications: SoC – NXP i.MX 8Quad, i.MX 8QuadPlus or i.MX 8QuadMax Arm Cortex-A72/A53/M4F processor @ up to 1.6 GHz with Tensilica HiFi 4 DSP @ 666 MHz, 2x Vivante GC7000XSVX GPUs System Memory – 1 to 8GB LPDDR4 RAM Storage – 64MB to 256MB Octal SPI/DualSPI SPI NOR Flash, 4 GB to 128 GB eMMC flash, 4kB EEPROM Connectivity – 2x Gigabit Ethernet PHY 4x 120-pin Board-to-board connectors with: Display – 2x LVDS, 2x MIPI DSI, 1x HDMI Video Input / Camera – 1x HDMI, 2x MIPI CSI Audio – 2x ESAI, up to 4x SAI Networking – 2x 10/100/1000 Mbit/s Ethernet USB – 1x […]

July 3, 2017June 18, 2018 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

Linux 4.12 Release – Main Changes, ARM & MIPS Architectures

Linus Torvalds has just released Linux 4.12: Things were quite calm this week, so I really didn’t have any real reason to delay the 4.12 release. As mentioned over the various rc announcements, 4.12 is one of the bigger releases historically, and I think only 4.9 ends up having had more commits. And 4.9 was big at least partly because Greg announced it was an LTS kernel. But 4.12 is just plain big. There’s also nothing particularly odd going on in the tree – it’s all just normal development, just more of it that usual. The shortlog below is obviously just the minor changes since rc7 – the whole 4.12 shortlog is much too large to post. In the diff department, 4.12 is also very big, although the reason there isn’t just that there’s a lot of development, we have the added bulk of a lot of new header files […]

April 22, 2014 by Jean-Luc Aufranc (CNXSoft) - No Comments

Phytec phyBOARD WEGA Industrial Pico-ITX SBC Features Texas Instruments Sitara AM335x SoCs

Phytec has recently announced phyBOARD WEGA board powered by Texas Instruments AM335x Sitara ARM Processors via their phyCORE-AM335x SoM, which comes with up to 1GB DDR3 SDRAM, and up to 2GB NAND Flash. This single board computer targets industrial HMI (Human Machine Interface) and is suitable for various automation and display applications. PhyBOARD WEGA specifications: SoM – phyCORE-AM335x with: SoC – Texas Instruments Sitara AM355x ARM Cortex-A8 processor @ up to 1GHz, with PowerVR SGX530 GPU System Memory – 256 MB DDR3 RAM (Max: 1GB) Storage – 128 MB NAND Flash (Max: 2GB), optional 8 MB NOR Flash, 4KB EEPROM External Storage – micro SD card slot Connectivity – 2 x 10/100 Ethernet USB – 1 x USB Host, 1 x USB OTG Display I/F – 24bpp TTL Communication Interfaces – 6 x UART, 3 x I2C, 2 x SPI, 1 x CAN Expansion Connectors – 1x ADC(12Bit, 8Channel), GPIOs, […]

July 25, 2013December 15, 2013 by Jean-Luc Aufranc (CNXSoft) - No Comments

$55 Phytec Cosmic Boards Feature Freescale Vybrid SoCs

Freescale Vybrid SoC family has been announced at the beginning of last year, with the low-end VF3xx and mid-end VF4xx featuring a single Cortex A5 CPU, and the higher-end VF6xx and VF7xx providing a multi-core processor with Cortex A5 and Cortex M4 cores, for respectively performance, and real-time/low power tasks. Phytec has just announced the Cosmic board featuring Freescale Vybrid VF6xx single core Cortex A5 processor, and Cosmic+ board with Vybrid VF6xx Cortex A5 + Cortex M4 processor. Both boards are comprised of a baseboard coupled with a Phytec phyCORE-Vybrid system-on-module (SoM), and can be used for Linux and MQX (Freescale RTOS) development. Cosmic / Cosmic+ boards specifications: Processor VF5xx ARM Cortex-A5 @ 500MHz (Cosmic) VF6xx ARM Cortex-A5 @ 500MHz + ARM Cortex-M4 @ 167 MHz (Cosmic+) System Memory – 512 MB DDR3 Storage – 512 MB NAND + micro SD slot USB – HS USB OTG / HS USB […]

February 20, 2013 by Jean-Luc Aufranc (CNXSoft) - No Comments

Phytec India Unveils “Open Board-AM335x” Development Kit

PHYTEC has launched the Open Board-AM335x development kit in order to support Linux and Android development on Texas Instruments AM335x Sitara ARM Processors in India. The Open Board-AM335x is comprised of a baseboard and phyCORE-AM335x SoM, and comes with 512 MB DDR3 SDRAM, 512 MB NAND Flash, and optionally, 8 MB SPI Flash. The baseboard is open source hardware as schematics and Gerber/BOM are freely available. Here are the key features of Phytec Open Board-AM335x: SoM – PhyCore-AM335x with ARM Cortex-A8 processors @ 720 MHz (AM3352, AM3354, AM3356, AM3357, AM3358 and AM3359) System Memory – 512 MB DDR3 RAM Storage – 512 MB NAND + SD Card slot + 8 MB SPI NOR Flash (Optional) + 32 KB EEPROM (Optional) Serial – 1x UART (RS232) + 4x UART (TTL) USB – 1x USB Host + 1x USB OTG Connectivity – 1x 10/100/1G Ethernet Audio – WM8974 Codec Display Interfaces – 24 bpp TTL […]
