ops News - CNX Software - Embedded Systems News

August 15, 2022August 15, 2022 by Sponsored Post - Comments Off

OPS-compliant digital signage player features Amlogic S905X3 CPU (Sponsored)

DataMax DM29 is a digital signage player and mini PC compliant with the OPS (Open Pluggable Specification) standard and powered by an Amlogic S905X3 quad-core Cortex-A55 processor coupled with 4GB RAM and 32GB internal storage. The Android 9 system also features an HDMI 2.1 port capable of up to 4Kp60 video output, Gigabit Ethernet, dual-band WiFi, and 3G or 4G LTE cellular connectivity, as well as a pair of USB 3.0 ports. The system can be powered from an OPS-compliant display or via PoE. DataMax DM29 specifications: SoC – Amlogic S905X3 quad-core Arm Cortex-A55 processor @ up to 1.9 GHz with Arm Mali-G31 MP2 GPU supporting OpenGL ES 3.2, Vulkan 1.0, OpenCL 2.0 System Memory – 4GB dual-channel LPDDR4 or DDR3 Storage – 32GB eMMC flash, microSD card socket, M.2 SSD socket Video & audio output – HDMI 2.1 up to 1080p120 or 4Kp60 Video Decoding – 10-bit H.265, VP9, […]

January 17, 2018January 17, 2018 by Jean-Luc Aufranc (CNXSoft) - No Comments

ZidooLab OPS Android Digital Signage Players are Powered by Rockchip RK3368 or Realtek RTD1295 SoC

Zidoo is known for their Arm based Android TV boxes targeting the consumer market, but the company also runs ZidooLab for the B2B market, and especially digital signage application, which may explain why they release a digital signage SDK a while ago. The company can customize hardware and software for their customer’s needs, but what caught my intention is that they have Arm based digital signage players that comply with OPS (Open Pluggable Specification) that was first released by Intel in 2010, and defines electrical, mechanical and thermal specifications of OPS compliant devices which are meant to be plugged into compliant monitors. ZidooLab has currently two Android OPS hosts: A1 & A2 that share most of the same specifications, except for the processor, and some I/Os: SoC A1 – Rockchip RK3368 octa-core Cortex A53 processor up to 1.5 GHz, PowerVR G6110 GPU A2 – Realtek RTD1295 quad core Cortex A53 […]

March 29, 2017 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

VIA VTS-8589 OPS Board Powered by NXP i.MX 6 ARM Processor Complies with Intel’s OPS Digital Signage Specifications

Intel introduced the Open Pluggable Specifications (OPS) defining mechanical and electrical requirements for boards used in digital signage back in 2010. Since then there has been a few Intel OPS boards launched on the market, and the company introduced OPS+ specifications with support for simultaneous display and broadcast usages, 8K resolution displays, and the ability to drive three individual 4K resolution display outputs. VIA has now launched VTS-8589 OPS board compliant with the older specifications, and featuring NXP i.MX6 quad core ARM Cortex A9 processor combined with 2GB RAM, 8GB flash, and more. VIA VTS-8589 OPS has two version of the board with the following specifications: SoC VTS-8589-QP model – NXP i.MX 6QuadPlus quad ARM Cortex-A9 processor @ 1.0 GHz with Vivante GC2000+ GPU supporting OpenGL ES 3.0, OpenCL and OpenVG 1.1, 512KB embedded SRAM VTS-8589 model – NXP i.MX 6Quad quad ARM Cortex-A9 processor @ 1.0 GHz with Vivante GC2000 […]

January 22, 2013 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Norco BIS-6332A Freescale i.MX6 OPS Compliant Digital Signage Platform

Norco recently unveiled a BIS-6332A, a platform based on Freescale i.MX6 processor compliant with Intel’s Open Pluggable Specification (OPS) mainly to be used as a digital signage player, but also as a fanless Box PC, a media player, a point of sale and more. The open pluggable specification (OPS) defines mechanical and electrical characteristics so that you can easily replace a OPS compliant board or device with another compliant platform. Here are the specifications of the device: SoC – Freescale Cortex-A9 i.MX 6 series (Single-core/dual-core/ Quad Core CPUs) System Memory – Onboard 1GB/2GB DDR3 800MHz RAM Storage: 1xMicro SD 4GB/8GB iNAND flash 1x SATAII for 2.5″ HDD or SSD Video Output – 1x HDMI (front panel), 1x HDMI ( extended by OPS slot) and LVDS Connectivity: 10/100/1000Mbps LAN (Atheros AR8033) On-board USB WIFI 3G (optional) USB – 2x USB on front panel, 3x USB provided via OPS slot, one 2x5Pin USB […]

November 5, 2010November 5, 2010 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Digital Signage Standard: Open Pluggable Specification (OPS)

A while ago, we discussed about Popai Digital Signage Standards, mainly focused on software and client/server interoperability. Intel has just released a new standard for Digital Signage: Open Pluggable Specification (OPS). Here’s the description of the specification on Intel website. The Open Pluggable Specification (OPS) helps standardize the design and development of digital signage devices and pluggable media players. Intel created the OPS to address digital signage market fragmentation and simplify device installation, usage, maintenance and upgrades. The OPS enables digital signage manufacturers to deploy interchangeable systems faster and in higher volumes, while lowering costs for development and implementation. Installing digital signage equipment based on Intel® architecture helps you implement scalable digital signage applications that can network easily with other equipment. This simplifies interoperability and application upgrades designed to meet the digital signage requirements of individual customers, while helping to future-proof technology investments. You’ll need to fill a form to […]
