March 27, 2018March 27, 2018 by Jean-Luc Aufranc (CNXSoft) - 9 Comments

Turris MOX is a Modular Router with WiFi, SSD, LTE Modem, Ethernet, and SFP (Fiber) Modules (Crowdfunding)

The makers of Turris Omnia router – powered by a Marvell ARMADA 385 processor and running Turris OS based on OpenWrt – have been working a new product: Turris MOX modular router which can be extended with mPCIe add-on cards for LTE, SFP cage, M.2 SSD, and so on. They will soon launch an Indiegogo campaign for it, but in the meantimes, CZ.NIC association has a pre-campaign for a $69 MOX access point with dual band WiFI card, and intended for Turris Omnia users. The full details are not available, although we can find out a little more through root.cz and the video embedded below. The system is comprised of a basic MOX A module powered by a dual-core Armada 3720 processor coupled with 512 MB RAM, as well as USB 3.0, Gigabit Ethernet, and an I/O expansion header with GPIO, SDIO, UART and I2C. There’s also an mPCIe port […]

March 9, 2018March 9, 2018 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

ALB32-WROVER is an ESP-WROOM-32 Compatible Module with 32 Mbit PSRAM, up to 128 Mbit Flash

ESP-WROOM-32 is one of the most commonly ESP32 WiFi + Bluetooth module, and does the job for many applications. However, it only includes 4MB (32Mbit) flash, and no external PSRAM, while Espressif ESP32 chip itself supports up to 128 Mbit (16MB) NOR flash and up to 32Mbit (4MB) PSRAM, so for applications demanding more resources (e.g. MicroPython), or for initial development it would good to have a module maxing out memory and storage capabilities of the chip. Analog Lamb ALB32-WROVER does exactly that with 32 Mbit PSRAM, and 32 to 128 Mbit flash, in a form factor compatible with ESP-WROOM-32 module. ALB32-WROVER specifications: WiSoC – Espressif ESP32 (Rev0?) Wi-Fi and Bluetooth combo chip External Memory – 32Mb PSRAM Storage – 32, 64, or 128Mbit Flash Dimensions – 18 x 25 x 3 mm Compatible with ESP-WROOM-32, except for GPIO16 & 17 (used for PSRAM) It’s very odd the company claims the […]

March 31, 2017March 31, 2017 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

Aconno Bluetooth 4.0 & 5 IoT Development Board Features an nRF52832 or nRF52840 Module, an e-Paper Display, Sensors and More

Bluetooth 5 is the latest iteration of Bluetooth with up to four times the speed and twice the range of Bluetooth 4.0 LE, and so far apart from Puck.js and Nordic Semi nRF52840 devkit, I had not seen many Bluetooth 5 IoT modules or boards. Aconno, a German startup, has designed ACD-52832 Bluetooth 4.0 / Thread / ANT+ IoT development board based on their own nRF52832 module, and equipped with some goodies like a black & white e-Paper display, a joystick, sensors, I/Os, etc… They’ve also launched an updated module with Bluetooth 5 using nFR52840 SoC. I don’t have the full details about the new module, but the nRF52832 module and devkit is interesting to look at, especially features should be similar. Aconno ACD-52832 board specifications: Wireless Module – ACN52832 based on Nordic Semi nRF52832 ARM Cortex-M4 @ 64 MHz SoC with Bluetooth Smart, ANT+, Thread, NFC, and 2.4 GHz […]

November 14, 2016 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

$2 Wisol SFM10R1 & SFM10R2 Sigfox Modules and Evaluation Board

LoRa appears to be one of the most popular long range lower power WAN standards, at least based on the number of hobbyist boards coming to market, but hardware is not exactly cheap with modules such as Microchip RN2483 & RN2903 LoRa modules selling a little over $10, and development board such as LoPy normally going for at least $35. If large scale IoT is ever going to take off, prices will have to go lower, and AFAIK we are still waiting for the promised sub $2 Weightless chips. But if Elettronica In tweet is to be believed some Sigfox modules made by Korean company Wisol are selling for just $2, likely in larger quantities. WiSOL SFM10R1 is made with RCZ1 (Radio Configuration Zone 1 – ETSI – Europe), while SFM10R2 module is made for RCZ2 ((Radio Configuration Zone 2 – FCC – North America). SFM10R1 key features and specifications: […]

September 15, 2016 by Jean-Luc Aufranc (CNXSoft) - 20 Comments

A.I. Thinker A20 Plus ESP8266 WiFi Board Includes GPRS Support and a VGA Camera

A.I. Thinker, a company known for its ESP8266 module, has designed a new intriguing product with A20Plus board powered by Espressif ESP8266 (or ESP8285) WiFi SoC, that also features GPRS connectivity, and a 0.3MP camera. There’s basically no info on the “English Internet”, but Raymond Tunning found lots of info in Chinese, and posted information and links on his blog. A20 Plus board specifications: Wireless Module – A.I. Thinker A20 module with GPRS and WiFi (ESP8266 or ESP8285), two antennas connector Camera – VGA camera interface (up to 640×480 resolution) compatible with OV7670, GC0308, GC0328, & GC0309 sensors. Expansion – 2x headers with GPIO, ADC, power signals… USB – 1x micro USB port for power and programming Misc – Reset and user button, two LEDs (for flash?) Dimensions – TBC An Android app (binary + source code) is provide to retrieve pictures (apparently no video for now) over WiFi or […]
