Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on Aller Artix-7 FPGA Board with M.2 Interface Fits into a Laptop

Aller Artix-7 FPGA Board with M.2 Interface Fits into a Laptop

Aller FPGA board

A few days ago, we wrote about Nitefury M.2 card equipped with a Xilinx Artix-7 FPGA, and which you can connect to any laptop, board, a computer with a spare M.2 socket. It turns out Numato Lab has done something similar with the Aller board, specifically designed for development and integration of FPGA based accelerated features into other larger designs, and provided in a standard 2280 M.2 form factor M-key slot. Aller FPGA M.2 card key features & specifications: FPGA- Xilinx Artix-7 FPGA (XC7A100T-1FGG484C) with 101,440 Logic cells, ~126K Flip-flops, ~600KiB Block RAM, and 240 DSP slices System Memory – 2Gbit DDR3 (MT41J128M16JT-125:KTR) Storage – On-board 1Gb QSPI flash memory for FPGA configuration Host Interface – 4 lane PCIe Gen1 (2.5GT/s) via M.2 Connector Interface, M-Key Debugging – JTAG header for programming and debugging Security – 1x Trusted Platform Module (AT97SC3205) Misc – 100 MHZ CMOS oscillator, 1x RGB LED […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on Numato Opsis is an Open Source Hardware FPGA Board with 6 Video Inputs and Outputs (Crowdfunding)

Numato Opsis is an Open Source Hardware FPGA Board with 6 Video Inputs and Outputs (Crowdfunding)

Numato Lab is a Bangalore based company specializing in MCU and FPGA boards such as the low cost Mimas V2 Spartan 6 board, and their latest board is also based on a Spartan 6 FPGA, but a more powerful part with LX45T FPGA, and targets video applications with two HDMI inputs, two HDMI outputs, one DisplayPort output, and one DisplayPort input, among other interfaces. Instead of simply listing specifications of Numato Opsis, I’ll reproduce a table – drawn by Numato – showing Opsis features and specifications against some other FPGA video platforms. Opsis miniSpartan6+ Mixxeo Atlys Nexys Anvyl CVK 2.0 AVDB Make Numato ScarabHardware M‑Labs Digilent Digilent Digilent TED OmniTek License Open Open Open Closed Closed Closed Closed Closed Cost USD $349 USD $105 no stock USD $419 USD $499 USD $539 USD $2,995 USD $999 FPGA Fab Xilinx Xilinx Xilinx Xilinx Xilinx Xilinx Xilinx Altera Family Spartan‑6 Spartan‑6 Spartan‑6 Spartan‑6 Artix‑7 Spartan‑6 Spartan‑6 Cyclone V Part LX45T […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on $50 Mimas V2 Spartan 6 FPGA Development Board Comes with a VGA Port, 64MB RAM

$50 Mimas V2 Spartan 6 FPGA Development Board Comes with a VGA Port, 64MB RAM

Just last week, I wrote about miniSpartan3, an FPGA board powered by Xilinx Spartan 3A. It costs as low as $25, features an HDMI output port, but lacks RAM. Numato Lab’s Mimas V2 is another low cost FPGA board with a more powerful Spartan 6 FPGA, 512 Mb LPDDR memory, and instead of HDMI output, a VGA port has been included on the board. The board can be used for prototype development, signal processing, learning digital electronics and as an educational tool for schools and universities. Technical specifications: FPGA – Xilinx Spartan XC6SLX9 in CSG324 package System Memory – 512Mb LPDDR @ 166 MHz (MT46H32M16LF/W949D6CBHX6E) Storage – 16 Mb SPI flash memory (M25P16) + micro SD card slot Video Output – VGA connector Audio – Stereo jack USB – 1x mini USB 2.0 port for on-board flash programming Expansion Headers – Four 6×2 header with access to 32 I/O pins, […]
