panel pc

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Raspberry Pi CM4-based industrial panel PC adds 4G LTE, RS232 and RS485, M.2 NVMe SSD

Raspberry Pi CM4-based industrial panel PC adds 4G LTE, RS232 and RS485, M.2 NVMe SSD

10.1-inch Raspberry Pi CM4 panel PC

EDATEC ED-HMI2120-101C is a Raspberry Pi CM4-based industrial panel PC with a 10.1-inch capacitive touchscreen display with plenty of interfaces to cater to a wide range of use cases from robotics to energy management and industrial automation. The panel PC builds upon the ED-HMI2020-101C introduced just a few months ago, but adds a range of features with dual Ethernet, RS485 and RS232 interfaces, and optional supports for an M.2 NVMe SSD and 4G LTE cellular connectivity. The device now supports an even wider DC input range from 9V to 36V and provides three 12V DC outputs to power external hardware such as an additional LCD. ED-HMI2120-101C specifications (with highlights in bold and strikethrough showing the differences against the earlier ED-HMI2020-101C model): System-on-Module (SoM) – Raspberry Pi CM4 SoC – Broadcom BCM2711 CPU – Quad-core Cortex-A72 processor @ 1.5GHz GPU – VideoCore VI conformant with OpenGL ES 3.1 & Vulkan 1.2 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on EDATEC ED-HMI2020-101C – A 10.1-inch Raspberry Pi CM4-based industrial panel PC

EDATEC ED-HMI2020-101C – A 10.1-inch Raspberry Pi CM4-based industrial panel PC

10.1-inch Raspberry Pi CM4 industrial panel PC

EDATEC has launched yet another Raspberry Pi CM4-based platform for industrial applications with the ED-HMI2020-101C 10.1-inch panel PC with 1280×800 resolution, 9V to 28V wide power input, and support for an optional “extended display” via an HDMI FPC cable that also carries USB/I2C signal for the touchscreen. The system comes with up to 8GB RAM, 32GB eMMC flash, Gigabit Ethernet, optional WiFi 5 and Bluetooth 5.0, built-in stereo speakers, several other audio interfaces, as well as a 40-pin GPIO header for expansion. EDATEC ED-HMI2020-101C specifications: System-on-Module (SoM) – Raspberry Pi CM4 SoC – Broadcom BCM2711 CPU – Quad-core Cortex-A72 processor @ 1.5GHz GPU – VideoCore VI conformant with OpenGL ES 3.1 & Vulkan 1.2 VPU 4Kp60 H.265 video decoder 1080p60 H.264 video decoder 1080p30 H.264 video encoder System Memory – 1GB, 2GB, 4GB, 8GB LPDDR4-3200 SDRAM Storage – 8GB, 16GB, 32GB eMMC flash Wireless – Optional WiFi 5 and Bluetooth […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Cincoze P1201 – A slim Atom x6000E Elkhart Lake PC for embedded and panel PC applications with a CDS connector

Cincoze P1201 – A slim Atom x6000E Elkhart Lake PC for embedded and panel PC applications with a CDS connector

Elkhart Lake Embedded PC Panel PC

Cincoze P1201 is a slim embedded computer based on an Atom x6000E Elkhart Lake processor and mostly designed for panel PC applications thanks to the company’s patented CDS (Convertible Display System) connector that allows the mini PC to slide into the back of a display for easy installation. Equipped with up to 32GB RAM, SATA and/or mSATA storage, the P1201 can also be used for generic embedded and industrial applications thanks to DisplayPort and VGA video interfaces, two Gigabit Ethernet ports, optional wireless modules for WiFi, Bluetooth, and cellular, terminal blocks for RS232, RS485, and digital I/Os, as well as support for a wide supply voltage up 48V, and a -40°C to 70°C operating temperature range. Cincoze P1201 specifications: Elkhart Lake SoC (one or the other) Intel Atom x6425E quad-core processor @ 2.00 GHz / 3.0 GHz with 1.5MB cache, 32 EU UHD graphics; 12W TDP Intel Atom x6211E dual-core […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on Raspberry Pi CM4 based 7-inch industrial Panel PC takes IO board with RS232, 12V-24V inputs and outputs

Raspberry Pi CM4 based 7-inch industrial Panel PC takes IO board with RS232, 12V-24V inputs and outputs

Raspberry Pi CM4 industrial panel PC

The ComfilePi CPi-C070WR4C is a 7-inch industrial Panel PC powered by a Raspberry Pi CM4 module with GPIO, RS-232, RS-485, and I2C interfaces as well as the ability to add two more RS232 interfaces and several 12V-24V DC inputs and outputs through an I/O board connected to the GPIO port of the panel PC. The new panel PC is an update to the ComfilePi Industrial Touch Panel PC introduced with a Raspberry Pi CM3 module in 2017. Besides upgrading to a more powerful Raspberry Pi Compute Module 4,  COMFILE also makes use of an RS-485 port that utilizes a full UART interface that does not exhibit the limitations of the mini-UART interface, and also added the CP-IO13-4C I/O board for even more expansion capabilities. ComfilePi CPi-C070WR4C specifications: SoM – Raspberry Pi Compute Module 4 with SoC – Broadcom BCM2711 quad-core Arm Cortex-A72 processor @ 1.5GHz with VideoCore Vi GPU supporting […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Chipsee AIO-CM4-156 – A 15.6-inch industrial All-in-One computer with Raspberry Pi CM4

Chipsee AIO-CM4-156 – A 15.6-inch industrial All-in-One computer with Raspberry Pi CM4

15.6-inch industrial all-in-one computer raspberry pi cm4

Chipsee AIO-CM4-156 is an industrial All-in-One computer powered by a Raspberry Pi CM4 module and equipped with a 15.6-inch capacitive touchscreen display with 1920×1080 resolution. The new panel PC builds upon the earlier AIO-CM4-101 model with a 10.1-inch touchscreen display and besides the larger and higher resolution 15.6-inch Full HD display, it also adds support for an optional 250GB Sandisk NVMe SSD and a 2mm protective “armoplated” Glass. Since as far as I know, “armoplated” is not a word, they may refer to armored/toughened glass instead. AIO-CM4-156 specifications: SoM – Raspberry Pi CM4 with Broadcom BCM2711 quad-core Cortex-A72 processor at 1.5 GHz, up to 8GB RAM, up to 32GB eMMC flash Storage MicroSD card slot for boot (only used with CM4 Lite) M.2 NVMe socket for an optional 250GB SSD drive Display – 15.6-inch IPS LCD with 1920×1080 resolution, optional 10-point capacitive touchscreen, 250 cd/m2 brightness, 2mm protective armored glass […]

Posted on by Sponsored Post - Comments Off on 23.8-inch touch screen system with EDLA GMS for sports, healthcare, education, advertising, and home appliances (Sponsored)

23.8-inch touch screen system with EDLA GMS for sports, healthcare, education, advertising, and home appliances (Sponsored)

23.8-inch touch screen system arm VESA mount

DataMax DP03F touch screen system comes with a 23.8-inch Full HD touchscreen display with anti-bacterial plastics and healthcare-certified components and runs Android 11 on an hexa-core Arm processor, either Rockchip RK3399 Arm Cortex-A72/A53 SoC or Amlogic A311D Arm Cortex-A73/A53 processor. This type of touch screen system can be used as a medical bedside terminal, digital signage, conference terminal, treadmill terminal, smart PoS, industrial panel PC, robots, and more. It would typically be mounted on the device itself, or in the case of hospital settings a VESA-compatible flexible arm to provide the patient with easy access to entertainment and education, while doctors, nurses, or the patient him/herself can check out clinical records and vital signs. DataMax DP03F specifications: SoC (one or the other) Rockchip RK3399 hexa-core processor with 2x Cortex-A72 cores @ up to 1.8 GHz, 4x Cortex-A53 cores @ up to 1.4 GHz with Mali-T860 GPU Amlogic A311D hexa-core processor […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on 15.6-inch Panel PC supports Intel Comet Lake socketed processors

15.6-inch Panel PC supports Intel Comet Lake socketed processors

AAEON Panel PC dual Ethernet, serial, USB 3.2

AAEON OMNI-2155-CML is an industrial touch panel PC with a 15.6-inch display, and a choice of 10th generation Intel Core and Celeron Comet Lake processors, as well as various I/O features. The system comes with two SO-DIMM sockets for up to 64GB DDR4 RAM, M.2 and SATA storage, dual Gigabit Ethernet, two serial ports, four USB 3.2 ports, and support for a wide input voltage range. AAEON OMNI-2155-CML specifications: Supported socketed processors Intel Core i9-10900TE 10-core/20-thread processor @ 1.80 GHz / 4.50 GHz (Turbo) with 20 MB Smart Cache, Intel UHD Graphics 630 @ 350 MHz / 1.20 GHz; TDP: 35 W Intel Core i7-10700TE 8-core/16-thread processor @ 2.00 GHz / 4.40 GHz  with 16 MB Smart Cache, Intel UHD Graphics 630 @ 350 MHz / 1.15 GHz; TDP: 35W Intel Core i5-10500TE 6-core/12-thread processor @ 2.30 GHz / 3.70 GHz with 12 MB Smart Cache, Intel UHD Graphics 630 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on IP66 & IP69K-rated stainless steel fanless panel PC’s feature Kaby Lake processor

IP66 & IP69K-rated stainless steel fanless panel PC’s feature Kaby Lake processor

IP66 IP69K panel pc

Last year, we wrote about IP69K-Rated stainless steel panel PC’s made by ADLINK, powered by an Intel x7-E3950 quad-core Apollo Lake processor, equipped with a 15.6-inch to 23.9-inch display, and designed for special production environments including food, pharmaceutical, and chemical production. If you need an IP69K panel PC with a more powerful processor, Axiomtek has now introduced GOT815W-511 and GOT812W-511 15.6-inch and 12.1-inch stainless steel fanless touch panel computers powered by an Intel Core i5-7300U quad-core Kaby Lake processor, available with either IP69K/IP66 ingress protection rating. Axiomtek GOT815W-511 / GOT812W-511 specifications: SoC – Intel Core i5-7300U dual-core/quad-thread Kaby Lake processor @ 2.6 GHz / 3.5 GHz (Turbo) with Intel HD Graphics 620; 15W TDP System Memory – 1x 260-pin DDR4-2133 SO-DIMM for up to 16GB RAM Storage – 1x 2.5-inch SATA SSD or HDD (9.5 mm height max) LCD Panel GOT815W-511 – 15.6-inch TFT LCD with 1920 x 1080 pixels […]
