music News - CNX Software - Embedded Systems News

October 28, 2024October 28, 2024 by Sayantan Nandy - No Comments

Datanoise PicoADK v2 music synthesizer is a Raspberry Pi RP2350 board for audio experimentation

PicoADK v2 Synthesizer Development Platform

After the success of PicoADK v1, Datanoise has recently announced the launch of its PicoADK v2 music synthesizer built around the Raspberry Pi RP2350 MCU. The board supports projects like custom synthesizers, audio effects, and noise generation, and the 8 MB QSPI PSRAM of the RP2350 makes it ideal for memory-intensive applications such as long delays. Additionally, it features a SWD debug port, microSD card support, a MIDI-in circuit with an optocoupler, USB Type-C, user and power LEDs, and more. Previously, we have written about various similar synthesizer boards, like the Arduino-based MIDI controller, and we have seen products like the TinyLlama x86 retro computer, which uses the Raspberry Pi Zero 2 W as a MIDI synthesizer. PicoADK v2 music synthesizer specification Microcontroller – Raspberry Pi RP2350A MCU CPU – Dual-core Arm Cortex-M33 processor @ 150MHz Memory – 520KB internal RAM Storage – 8KB OTP Package – QFN-60; 7×7 mm Memory – Optional 8MB QSPI […]

August 1, 2024August 2, 2024 by Jean-Luc Aufranc (CNXSoft) - No Comments

The Open Home Foundation adds HACS, microWakeWord, and Music Assistant open-source projects

Open Home Foundation adds HACS, microWakeWord, Music Assistant

HACS, microWakeWord, and Music Assistant projects have joined the Open Home Foundation launched a few months ago to manage open-source projects related to Home Assistant and Smart Home applications in general separating them from Nabu Casa’s commercial activities. Note the HACS, microWakeWord, and Music Assistant projects will not operate directly under the Open Home Foundation’s umbrella, but they are external projects that the foundation collaborates on since it believes those are projects worth investing in to further develop the Smart Home ecosystem. Let’s have a quick look at the three projects. Home Assistant Community Store (HACS) is the most used custom integration for Home Assistant and allows users to easily install custom integrations, cards, and themes. Music Assistant gives users control over their media players and audio files handling both local music collection and music streaming services so that users can play any tune anywhere in their house without restrictions. […]

September 26, 2023October 8, 2023 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

Review of Arylic BP50 Bluetooth 5.2 preamplifier with TIDAL Music

Arylic has sent us a sample of their low-cost BP50 Bluetooth 5.2 preamplifier for review. It features an ESS Saber ES9023P DAC chip and Qualcomm QCC3040 Bluetooth chip with support for aptX, aptX HD (High Definition), aptX LL (Low Latency), and aptX AD (Adaptive). It offers many input-output connections such as phono preamp MM/MC, optical, Line-in, subwoofer output, and HDMI ARC. You can find the full details about the specifications in the aforelinked announcement. Arylic BP50 unboxing Let’s start our review with an unboxing. Our package came with the following items: Arylic BP50 Bluetooth 5.2 preamplifier A 12V/1A power supply 2x Bluetooth antennas (3dBi) A remote Control A user manual As a reminder, here are the ports on the back of the preamplifier as shown in a stock image from the company. Test setup For this review, we’ve connected the Arylic BP50 Bluetooth preamplifier’s Line-Out port to the CD Audio […]

September 7, 2023September 6, 2023 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Haxophone – A Raspberry Pi-based electronic saxophone with mechanical keys (Crowdfunding)

The Haxophone is an unusual Raspberry Pi expansion board that transforms the popular SBC into a travel saxophone using mechanical keys. The hackable musical instrument is open-source hardware and OSHWA certified and comes with mechanical keys which makes it easily repairable, customizable by changing keycaps or the firmware, and at a price point cheaper than commercial digital saxophones with custom molded keys. Haxophone key features and specifications: Custom Raspberry Pi HAT PCB Tactile-feedback 5-pin mechanical switches Mechanical keycaps Airflow pressure sensor Built-in audio amplifier compatible with Raspberry Pi Zero and Zero W Serial console for hacking Weight – 180 grams OSHW certifications – PT000005 You’ll find KiCAD hardware design files, assembly instructions, documentation, and the software and firmware used with the Haxophone on GitHub. There are two main software components, first haxo-rs Rust-based driver for detecting key presses and breath in order to convert them into notes, and fluidsynth synthesizer […]

September 26, 2022December 4, 2022 by Jean-Luc Aufranc (CNXSoft) - No Comments

Arylic A50+ review – An entry-level wireless stereo amplifier

The Arylic A50+ is a stereo audio streamer with a built-in power amplifier and support for wireless networks such as WiFi and Bluetooth as well as wired connections such as Ethernet, Analog RCA Line In, optical S/PDIF input, Subwoofer Out, and USB host port. All you need to do is connect the Arylic A50+ amplifier to passive speakers, and you can then easily stream music from streaming services such as Spotify, Tidal, or Qobuz in high-definition audio with the company’s 4STREAM app or another compatible app. Multiple A50+ wireless amplifiers can also be connected through your house to enable multiple rooms and/or zones support. Arylic A50+ unboxing Arylic A50+ wireless amplifier teardown We can open the device after loosening four screws and have a look at the various electronic components used in the design. The main board, named Up2Stream A50Pro, consists of 5 important integrated ICs: Those include: […]

January 31, 2017 by Jean-Luc Aufranc (CNXSoft) - No Comments

MacroFAB FX Development Board is an Open source Audio Electronics Prototyping Platform (Crowdfunding)

A couple of years ago, I wrote about a Linux multi-effects guitar pedal, and if you are interested in such audio projects, another company called MacroFab, specializing in manufacturing & assembling PCBs & electronic device, has now designed open source FX development board for audio electronics prototyping, that can be used for audio effects “guitar” pedals, and let you design your own tones. Key features of FX development board: Potentiometers 9V battery holder ¼” Input and output jacks connected to breadboard True bypass 3PDT switch User selectable power supply connections Dual solderless breadboards with power rails selectable by jumpers Adjustable 9 V power supply Power supply with 2.1 mm dc input jack for use with AC-to-AC wall wart; +/- 15 volt @ 200 mA power supplies with over-current protection; +1.25 to 9 V @ 150 mA adjustable power supply; Split voltage rail (1/2*9 Volt Rail) @ 15 mA for use […]

November 18, 2016June 18, 2018 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

$49 Dashbot Car Dashboard Assistant is Powered by C.H.I.P Pro Allwinner GR8 Module (Crowdfunding)

Most companies specializing in development boards may sell a few accessories for their boards, but usually leave product design to their customers. Next Thing Co. does that too, but the company also produces some products like PocketCHIP portable Linux computer & retro game console, and more recently Dashbot, a voice controller assistant for your car’s dashboard powered by CHIP Pro module. Dashbot hardware specifications: CPU Module – CHIP Pro with Allwinner GR8 ARM Cortex A8 processor @ 1.0 GHz, 512MB NAND flash, 256 DDR3 RAM, 802.11 b/g/n WiFi, Bluetooth 4.2 External Storage – micro SD slot Display – Red LED display Audio – 32-bit audio DSP for beamforming & noise suppression; fairfield audio pre-processor with 24-bit ADC; high fidelity MEMS microphone array (106 dB dynamic range) USB – 1x USB host port Power Supply – 5V via USB port or 12V via power port (aka cigarette lighter) + backup LiFePo4 […]

June 25, 2016June 26, 2016 by Jean-Luc Aufranc (CNXSoft) - 15 Comments

Review of PocketCHIP Hackable Handheld Linux Computer

It’s not that easy to describe PocketC.H.I.P in a couple of words, as it’s so versatile. It’s a Debian based portable Linux computer with a resistive touchscreen and battery, but also a retro gaming console thanks to PICO-8, as well as a hardware development platform for IoT application with expansion header providing access to I/Os including GPIOs, I2C, SPI, UART…, and WiFi and Bluetooth connectivity. Furthermore you can easily dismantle the device, in order to use the CHIP board, based on Allwinner R8 Cortex A8 processor, for a different project. So when Next Thing asked me if I was interested in reviewing Pocket CHIP, I was pretty excited, but when I received it, I scratched my head as there are so many ways to review the item, and it works out of the box with the firmware pre-loaded inside the internal flash, so a getting starting guide would have been […]
