Posted on by Jean-Luc Aufranc (CNXSoft) - 11 Comments on iWave Systems Introduces RainboW-G16M µMXM SoM Powered by Freescale Vybrid ARM Cortex A5 / M4 SoC

iWave Systems Introduces RainboW-G16M µMXM SoM Powered by Freescale Vybrid ARM Cortex A5 / M4 SoC

iWave Systems has unveiled new microMXM system-on-modules powered by Freescale Vybrid dual core ARM Cortex-A5 @ 500Mhz and Cortex-M4 @ 167 Mhz SoC. Rainbow-G16M modules target applications that can leverage the Cortex M4 MCU for real-time tasks, and the Cortex A5 core for application processing such as industrial process control & kiosks , smart grid, medical / healthcare devices, smart connected devices, and battery operated handheld devices. Here are the module specifications: SoC – Vybrid VF6x Series Controller with ARM Cortex A5 core @ 500Mhz, and Cortex M4 core @ 167 MHz System Memory – 256 MB DDR3 (Expandable upto 1GB) Storage 256MB NAND Flash (Expandable up to 2GB) QSPI Flash (Optional) EEPROM (Optional) On Board peripherals support: On module 10/100 Ethernet PHY JTAG Header for processor (Optional) Open SDA Header (Optional) DIP Switch for boot settings (Optional) 314-pin MXM PCB Edge Connector Interfaces: 10/100 Ethernet PHY interface 2nd RMII […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on EnSilica eSi-ZM1 System-on-Module Features Xilinx Zynq XC7Z020 SoC

EnSilica eSi-ZM1 System-on-Module Features Xilinx Zynq XC7Z020 SoC

EnSilica has introduced the eSi-ZM1 SoM powered by Zynq ZC7Z020 SoC featuring 2 ARM Cortex A9 core, and an Artix-7 FPGA with 85K logic cells. The module also comes with 1GB RAM, 1GB NAND flash, and 16MB QSPI Boot Flash. ZC7Z020 SoC is notably used in ZedBoard development board, so if you have developed an application around this board, and want to commercialize it, using eSi-ZM1 module with your own custom baseboard could be an option. eSi-ZM1 system-on-module specifications: SoC – Xilinx Zynq XC7Z020 dual-core Cortex A9 processor @ 666 MHz, 85 K logic cells, 560 KB block RAM, and 220 DSP Slices. CLG484 package type System Memory – 1 GB, 1.35 V, 32-bit wide DDR3 SDRAM @ 533 MHz Storage: 1 GB, 1.8 V, 8-bit wide NAND FLASH 16 MB QSPI flash 1 or 2 Kb I2C EEPROM (and not 1MB as mentioned in the block diagram ) uSD card […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Congatec Reference Board for Video Wall Systems Powered by AMD Embedded R-Series APU

Congatec Reference Board for Video Wall Systems Powered by AMD Embedded R-Series APU

congatec AG has introduced a new reference board for video wall system design. This reference design is based on a baseboard, an AMD Embedded R Series APU COM Express CPU module (conga-TFS) & an optional AMD Radeon E6760 GPU  MXM module, and can support up to 9 independent displays. The video wall baseboard includes a wide range of ports and features for embedded applications such as : Video Output – VGA, 18/24Bit single/dual channel LVDS, 3x DisplayPort 1.2, 1x HDMI 1.4 and 2x single-link DVI (All ports are available when both the CPU and MXM graphics modules are used) Ethernet – 2x Gbit Ethernet SATA – 4x SATA (for 2.5″ SATA or SSD) USB – 4x USB 3.0 and 4x USB 2.0 PEG Port 2.0 7x PCI Express 2.0 x1 lanes RF4CE (ZigBee) receiver enabling remote control 19V power supply for standard notebooks Developers can optionally integrate an additional graphics […]
