Posted on by Tomisin Olujinmi - No Comments on MSI MS-CF17 is a 3.5-inch fanless single board computer with Intel Raptor Lake-P SoC

MSI MS-CF17 is a 3.5-inch fanless single board computer with Intel Raptor Lake-P SoC

MSI MS-CF17 3.5-inch Raptor Lake-P SBC

The MSI MS-CF17 is a fanless 3.5-inch single board computer powered by the Intel 13th Gen Raptor Lake-P series with options for embedded and industrial SKUs. It comes with up to 32GB of DDR5 SODIMM memory and features an M.2 M key (PCIe Gen4) socket and a SATA III storage slot. It also supports four 2.5GbE ports, four internal COM ports, eight USB interfaces, and M.2 Key-B and Key-E sockets for wireless expansion. It supports four independent displays via four HDMI 2.0 ports and an eDP/LDVS display interface. Potential applications for the fanless single board computer include industrial automation, digital signage, edge computing, transportation, and imaging systems MSI MS-CF17 specifications: SoC – Intel 13th Gen Raptor Lake-P Embedded/Industrial SKU Series; P-core: 4.3GHz ~ 4.9GHz; E-core: 3.2GHz ~ 3.7GHz; Intel Iris Xe Graphics (Core i5/i7) or Intel UHD Graphics (Core i3) Core i7-1365UE / i5-1345UE / i5-1335UE / i3-1315UE / U300E, […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on MSI MS-CF13 is a fanless mini-ITX motherboard powered by Intel N97, Core i3-N305, or Atom x7425E Alder Lake-N SoC

MSI MS-CF13 is a fanless mini-ITX motherboard powered by Intel N97, Core i3-N305, or Atom x7425E Alder Lake-N SoC

MSI MS-CF13 mini-ITX motherboard

MSI MS-CF13 is a low-profile, low-power, fanless mini-ITX motherboard offered with a choice of Alder Lake-N processors namely Intel Processor N97, Intel Core i3-N305, or Intel Atom x7425E SoC. The motherboard supports up to 16GB DDR5 SO-DIMM memory and SATA III storage, features dual 2.5GbE, six internal COM ports, six USB interfaces, M.2 Key-B and Key-E sockets for wireless expansion, and supports up to three independent display through up to two DisplayPort, one HDMI, LVDS/eDP display interfaces, MSI MS-CF13 specifications: Alder Lake N-series SoC (one or the other) Intel Atom x7425E quad-core processor up to 3.4 GHz with 6MB cache, 24EU Intel UHD Graphics @ 1.00 GHz; TDP: 12W Intel Processor N97 quad-core processor up to 3.6 GHz with 6MB cache, 24EU Intel UHD Graphics @ 1.20 GHz; TDP: 12W Intel Core i3-N305 octa-core processor up to 3.8 GHz with 6MB cache, 32EU Intel UHD Graphics @ 1.25 GHz; TDP: […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on MSI MS-C918 is a palm-sized pocket PC with Intel Processor N100 CPU, Windows 11 IoT Enterprise

MSI MS-C918 is a palm-sized pocket PC with Intel Processor N100 CPU, Windows 11 IoT Enterprise

MSI MS-C918 industrial palm-sized PC

MSI MS-C918 industrial palm-sized pocket PC is powered by an Intel Processor N100 CPU with up to 4GB LPDDR5 memory and a 128GB eMMC flash preloaded with Windows 11 IoT Enterprise. The mini PC also comes with two HDMI 2.0 ports including one with HDMI CEC support, gigabit Ethernet, WiFI 6E, and Bluetooth 5.2 connectivity, and three USB 3.2/2.0 ports. The company says it’s best suited for small office environments, digital signage, meeting systems, and other compact setups. MSI MS-C918 specifications: SoC – Intel Processor N100 Alder Lake-N quad-core processor @ up to 3.4 GHz (Turbo) with 6MB cache, 24 EU Intel HD graphics @ up to 750 MHz; TDP: 6W System Memory – Up to 4GB LPDDR5 @ 4800 MHz Storage 128GB eMMC flash MicroSD card slot Video Output – 2x HDMI 2.0 ports up to 4Kp60 with one supporting HDMI CEC Power On/Off Audio – 3.5mm audio jack, […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 9 Comments on MSI Cubi N ADL – An Intel Processor N100/N200 Alder Lake-N mini PC

MSI Cubi N ADL – An Intel Processor N100/N200 Alder Lake-N mini PC

MSI Cubi N ADL Processor N100 N200 mini PC

MSI Cubi N ADL is one of the first mini PCs based on the Alder Lake-N processor family. The mini PC will be offered with Intel Processor N100 or N200 quad-core processor and up to 16GB RAM, as well as M.2 SSD and 2.5-inch SATA storage support. The low-power mini PC also offers 4Kp60 capable HDMI and DisplayPort video output ports, two Gigabit Ethernet ports, WiFi 5 and Bluetooth connectivity, and a range of USB ports. MSI Cubi N ADL specifications: SoC Intel Processor N100 quad-core processor @ up to 3.4 GHz (Turbo) with 6MB cache, 24EU Intel HD graphics; TDP: 6W Intel Processor N200 quad-core processor @ up to 3.7 GHz (Turbo) with 6MB cache, 32EU Intel HD graphics; TDP: 6W System Memory – Up to 16GB single channel DDR4 3200MHz memory via one SO-DIMM socket Storage 1x M.2 SSD (auto switch) 1x 2.5-inch SSD / HDD Video Output […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on MSI MS-98M3 3.5-inch SBC is made for autonomous mobile robots

MSI MS-98M3 3.5-inch SBC is made for autonomous mobile robots

MSI 3.5-inch Tiger Lake SBC

MSI is better known for its consumer-grade motherboard and mini PCs, but they also have a division called MSI IPC (industrial PC) that makes embedded hardware such as the MS-98M3 3.5-inch single board computer (SBC) powered by an Intel Tiger Lake UP3 processor and designed for autonomous mobile robots (AMR). The SBC supports up to 64GB DDR4 RAM, SATA and NVMe storage, offers two 2.5 Gbps Ethernet ports, up to four display interfaces with HDMI, DisplayPort, LVDS and/or eDP,  four USB 3.2 ports, M.2 expansion sockets for storage and wireless connectivity, as well as various other internal headers.     MSI MS-98M3 specifications: Tiger Lake UP3 “IoTG” SoC (one or the other) @ 1.5GHz to 4.4GHz depending on SKU Embedded Intel Core i7-1185G7E/i5-1145G7E quad-core processor with Iris Xe graphics; TDP: 28W Intel Core i3-1115G4E dual-core processor with Intel UHD graphics; TDP: 28W Intel Celeron 6305E dual-core processor with Intel UHD […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 5 Comments on MSI Cubi N JSL mini PC comes with Celeron N4500 or Pentium N6000 Jasper Lake processor

MSI Cubi N JSL mini PC comes with Celeron N4500 or Pentium N6000 Jasper Lake processor

MSI Cubi N JSL

MSI has announced a new variant of its Cubi N family of mini PCs with the MSI Cubi N JSL mini PC powered by a Jasper Lake processor either an Intel Celeron N4500 or a Pentium Silver N6000. The 0.45L computer also comes with up to 16GB dual-channel DDR4 memory, NVMe and SATA storage, HDMI and VGA outputs, and four USB 3.2 ports. MSI Cube N JSL specifications: SoC (one or the other) Intel Celeron N4500 dual-core processor @ 1.1GHz / 2.8GHz (Burst frequency) with Intel UHD graphics; 6W TDP Intel Pentium N6000 Silver quad-core processor @ 1.1 GHz / 3.1GHz (Burst frequency) with Intel UHD graphics; 6W TDP System Memory – 2x DDR4 2933MHz SO-DIMMs, Up to 16 GB Storage 2x M.2 SSD combo (NVMe PCIe Gen3x2) 1x 2.5-inch HDD/SSD Video Output – 1x HDMI 1.4 up to 4Kp30 (TBC), 1x VGA Audio Realtek ALC233 audio codec 1x Mic-in/Headphone-out […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Intel Introduces 10th Generation Comet Lake Y and U-Series Processors

Intel Introduces 10th Generation Comet Lake Y and U-Series Processors

10th Generation Ice Lake processors for 2-in-1 laptops and tablets, and other low-power devices have just started shipping, but Intel has now launched another 10th generation family, namely Comet Lake, that is also designed for the same type of products. But instead of being manufactured using a 10nm process, Comet Lake processors will rely on Intel’s “highly optimized” 14nm process technology leveraging “improvements in intra-node optimizations”. There will be Y-Series and U-Series like in other low-power high-performance Intel processors with respectively 7W and 15W TDP, and those processors will come as Core i3/i5/i7 parts Intel Comet Lake family is the first to offer a 6-core processor in the U-series family and will provide faster CPU frequencies, faster memory interfaces, support for Intel Wi-Fi 6 (Gig+) and Thunderbolt 3.  The new processors are said to deliver up to 16% overall performance gains, and over 41% better productivity and multitasking on Microsoft […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Intel Celeron N3000 2-in-1 Laptop, and MSI Motherboards with Celeron N3050/N3150 and Pentium N3700 Processors

Intel Celeron N3000 2-in-1 Laptop, and MSI Motherboards with Celeron N3050/N3150 and Pentium N3700 Processors

Intel introduced the first low power Braswell Celeron and Pentium processors with 4 to 6W TDP, meaning a lower power consumption compared to Bay Trail-M processors, and with better performance. The first devices and motherboards based on these have started to show up with Intel’s Orchid Island 2-in-1 Reference Design based on Celeron N3000, and three MSI motherboards: N3050I ECO, N3150I ECO, and N3700I ECO respectively powered by Celeron N3050 dual core processor, Celeron N3150 quad core processor, and Pentium N3700 quad core processor, all clocked @ 1.6GHz (base frequency) and with 6W TDP. MSI did not release full details about their motherboards but we still now they’ll support H.265/HEVC hardware decoding up to 4K, Blu-ray playback and 8-channel HD Audio via an HDMI 1.4b port. Other connectors and interfaces include two DDR3L-1600MHz SO-DIMM slots (up to 8GB), two SATA III ports, one PCIe slot, Gigabit Ethernet, a COM port, […]
