May 22, 2014May 22, 2014 by Jean-Luc Aufranc (CNXSoft) - 20 Comments

$15 Open Source Hardware VoCore Wi-Fi Module Runs OpenWRT (Crowdfunding)

There are already low cost Wi-Fi modules that can be used for the Internet of Things such as AsiaRF AWM002 and Hi-Link HLK-RM04. However, AsiaRF mainly caters to companies, and the Hi-Link module has a limited memory (16MB), which may or may not be an issue depending on your application. VoCore Wi-Fi module could prove to be an interesting option as it is the same $15 to $20 price range, runs OpenWRT with 32 MB RAM, will be open source hardware, and provides up to 20 GPIOs in a tiny (25x25mm) form factor. VoCore Wi-Fi module specifications: SoC – Ralink/Mediatek RT5350 MIPS processor @ 360MHz with dual band 802.11n Wi-Fi with data Rate up to 150Mbps System Memory – 32 MB RAM Storage – 8MB SPI Flash (for firmware) / 16 MB on limited edition Available Signals (Via through holes): 10/100M Ethernet USB UART, I2C, SPI I2S, PCM JTAG Over 20 […]

April 28, 2014May 1, 2014 by Jean-Luc Aufranc (CNXSoft) - 20 Comments

$15 AsiaRF AWM002 & AWM003 Wi-Fi Modules Run OpenWRT, Expose GPIOs

This week-end I explained how to build a web server that could be used for automation and other Internet of things applications for less than $15 by combining an Arduino Leonardo with ECN18J60 Ethernet module. The hardware itself is cheap, but it may not always be convenient, or cost effective, to wire your house or office with Ethernet cables. One solution is to use Wi-Fi modules such as TI CC3000 evaluation module, an Electric Imp module, or Ariettea G25 + Wi-Fi board, but these usually cost between $30 to $50 in single quantity. AsiaRF AWM002 and AWM003 are low cost 802.11n Wi-Fi modules with access to GPIOs that could be an interesting alternative as they cost $15 + shipping, and even below $10 in quantities. The only difference between the two is that AWM003 supports more RAM (64MB vs 32MB). Here are the specifications for these modules: SoC – Mediatek/Ralink […]

September 29, 2013 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

$27 TP-LINK TL-MR10U is an Hackable OpenWRT Wi-Fi Router with a Power Bank

TP-Link WR703N is a cheap 802.11 b/g/n router (you can now get it for about $20) that can easily be hacked to run openWRT and for example, act as an home automation gateway, printer server and more. But if you need a battery powered router for your application, TP-Link TL-MR10U, based on similar hardware as TL-703WR, should be a better match as it comes with a 2600 mAh battery, and costs just about $27 on DealExtreme. Here are the specifications of the device: CPU – Atheros AR9331 CPU @ 400Mhz System Memory – 32MB RAM Storage – 4 MB Flash Connectivity: 10/100 Mbit Ethernet port 802.11 b/g/n 150Mbps 3G support via external USB dongle USB – USB 2.0 port + micro-USB port for power Misc – Serial port access Dimensions – 91mm x 43mm x 25.85mm（L x W x H） The device comes with a microUSB cable and a user’s […]

July 31, 2013September 28, 2013 by Jean-Luc Aufranc (CNXSoft) - 18 Comments

Freescale i.MX6 Based Server Systems – Cornfed CONSERVER and Ventana Network Processing Boards

I usually spend most of my time writing about low cost hardware in this blog, but in this post, I’ll deal with higher-end and more expensive devices based on Freescale i.MX6 with Cornfed CONSERVER Server System and corresponding CONSERVER motherboard, as well as Ventana Network Processing Boards. Cornfed CONSERVER Conserver is a low power high-performance ARM processor server system based on Freescale i.MX6 with 4GB RAM, Gigabit Ethernet, and SATA. The hardware specifications are as follows: SoC – Freescale i.MX6Q Quad Core ARM Cortex A9 processor @ 1.2 GHz System Memory – 4 GB DDR3 RAM Storage – ?? GB NAND Flash + 1x SATA2 connector for HDD/SSD Connectivity – 1x Gb Ethernet port USB – 4x USB Host ports Video Output – 1x HDMI port Misc – RS-232 Serial port Power Supply – 35W Internal AC Power Supply Dimensions – Mini-ITX form factor The system is preloaded with Ubuntu, and […]

May 19, 2013May 19, 2013 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

$69 Linux Powered Arduino Yún Board is Designed for the Cloud

Massimo Banzi announced the Arduino Yún, the first of a family of Wi-Fi products combining Arduino with Linux, at the Maker Faire Bay Area. The company used the name Yún (云), meaning “cloud” in Chinese, as the purpose of this board to allow connection to web services directly from Arduino. Arduino Yun Specifications: MCU – Atmel ATMega32u4 @ 16 MHz (same as the one used in Leonardo board) with 2.5KB SRAM and 32KB flash SoC – Atheros AR9331 MIPS-based Wi-Fi SoC running Linino, Arduino’s own Linux distribution based on OpenWRT. It’s the same chipset as in TP-Link WR703N router. Storage – microSD card slot USB – micro USB connector + full USB host port Connectivity – Ethernet + Wi-Fi 14 digital input/output pins (of which 7 can be used as PWM outputs and 12 as analog inputs) Arduino Yún ATMega32u4 can be programmed as a standard Arduino board by plugging it […]

January 14, 2013January 14, 2013 by Jean-Luc Aufranc (CNXSoft) - 16 Comments

$14 Marstek MPR-N9 WiFi/3G Router with 2,400 mAh Battery

One of my readers (Onebir) brought Poray M3 mini Router to my attention a few days ago, as it just cost $17 at the time (now over $20) and OpenWRT developer Squonk seems very interested about it since it features microSD and SD card slots missing in TL-WR703N. However, the device only has 16 MB memory which makes it somewhat difficult to run OpenWRT, or at least some of its features. But today, I’m not going to talk about this. Mentions of Poray M3 router came in HAME MPR-A1 OpenWRT forum thread, and I discovered a new (to me) type of low cost, small form factor device: portable Wi-Fi/3G routers. Those devices are about the size of android mini-PC and contain the chips to handle Wi-Fi, USB host (for external 3G dongle), and comes with a built-in battery so that you can use them anywhere (beach, mountain, car…), as long […]

July 19, 2012July 19, 2012 by Jean-Luc Aufranc (CNXSoft) - 24 Comments

TP-Link WR703N – $23 Hackable openWRT Wi-Fi 802.11N Router

TP-Link WR703N is a tiny 802.11N 150 Mbps Wi-Fi router smaller than a credit card (5.7 x 5.7 cm) and 1.8 cm thick based on Atheros AR7240 processor with 4 MB flash and 32 MB RAM. It costs just above $20 US and can be hacked with openWRT. It features one USB host connector that allows you to connect USB devices (USB flash drive, printer…) to it. TL-WR703N Specifications: Atheros AR7240 CPU @ 400Mhz (MIPS24k core) Atheros AR9331 Chipset (integrated wireless) 10/100 Mbit Ethernet port 802.11 b/g/n 150Mbps 3G support via external USB dongle 4 MB flash memory 32 MB RAM USB 2.0 port micro-USB port for power Dimension – 5.7 x 5.7 x 1.8 cm All you need is a USB to TLL board to access the serial console, open the box to access the serial pins (TP_IN and TP_OUT) and follow the instructions on openWRT website to convert […]
