March 17, 2024March 17, 2024 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

7-inch Raspberry Pi CM4-based industrial HMI offers gigabit Ethernet, RS485 Modbus, digital and analog inputs

NORVI RPI-HMI is an industrial controller with a 7-inch touchscreen screen display powered by a Raspberry Pi CM4 and equipped with a range of interfaces including a gigabit Ethernet RJ45 port, a few USB ports, and several terminal blocks for RS485 (Modbus), digital and analog input, transistor outputs, and 24V DC power input. The new Raspberry Pi CM4-based HMI announcement follows the NORVI ESP32-HMI controller that was launched last December with an ESP32-S3 wireless microcontroller and a 5-inch LCD display with resistive touch. The NORVI RPI-HMI builds on that with a much faster Arm processor, a larger display with a capacitive touchscreen, gigabit Ethernet, and a wider range of I/Os that makes it suitable for various industrial HMI and PLC applications. NORVI RPI-HMI Industrial Controller specifications: SoM – Raspberry Pi CM4 SoC – Broadcom BCM2711 quad-core Cortex-A72 processor with VideoCore GPU System Memory – 1GB, 2GB, 4GB or 8GB LPDDR4-3200 […]

January 26, 2024January 26, 2024 by Jean-Luc Aufranc (CNXSoft) - 10 Comments

Entry-level Industrial Shields ESP32 PLC 14 sells for 100 Euros

Boot & Work Corp has just introduced an entry-level PLC based on ESP32 wireless microcontroller with the “Industrial Shields ESP32 PLC 14” that comes with seven inputs and five outputs, as well as I2C, RS485, Ethernet, WiFi, and Bluetooth communication interfaces. We first covered “Industrial Shields” automation devices in 2017 when the company introduced panel PCs based on Banana Pi, Raspberry Pi, and Hummingboard (NXP i.MX 6) SBCs, as well as a few Arduino and Raspberry Pi PLCs. Boot & Work Corp then launched a Raspberry Pi 4-based PLC in 2021, and now the company has introduced the ESP32 PLC 14 part of a larger family of PLC devices as we’ll see further below. ESP32 PLC 14 specifications: Wireless module – ESP-WROOM-32U with ESP32 dual-core wireless microcontroller @ 240 MHz with 4MB SRAM, 4MB flash, 2MB PSRAM I/Os through terminal blocks 4x Digital Outputs 12/24 V DC (can also act […]

November 22, 2023 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

Theengs Bridge BLE to MQTT gateway supports Home Assistant, OpenHAB, Jeedom, NodeRed, and more

The Theengs Bridge is a new WiFi & Ethernet BLE to MQTT gateway running the open-source OpenMQTTGateway firmware, compatible with a range of sensors, and supporting Home Assistant, OpenHAB, Jeedom, NodeRed, and other MQTT-compatible systems. It follows the Theengs Plug smart socket introduced at the beginning of the board with many of the same features (minus the socket part…) but adds Ethernet and an external antenna for improved range, and improves modularity with a Grove I2C connector and mounting holes for a LoRa-E5-based Grove module and a prototyping area where you can solder your own circuitry with DIP components. Theengs Bridge specifications: Wireless module MCU – ESP32 microcontroller with WiFi and Bluetooth Storage – 8MB flash PCB antenna and u.FL antenna connector Connectivity 10/100M Ethernet RJ45 port 2.4 GHz WiFi 4 and Bluetooth LE with 6dBi 50Ohm external antenna Optional LoRa module via Grove I2C connector MQTT protocol Expansion – […]

November 14, 2023November 13, 2023 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

Linux-based DIN Rail smart controller works with Zigbee, Z-Wave, KNX, and Ajax Systems security solutions

CONNECT Y1 Smart Controller in a DIN Rail gateway running Ubuntu Linux and acting as the main control of YoctoCONNECT’s Smart Home/Smart Building solution with YoctoBus (RS485) and Ethernet interfaces, support for expansion blocks, and third-party integration with Zigbee, Z-Wave, KNX, and Ajax Systems security and smart home solutions. The Y1 Smart Controller handles automation algorithms and RS485, Ethernet, and USB communication for automated control systems for lighting, power distribution equipment, ventilation systems, climate control, and other electrical loads in various sectors such as Industry 4.0, Smart Homes, and Smart Cities. CONNECT Y1 Smart Controller specifications: SoC – Quad-core processor @ 1.2 to 2.4 GHz System Memory – 512MB, 1GB, or 2GB DDR3 RAM Storage – 16GB or 32 GB eMMC flash Audio – 3.5mm audio output jack; AirPlay support Connectivity YoctoBUS (RS485) interface via 3-pole terminal block 10/100M Ethernet RJ45 port USB 2.0 interface for Z-Wave or Zigbee Ajax […]

August 20, 2023August 20, 2023 by Jean-Luc Aufranc (CNXSoft) - No Comments

Setting up a private LoRaWAN network with WisGate Connect gateway

RAKwireless Wisgate Connect Gateway Review with Link.ONE devit

In this guide, we’ll explain how to set up a private LoRaWAN network using the Raspberry Pi CM4-based RAKwireless’ WisGate Connect gateway and Docker or Portainer to install NodeRED, InfluxDB, Grafana, and other packages required to configure our gateway. The WisGate Connect is quite a versatile gateway with Gigabit and 2.5Gbps Ethernet plus several optional wireless connectivity options such as LoRaWAN, 4G LTE, 5G, WiFi 6, Zigbee, WiFi HaLoW, and more that can be added through Mini PCIe or M.2 sockets, expansion through WisBlock IO connectors and a 40-pin Raspberry Pi HAT connector. We’ll start by looking at the gateway features in detail, but if you already know all that, you can jump to the private LoRaWAN network configuration section. WisGate Connect unboxing, specifications, and teardown RAKwireless sent us a model with a Raspberry Pi CM4 equipped with 4 GB of RAM and 32 GB of eMMC memory, GPS and […]

April 12, 2023April 11, 2023 by Paisit Wongsongsarn - 8 Comments

SONOFF iHost Review – A future-proof Smart Home Hub for local control

ITEAD has sent us a Sonoff iHost Smart Home Hub for review, and this device seems to be what many SONOFF fans have been waiting for, especially in terms of local control. meaning it can work without an Internet connection. SONOFF is known for its durable devices and good interoperability, but they are still catching up with other companies in terms of local control. Finally, the iHost Smart Home Hub fills the gap. In addition to local control, it also comes with privacy features as data stay local. SONOFF plans to expand its ecosystem by including devices from other brands compliant with standards such as Zigbee 3.0. Furthermore, the iHost Smart Home Hub is more like a platform than just a product, as it has add-ons to add more capability over time. In the future, it can be expanded to support the new “Matter” standard, similar to Home Assistant. The […]

March 9, 2023 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

SONOFF iHost Smart Home Hub enables local control of SONOFF, Tasmota, Matter home automation devices

SONOFF iHost is a Smart Home Hub that enables local control of SONOFF smart switches, lightbulbs, Zigbee sensors, and so on without having to require a connection to the cloud (e.g. eWelink). Future software upgrades will also add more devices such as the ones flashed with Tasmota firmware and any device compatible with the Matter IoT protocol. The gateway is based on either a Rockchip RV1109 SoC with 2GB RAM or a Rockchip RV1126 with 4GB RAM and offers 10/100M Ethernet, WiFi, Bluetooth LE, and Zigbee 3.0 connectivity, as well as a USB 2.0 port to allow for more connectivity. SONFF iHost Smart Home Hub specifications: SoC and Memory Rockchip RV1109 dual-core Arm Cortex-A7 @ 1.5 GHz with RISC-V MCU @ 400 MHz, 2D graphics engine, 1.2 TOPS NPU, 5MP H.264 and H.265 hardware video decoder and encoder, and 2GB DDR4 Rockchip RV1126 quad-core Arm Cortex-A7 @ 1.5 GHz with […]

January 26, 2023 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

ESP32 OpenMQTTGateway smart plug acts as an BLE MQTT gateway and a power meter

The Theengs Plug ESP32 smart plug runs OpenMQTTGateway firmware to serve as a BLE MQTT gateway and power meter compatible with Home Assistant, Homebridge, OpenHAB, DomoticZ, FHEM, Jeedom, NodeRed, AWS, and any MQTT-compatible IoT or Smart Home system. While the Matter standard should improve interoperability between Smart Home frameworks over time, there are still millions of devices already produced that are not Matter compatible, and the Theengs Plug aims to at least partially address this issue by helping users reduce the number of hubs required and have only one that supports different ecosystems. Theengs Plug hardware specifications: Microcontroller – ESP32 dual-core wireless MCU with 2.4 GHz WiFi and Bluetooth LE connectivity Network Protocol – MQTT Power Supply – 100-120VAC, 60Hz, up to 15A Dimensions – 103 x 61 x 34.6mm Temperature Range – Operating: 0ºC ~ 40ºC; storage: -10°C ~ 50°C Humidity – 0%～95% (no condensation) Certification – UL Some […]
