onlogic News - CNX Software - Embedded Systems News

June 15, 2023 by Jean-Luc Aufranc (CNXSoft) - No Comments

Helix 511 fanless industrial embedded computer features Intel Celeron 7305 up to Core i7-12800HL CPU

OnLogic Helix 511 edge computer features an Intel Alder Lake processor from Celeron 7305 up to a Core i7-12800HL CPU with up to 64GB DDR5, M.2 SATA or NVMe storage and designed for use in manufacturing, automation, energy management, and other edge and IoT applications. The fanless industrial embedded computer also comes with two 2.5GbE ports, support up to four independent displays via DisplayPort and Thunderbolt 4 connectors, is equipped with six USB 3.2 ports, as well as optional digital I/O or serial ports for expansion. Helix 511 specifications: Alder Lake SoC Intel Celeron 7305 penta-core processor @ 3.10GHz / 4.20GHz (Turbo) with 48EU Intel UHD graphics – PBP: 15W, up to 55W MTP Intel Core i3-12300HL octa-core/12-thread processor @ 2.00GHz / 3.30GHz / 4.40GHz (Turbo) with Intel UHD graphics – PBP: 45W, up to 65W MTP Intel Core i5-12600HL 12-core/16-thread processor @ 2.70GHz / 3.30GHz / 4.50GHz (Turbo) with […]

March 21, 2023 by Jean-Luc Aufranc (CNXSoft) - No Comments

OnLogic Helix 401 – A compact fanless industrial computer powered by an Alder Lake Embedded processor

OnLogic Helix 401 is a fanless industrial computer with a compact design powered by a choice of Alder Lake Embedded processors from Celeron 7305E to Core i7-1270PE designed for edge computing, Industry 4.0, Internet of Things (IoT), and more. The computer supports up to 64GB DDR5 memory, SATA or NVMe storage via two M.2 sockets, and offers up to four video outputs via DisplayPort and USB4 ports, dual Gigabit Ethernet, optional WiFi and/or 4G or 5G cellular connectivity, COM and CAN bus ports, and Digital Input/Output (DIO) connector. OnLogic Helix 401 (HX401) specifications: Alder Lake SoC Intel Celeron 7305E penta-core processor @ 3.10GHz / 4.20GHz (Turbo) with 48EU Intel UHD graphics – PBP: 15W, up o 55W MTP Intel Core i3-1220PE 8-core/12-thread processor @ 3.10GHz / 4.20GHz (Turbo) with 48EU Intel UHD graphics – PBP: 28W, up to 64W MTP Intel Core i5-1250PE 12-core/16-thread processor @ 3.20GHz / 4.40GHz (Turbo) […]

March 15, 2022March 17, 2022 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

OnLogic announces Factor 201 Raspberry Pi CM4 industrial PC, Factor 202 controller coming soon

OnLogic has announced the launch of the Factor 201, a compact fanless industrial PC based on Raspberry Pi CM4 (Compute Module 4) for Edge IoT applications, and is working on the Factor 202 industrial controller with onboard digital and analog I/Os (DIO & AIO), as well as a capacitive touchscreen. OnLogic Factor 201 Specifications: SoM – Raspberry Pi CM4 with Broadcom BCM2711 quad-core Arm Cortex-A72 processor @ up to 1.5 GHz, up to 8GB LPDDR4 RAM, up to 32GB eMMC flash Additional storage – Optional M.2 SATA SSD (See Expansion section) Video Output – HDMI port up to 4Kp60 Networking 2x Gigabit Ethernet LAN (Optional PoE PD Input) via Realtek RTL8153 controller Optional WiFi/Bluetooth module on Raspberry Pi CM4 module + 3x antenna holes Optional 4G LTE wireless module via M.2 socket USB – 1x USB 3.2 Gen 1 port, 2x USB 2.0 ports, 1x USB-C management port Serial – […]

January 14, 2022 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

OnLogic unveils Karbon 800 Series Alder Lake-S embedded computers

OnLogic Karbon 800 Alder Lake-S embedded computer

We’ve already seen the newly announced Intel Alder Lake-S desktop IoT processors in some COM Express and COM HPC modules, and quickly mentioned Vecow ECX-3000 rugged computer, and now, OnLogic has just announced the Karbon 800 Series, a family of Alder Lake-S embedded computers. There will be four Karbon 800 models at launch, equipped with up to an Intel Core i9 16-core processor, 64 GB of DDR4 ECC or non-ECC memory, as well as single and dual PCIe Gen 4 slots, and optional “ModBay” hot-swappable bays to add connectivity and storage option up to a six 2.5-inch SSD RAID array or 14 Ethernet ports. All four Karbon 800 embedded computer supports the same processor and memory options, and mostly differ in their storage and expansion options: Karbon 801 Storage – Support for NVME Storage Expansion – 4G Cellular, Wi-Fi, Bluetooth Karbon 802 Storage – 2x 2.5-inch SSD with optional Hot […]

March 16, 2021March 16, 2021 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

Onlogic industrial Raspberry Pi CM4 based mini PC to offer dual GbE, USB 3.1, M.2 SATA socket

Onlogic Raspberry-Pi CM4 mini PC Dual GbE

Yesterday, we covered two Raspberry Pi CM4 carrier boards with dual Ethernet ports, including one from Seeed Studio with dual Gigabit Ethernet and USB 3.1 ports, and another from MCUZone with Gigabit + Fast Ethernet ports, USB 2.0 ports, plus a 4G LTE modem. But Onlogic will soon add another option with a complete Raspberry Pi CM4 based industrial mini PC with dual Gigabit Ethernet, teased as “One Tough Pi”, as well as USB 3.2/2.0 ports, M.2 SATA storage, and more. Onlogic “One Tough Pi” mini PC preliminary specifications: SoM – Raspberry Pi CM4 module with up to 8 GB LPDDR4 memory, 32 GB eMMC flash storage Storage – M.2 2280 SATA SSD support Video & audio output – 1x Micro HDMI port up to 4Kp60 Connectivity – 2x Gigabit Ethernet ports USB – 3x USB ports include 1x USB 3.2 Gen 1 port, and 2x USB 2.0 ports; 1x […]

January 27, 2021September 22, 2022 by Jean-Luc Aufranc (CNXSoft) - No Comments

OnLogic Elkhart Lake fanless mini PC’s are made for IIoT applications

Onlogic Karbon 410 Elkhart-Lake fanless rugged mini pc

Intel Atom x6000E Series, Celeron and Pentium Elkhart Lake IoT Edge processors were introduced in September 2020, and we covered several Elkhart Lake modules and SBC’s. We’ve seen fewer full systems such as the Atom x6425RE based Vecow SPC-6000 Elkhart Lake mini PC for embedded & IoT applications. But OnLogic is more offering four more choices with Helix 300 and Karbon K400 Series of rugged fanless mini PCs, all equipped with Atom, Celeron, or Pentium Elkhart Lake processors, and designed for industrial IoT (IIoT) or Industry 4.0 applications Helix 300 Series Specifications The Helix 300 family is comprised of two models with Helix 310 and Helix 330 share most of the same specifications: SoC – Intel Celeron N6211 dual-core processor or Pentium J6425 quad-core processor System Memory – Up to 32 GB DDR4 RAM Storage – M.2 Storage Video Output – 3x DisplayPort for triple independent display setups Audio – […]

August 19, 2020 by Jean-Luc Aufranc (CNXSoft) - No Comments

OnLogic Introduces Fanless Apollo Lake Thin Clients Running IGEL Edge OS

OnLogic IGL200 Thin Client with IGEL Edge OS

OnLogic has launched its first two offerings as part of the new IGEL Ready program with IGL200 and IGL300 fanless thin clients powered by various Intel Apollo Lake processors. IGEL Edge OS enables the devices to be used for distributed computing, virtualization, and thin clients, and OnLogic thin clients target users in the manufacturing, energy, automation, and industrial Internet of Things (IIoT) sectors. OnLogic IGL200 Specifications: SoC – Intel Celeron N3350 dual-core Apollo Lake processor @ 1.1 GHz / 2.4 Ghz (Burst freq.) with Intel HD Graphics 500 System Memory – Up to 4GB LPDDR4-2133 Storage – 32GB eMMC flash, MicroSD Card slot, mSATA slot Video Output – 2x Mini DisplayPort outputs with dual independent display support Audio – 1x audio Jack with Line-out and Mic-in Networking 2x Gigabit Ethernet ports via Realtek RTL8111G controller 4x antenna holes for optional cellular modem or/and WiFi USB – 1x USB 2.0 port, […]

February 27, 2020 by Stephen Vicinanza - 1 Comment

OnLogic AMD Ryzen Embedded Mini PCs Launched for $565 and Up

OnLogic Announces Shipping of 2 New Mini-PCs OnLogic has just announced the availability of two AMD Ryzen Embedded powered mini PCs designed for industrial uses. The ML100G-40 is a fanless industrial mini PC, while the MC510-40 is an actively cooled mini PC Overview The ML100-40 has the option of having either a Ryzen Embedded R1505G or a V1605B, and comes with 3 video output ports and dual LAN ports. The system is equipped with 4 GB RAM, 32 GB M.2 SSD by default, and offers a wide range of I/O ports on the rear panel. The MC510-40 is a low-profile fanned industrial Mini-ITX carrying an AMD Ryzen Embedded V1605B processor, with Radeon Vega 8 GPU. The actively cooled Mini-PC has 4 ports for independent displays, M.2 storage, and max 32 GB memory. ML100-40 Specifications and Base Price Ryzen Embedded R1505G $565.00 Ryzen Embedded V1605B $685.00 The ML100-40 can be fitted […]
