mqx News - CNX Software - Embedded Systems News

January 17, 2019January 17, 2019 by Jean-Luc Aufranc (CNXSoft) - 13 Comments

Minnow Server is a Secure Web Server for Microcontrollers

Many embedded systems have a limited amount of memory, which would normally run programs with smaller footprints than on desktops or servers. For example, nginx and Apache2 are the common web servers, but on hardware with limited memory, smaller footprint web servers may be required, so that’s why I wrote a list of web servers for embedded systems running Linux/uClinux many years ago. But now, even platforms based on microcontrollers often need to run web server usually for configuration. We’ve already shown how to use Arduino to serve a simple web page and did the same in Getting Started with NodeMCU Board Powered by ESP8266 WiSoC but using Lua programming language instead. It may be more convenient to run a proper web server however, as it’s easier to change the interface, and we previously covered MicroWebSrv lightweight web server that works on platforms running MicroPython such as Pycom boards. Real Time […]

February 25, 2015 by Jean-Luc Aufranc (CNXSoft) - 9 Comments

Freescale Announces i.MX 6SoloX ARM Cortex A9 & Cortex M4 Processor

Freescale i.MX6 SoloX processor started to show up in the ARM Linux Kernel mailing list last year, and Cortex A9 + Cortex M4 processor showed up in some marketing documents, but so far all documentation was tied to a non-diclosure agreement. However, all resources are now publicly available, as the company officially launched i.MX 6SoloX processor at Embedded World 2015. Freescale i.MX 6SoloX specifications: CPU – ARM Cortex-A9 up to 1 GHz with 512 KB L2 cache, 32 KB instruction and data caches and NEON SIMD media accelerator MCU – ARM Cortex-M4 up to 200 MHz with 16 KB instruction and data caches, 64 KB TCM, MPU and FPU Memory Interface 16/32-bit DDR3-800 and DDR3L-800, 16/32-bit LPDDR2-800 SLC/MLC NAND, 62-bit ECC, ONFI2.2 2x DDR Quad SPI NOR flash, 16/32-bit NOR Flash Display and Camera Interfaces Parallel RGB LVDS 20-bit parallel CMOS sensor interface NTSC/PAL analog video input interface Multimedia GPU […]

August 7, 2014 by Jean-Luc Aufranc (CNXSoft) - No Comments

Emcraft Systems Introduces IoT Devkit with LCD Display Powered by Freescale Vybrid VF6 SoC

Emcraft Systems has launched a IoT development kit based on on their Freescale Vybrid VF6 SoM featuring MVF61 SoC with a Cortex A5 MPU and a Cortex M4 MCU, and connected to a baseboard (IOT-BSB-EXT) with various connectors (USB, Ethernet, …) as well as a 4.3″ LCD (480×272 resolution) with touchscreen. The kit targets IoT gateway applications where a GUI (Graphical User Interface) and/or HMI (Human Machine Interface) are required. Vybrid IoT devkit specifications: SoC/Memory/Storage – Via Vybrid VF6 SoM with Freescale MVF61NN151CMK50 (No Security), or Freescale MVF61NS151CMK50 (with Security), 128 MB DDR3, Up to 512 MB NAND Flash, and 32 MBytes dual QSPI Flash Storage on Baseboard – micro SD card slot Display – 4.3″ 480×272 LCD with touch panel connected to the back side of the baseboard. Connectivity – 10/100M Ethernet USB – 2x micro USB OTG ports, 1x micro USB for debugging and/or power Debugging – 20-pin […]

February 26, 2014 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Meet Freescale Kinetis KL03, the Smallest Ever ARM MCU

Last year at Embedded World 2013, Freescale announced Kinetis KL02, an ARM Cortex M0+ MCU measuring just 1.9 x 2.0mm. Customer must have complained that it’s not small enough, as the company has just unveiled Kinetis KL03 MCU, 15% smaller or 1.6 x 2.0 mm, at Embedded World 2014. Just like its predecessor KL03 targets space-constraint IoT applications such as ingestible healthcare sensing, portable consumer devices, remote sensing nodes, and wearable devices. Kinetis KL03 MCU features include: 48 MHz ARM Cortex-M0+ core, 1.71-3.6V operation Bit manipulation engine for faster, more code-efficient handling of peripheral registers 8 to 32 KB flash memory, 2 KB RAM, 8K ROM with on-chip boot loader High-speed 12-bit ADC Internal voltage reference for high ADC accuracy High-speed analog comparator Up to 22 GPIOs with pin interrupt support Low-power UART, SPI, I2C (high speed) Low power wake up Secure real time clock Timers for a broad range of […]

August 7, 2013 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Emcraft Systems Announces Freescale Vybrid VF6 SoM With Cortex A5 CPU and Cortex M4 MCU

Emcraft Systems has recently announced Vybrid VF6 SoM, a System-on-Module powered by Freescale Vybrid VF6 dual core Cortex A5/Cortex M4 SoC with 128MB DDR3, and 512MB Flash, as well as a starter kit composed of VF6 SoM and a carrier board. Emcraft VF6 System-on-Module specifications: SoC – Freescale Vybrid VF6 dual-core microprocessor with the ARM Cortex-A5 (up to 500 MHz) and Cortex-M4 cores (up to 167 MHz). Either MVF61NN151CMK50 (No Security), or MVF61NS151CMK50 (with Security). System Memory – 128 MBytes DDR3 SDRAM; Storage – Up to 512 MBytes NAND Flash, 32 MBytes dual QSPI Flash; Connectivity – Two 10/100 Ethernet interfaces with L2 switch; External interfaces using two 80-pin 0.4 mm-pitch connectors: Two USB 2.0 OTG interfaces Serial console interface at the UART CMOS levels; JTAG interface to the Vybrid VF6 TFT LCD interface Synchronous audio interface (SAI) supporting I2S, AC97 and CODEC/DSP interfaces Multiple serial digital (UART, SPI, I2C, […]

July 25, 2013December 15, 2013 by Jean-Luc Aufranc (CNXSoft) - No Comments

$55 Phytec Cosmic Boards Feature Freescale Vybrid SoCs

Freescale Vybrid SoC family has been announced at the beginning of last year, with the low-end VF3xx and mid-end VF4xx featuring a single Cortex A5 CPU, and the higher-end VF6xx and VF7xx providing a multi-core processor with Cortex A5 and Cortex M4 cores, for respectively performance, and real-time/low power tasks. Phytec has just announced the Cosmic board featuring Freescale Vybrid VF6xx single core Cortex A5 processor, and Cosmic+ board with Vybrid VF6xx Cortex A5 + Cortex M4 processor. Both boards are comprised of a baseboard coupled with a Phytec phyCORE-Vybrid system-on-module (SoM), and can be used for Linux and MQX (Freescale RTOS) development. Cosmic / Cosmic+ boards specifications: Processor VF5xx ARM Cortex-A5 @ 500MHz (Cosmic) VF6xx ARM Cortex-A5 @ 500MHz + ARM Cortex-M4 @ 167 MHz (Cosmic+) System Memory – 512 MB DDR3 Storage – 512 MB NAND + micro SD slot USB – HS USB OTG / HS USB […]

June 25, 2012July 17, 2012 by Jean-Luc Aufranc (CNXSoft) - No Comments

Motomic Butterfly Media Grid Renders Pictures and Videos on Freescale Kinetis K70 Cortex-M4 MCU

Motomic has officially announced Butterfly Media Grid, the first media player for Cortex M4 micro-controllers. The software currently runs on Freescale MQX Real-Time Operating System, and can display pictures and logos, as well as play videos on micro-controllers such as the Freescale Kinetis K70 MCU. Here are Media Grid key features: Display images, logos and videos Configure from full screen to grids up to 10×10 Rotate content Configure to optimize performance Display at resolutions up to HD Update over a network. Media Grid is available as a standalone application, and an SDK is also provided in order to embed the technology in custom applications using C, C++ or Qt interfaces. Since the media can be updated over the network, Media Grid is actually similar to a simple digital signage player for low end hardware. Motomic showcased the Media Grid at Design West, in March 2012, and only recently uploaded a […]

March 27, 2012March 27, 2012 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

Freescale Vybrid Controllers: Cortex A5 + Cortex M4 Solutions

Freescale announced the new Vybrid platform based on Cortex A5 application processor and Cortex-M4 MCU (VF6xx and VF7xx family only) which targets building/home automation and control, industrial automation, point-of-sale systems, medical devices, smart energy equipment, and appliances. There are 5 families of Vybrid Controllers which support the following common features: Video/Camera Interface Unit + optional OpenVG GPU (except VF3xx) Up to 800 MHz data rate DDR3 and LPDDR2 support (except VF3xx) USB 2.0 OTF with Integrated PHY (1 or 2 depending on model) Ethernet 10/100 MAC (1 or 2 depending on model) Display controller (WQVGA to XGA resolutions) High-assurance boot with Crypto Acceleration Up to 1.5 MB on chip SRAM NAND Flash controller and Dual Quad-SPI with eXecute-In-Place(XIP) Dual 12-bit ADC and DAC Here are the 5 families of Vybrid platforms and key differentiating features: VF3xx: ARM Cortex-A5 up to 266 MHz, 1x USB 2.0 OTG, 2x Ethernet, display up […]
