odroid News - CNX Software - Embedded Systems News

July 14, 2024July 14, 2024 by Jean-Luc Aufranc (CNXSoft) - 10 Comments

ODROID-H3/H4 x86 SBCs get M.2 PCIe Gen 3 x4 expansion cards with two or four M.2 sockets

ODROID-H3 and ODROID-H4 x86 single board computers have gotten two affordable M.2 expansion cards with the M.2 2×2 card adding two PCIe Gen 3 x2 slots and the M.2 4×1 adding four PCIe Gen 3 x1 slots (ODROID-H4 only) to the Intel SBCs. We’ve seen plenty of PCIe HAT+ boards for the Raspberry Pi 5 since the launch of the Arm SBC last year, but it’s limited by its PCIe Gen2/Gen3 x1 interfaces, and Hardkernel now provides two new M.2 cards leveraging the M.2 PCIe Gen3 x4 socket of the ODROID-H3/H4 family allowing users to add up to four M.2 PCIe modules for storage, wired or wireless connectivity, and/or AI acceleration. M.2 2×2 card for ODROID-H3 and H4 series The M.2 2×2 card also named “M.2 – NVME” adds two M.2 Key-M PCIe sockets for 2280 size modules with each having a PCIe 3.0 x2 interface supporting up to 16GT/s. […]

May 11, 2024May 26, 2024 by Jean-Luc Aufranc (CNXSoft) - 12 Comments

ODROID-H4+ kit review – Part 1: Unboxing, H4 Type 3 case assembly, and first boot

I’ve just received a kit comprised of an ODROID-H4+ SBC along with a Type 3 enclosure taking up to four 2.5-inch SATA drives and related accessories for review. I’ll start with an unboxing, followed by an assembly guide, and a quick first boot in the first part of the review, before testing performance, features such as IBECC memory, power consumption, and more in the second part of the review. ODROID-H4+ kit unboxing The package I received included small packages for the “H4 Type 3” enclosure and the ODROID-H4 PLUS SBC, a 15V/4A (60W) power supply with US plug adapter, a large fan with screws, as well as four sets of SATA data and power cables. We’ve already provided the ODROID-H4, H4+, and H4 Ultra specifications in the announcement post, but let’s have another quick look at the Intel Processor N97 fanless SBC. The rear panel comes with a DC jack, […]

November 8, 2022November 8, 2022 by Jean-Luc Aufranc (CNXSoft) - 48 Comments

ODROID-N2L is a smaller, low-cost variant of ODROID-N2+ Arm SBC

ODROID-N2L SBC is a smaller and cheaper version of the ODROID-N2+ single board computer powered by an Amlogic S922X hexa-core Cortex-A73/A53 processor and offered with 2GB or 4GB single-chip LPDDR4X memory. While the ODROID-N2+ is the most popular board from Hardkernel, it’s also fairly larger than most hobbyist SBCs on the market, and following requests from customers, the company designed the ODROID-N2L with a compact form factor that is smaller than Raspberry Pi Model B SBCs and sold at a lower price at the cost of missing some of the features of its big brother. ODROID-N2L specifications: SoC – Amlogic S922X hexa-core big.LITTLE processor with 4x Arm Cortex A73 cores @ up to 2,208/2,400 MHz, 2x Arm Cortex A53 cores @ 1,908/2,016GHz, Arm Mali-G52 GPU @ 846MHz; 12nm manufacturing process System Memory – 2GB or 4GB LPDDR4 @ 3216 MT/s Storage – eMMC flash module socket up to 128GB, microSD […]

April 30, 2022April 30, 2022 by Jean-Luc Aufranc (CNXSoft) - 8 Comments

DIY SBC cases and SBC Case Builder tool based on OpenSCAD

Since you can’t always rely on single board computer (SBC) vendors to provide a case to match your needs, some went the DIY route. Willy Tarreau designed some laser-cut enclosures with Inkscape for various SBCs, while hominoids went a step further by developing the “SBC Case Builder” tool to automatically generate various types of 3D printable enclosures using OpenSCAD. Willy designed five similar enclosures for Khadas VIM3/VIM3L, FriendlyELEC NanoPi Fire3, SolidRun Clearfog Base networking SBC, Libre Computer AML-S805X-AC (aka “La Frite”), and AAEON UP Board. All cases are available in Inkscape SVG format, and Willy accepts contributions for other boards. You’ll need a laser engraver or CNC router to cut out those enclosures. Hominoids’ SBC Case Builder project attempt to automatize enclosure generation for SBCs using SBC Model Framework written in OpenSCAD. Work has focused on ODROID boards so far, but it should work for other vendors too. The parameters […]

April 14, 2022 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

ameriDroid introduces $20 aluminum case for ODROID-N2+ SBC

You may know ameriDroid as a reseller of single board computers and accessories, but the US company has now designed and manufactured its first accessory with an aluminum case for ODROID-N2+ SBC. ameriDroid says the design of their enclosure is based on the metallic blue case found in the Home Assistant Blue gateway also powered by ODROID-N2+ board, and everything was 100% designed and manufactured by ameriDroid in the United States, specifically in Kentucky and California for the R&D, while the factory is located in Ohio. The enclosure has mostly been designed for industrial application, think of a factory floor for instance, so it may not be the prettiest. The company even explains that it is made of unpainted, unfinished aluminum with potentially some minor surface marks from the manufacturing process, but that it could be polished or painted for a better finish. It ships as a kit with an […]

November 8, 2021November 8, 2021 by Jean-Luc Aufranc (CNXSoft) - 13 Comments

ODROID-N2+ review with Ubuntu 21.10 using Wayland and Panfrost

ODROID-N2+ was launched in July 2020, but I only got the Amlogic S922X Rev C SBC recently with Hardkernel wanting me to test their latest Ubuntu 21.10 image with the Panfrost open-source GPU driver. ODROID-N2+ Kit Unboxing Let’s start by checking out the kit I received from the Korean SBC manufacturer. The package includes ODROID-N2+ single board computer fitted with a 32GB eMMC flash module, a 12V/2A power supply with an EU plug adapter, an 80mm fan kit, and a USB 3.0 to eMMC reader. ODROID-N2+ is now only available with 4GB RAM, as the old ODROID-N2 with 2GB was deprecated, and we get four USB 3.0 ports, HDMI 2.0 video output, Gigabit Ethernet networking, and a 40-pin GPIO header with the board cooled by a larger heatsink attached to the bottom of the board. Fan installation, first boot, and system information As we’ll see below the fan is not […]

October 27, 2021 by Jean-Luc Aufranc (CNXSoft) - 15 Comments

ODROID-GO Advance Black Edition is selling for $29.50 (Promo)

Hardkernel is having a “Black Friday” sale for the ODROID-Go Advance Black Edition portable game console that is now selling for $29.50, or exactly half of the normal price ($59.00), with either the transparent or black enclosure. As a reminder, the OGA Black Edition is a Linux console powered by a Rockchip RK3326 quad-core Arm Cortex-A35 processor coupled with 1GB RAM and a 3.5-inch display. This model builds on the earlier ODROID-Go Advance model by adding a WiFi & Bluetooth module, a USB-C port for charging, as well as some extra buttons. ODROID-Go Advance Black Edition specifications: SoC – Rockchip RK3326 quad-core Arm Cortex-A35 processor @ 1.3GHz with Mali-G31 MP2 GPU System Memory – 1GB DDR3L @ 786Mhz, 32 Bits bus width Storage – 16MB SPI Flash for bootloader, Micro SD Card slot (UHS-1 Capable interface) Display – 3.5″ 320×480 TFT LCD (Wide-viewing angle display, MIPI-DSI interface) Audio – 3.5mm […]

September 30, 2021 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

ODROID-N2+ SBC gets Ubuntu 21.10, Chromium OS with Panfrost open-source GPU driver

ODROID-N2+ running Ubuntu 21.10 with Panfrost

Panfrost open-source driver for Arm Mali Bifrost and Midgard GPUs has come a long way, and Hardkernel’s ODROID-N2+ board now supports Ubuntu 21.10 and Chromium OS with 3D graphics acceleration through the Panfrost driver. As a reminder, ODROID-N2+ is a single board computer powered by an Amlogic S922X Rev.C processor clocked at 2.4GHz with an Arm Mali-G52 GPU, with up to 4GB RAM, and which comes with HDMI 2.0, Gigabit Ethernet, four USB 3.0 ports, plus a GPIO header. ODROID-N2+ with Ubuntu 21.10 + Panfrost Ubuntu 21.10 Impish Indiri is supposed to be released on October 14, 2021 together with Gnome 40, but Hardkernel released a development version as early as August, with Linux 5.14 and Panfrost GPU acceleration as you can see from the screenshot above. The Ubuntu 21.10 image for ODROID-N2+ and the earlier ODROID-N2 SBC cannot be found in the Wiki just yet, but should be there […]
