March 1, 2021March 1, 2021 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Raspberry Pi CM4 Carrier Board comes with RS485/Modbus, CAN, 1-wire interfaces (Crowdfunding)

Another day, another Raspberry Pi CM4 carrier board. Just like the TOFU carrier board, CM Hunter carrier board for Raspberry Pi CM4 targets industrial applications, but in a different way, as it focuses on industrial communication protocols with Galvanically-Isolated RS485/Modbus, 1-Wire, CAN 2.0B, and together with more common interfaces like Ethernet, HDMI, USB, etc… CM Hunter specifications: Supported systems-on-module – Raspberry Pi Compute Module 4 / 4 Lite Industrial communication Interfaces Isolated RS485/Modbus (Profibus compatible) based on Texas Instruments ISO1410 controller Isolated CAN 2.0B based on Microchip MCP2515 controller and MAX14879 CAN transceiver Isolated 1-Wire via Maxim DS2482 I2C bridge Storage – MicroSD card slot Video Output – HDMI 2.0, optional 3.5-inch or 4-inch 480×320 LCD display with resistive touch connected over SPI Networking – Gigabit Ethernet RJ45 port and optional 802.11b/g/n/ac WiFi 5 plus Bluetooth 5.0 LE USB – 2x USB 2.0 ports, 1x micro USB 2.0 OTG port […]

January 28, 2021April 12, 2023 by Jean-Luc Aufranc (CNXSoft) - No Comments

Agromon smart agriculture wireless transmitter connects ModBus RS485 sensors to WiFi, LoRaWAN, Sigfox, or NB-IoT

The Internet of Things has many applications including smart agriculture . A few months ago, I talked to a local shrimp farm owner who used Arduino and ESP8266 boards to monitor water and activate pumps only when needed to get shrimps healthy and save on his electricity bill. He built his own solutions, but there are also companies offering easy-to-use smart farming solutions such as Malaysia-based Wondernica’s Agromon “interface wireless transmitter” designed specifically for smart agriculture applications. Agromon has two variants with support for 2 sensors (WR-AGRO-2S) or 3 sensors (WR-AGRO-3S) that share the following specifications: Connectivity – WiFi, Sigfox (RCZ 2/4), LoRaWAN, NB-IoT Sensor Interface – Modbus RS485 (analog input / 4-20mA / 12V-14V output) Power Supply – 12V DC (tolerance up to 14V); supports batteries, solar power, or power adapter Power Consumption – Sleep Mode: 3 mW Dimensions – 130 x 90 x 40mm Ingress Protection – IP67 […]

December 30, 2020December 30, 2020 by Abhishek Jadhav - No Comments

OAS software now supports Raspberry Pi 4 for Industry 4.0 solutions

A week before the announcement that Raspberry Pi supported industrial customers through several new services, including a dedicated website for the industry and the Raspberry Pi Approved Design Partners program, OAS announced support for deploying the Open Automation Software Platform on Raspberry Pi 4 with 4GB or 8GB of memory. The solution enables the low-cost scaling of operations and “reliable on-site data logging in remote locations with limited power and connectivity”. As you may know… or not, OAS has provided IIoT solutions for the last 20 years and is widely used since the company offers secure moving of data from one location to another. Network Configuration Possibilities The platform offers support for Windows PC/Server, Windows Embedded, Windows IoT, Linux Server, Virtual Machines (Win/Linux), Raspberry Pi 4, and Docker Containers (Win/Linux). “These systems can be networked together and share data creating endless network configuration possibilities”. The OAS platform running on the […]

October 26, 2020October 27, 2020 by Jean-Luc Aufranc (CNXSoft) - 8 Comments

Modberry 500 CM4 DIN Rail Industrial Computer Features Raspberry Pi Compute Module 4

We’ve been writing about Techbase Modberry industrial embedded computers with DIN-Rail enclosures such as Modberry M500 or M2000 for several years. Most of their systems are powered by SBC’s like Raspberry Pi 4 or AAEON Up Squared, but they’ve also made models based on Raspberry Pi Compute Module 3+, and with the launch of Raspberry Pi CM4, the company has now introduced Modberry 500 CM4 industrial computer powered by Raspberry Pi Compute Module 4 with up to 8GB RAM and 32GB eMMC flash. Modberry 500 CM4 key features and specifications: SoM – Raspberry Pi Compute Module 4 with Broadcom BCM2711 quad-core Cortex-A72 processor @ 1.5 GHz, 1 to 8GB RAM, up to 32GB eMMC flash. Storage – Optional NVMe SSD via PCIe 2.0 (mini PCIe or optional M.2 slot) Video Output – Optional HDMI port Connectivity Optional Gigabit Ethernet port Optional Wi-Fi (IEEE 802.11 b/g/n/ac) & Bluetooth 5.0 Optional 5G, […]

August 20, 2020 by Jean-Luc Aufranc (CNXSoft) - No Comments

RAK7431 RS485 Bridge Relays ModBUS Data over the LoRaWAN Network

Last year with covered Dragino RS485-LN RS485 to LoRaWAN converter that extends the range of RS485 wirelessly up to 15+km thanks to LoRaWAN connectivity. Rakwireless has now launched a similar product with RAK7431 Modbus RS485 to LoRaWAN bridge. RAK7431 key features and specifications: MCU- STM32L071 industrial-grade MCU with low-power consumption (4uA sleep) LoRa Semtech SX1272 LoRa transceiver Frequencies – RU864, IN865, EU868, US915, AU915, KR920, AS923 Tx Power – 20dBm (Max) LoRaWAN 1.0.3 protocol stack, supports Class A, Class B & C Polling mode, transparent mode and packet mode RS485 6-pin RS485 terminal block Support up to 16x RS485 devices, with up to 32 instruction sets Baud rate – Configurable 9600 to 115200bps Can power RS485 devices via a dedicated output USB – 1x Micro USB configuration port Misc – Reset key, 3x LEDs Input Voltages – 8-48V DC input via 2-pin terminal block; 5V via Micro USB Dimensions – […]

July 28, 2020July 28, 2020 by Jean-Luc Aufranc (CNXSoft) - No Comments

M.2 and Half-size mPCIe Cards Support Real-Time Ethernet and FieldBus Networks

Hilscher cifX M.2 and half-size mini PCIe cards powered by the company’s NETX 90 network-on-chip multi-protocol Cortex-M4 SoC bring real-time Ethernet and FieldBus to compatible systems. The tiny cards are designed for PC-based devices such as IPC’s, HMI’s and robots, and support various firmware for PROFINET IO-Device, EtherNet/IP Adapter, EtherCAT Slave, or OpenModbus/TCP. The company claims its cifX M.2 (A+E key) and half-size mini PCIe cards are the smallest multiprotocol PC cards on the automation market with a size of 22×30 mm and 30×26.8 mm respectively. The cards also support extended temperature from -20°C to 70°C and offer one hardware platform for all real-time Ethernet slave protocols. Besides PROFINET IO-Device, EtherNet/IP Adapter, EtherCAT Slave, and OpenModbus/TCP, Hilscher will provide support for CC-Link IE Field Basic and Ethernet POWERLINK Slave in new firmware available in Q4 2020, and OPC UA and MQTT functionalities are planned for future releases. The cards are […]

November 6, 2018November 6, 2018 by Jean-Luc Aufranc (CNXSoft) - No Comments

ModBerry M2000 Industrial Computer Features UP Squared Apollo Lake Board

TECHBASE has been providing DIN rail mountable Arm and x86 based Modberry industrial computers / IoT gateways for several years. The company has now upgraded ModBerry M1000 model with an Intel Cherry Trail UP board to ModBerry M2000 computer featuring AAEON UP Squared board powered by either an Intel Celeron N3350 dual core processor, or Pentium N4200 quad core processor, both part of Intel’s Apollo Lake family. ModBerry M2000 specifications: SoC (one or other other) Intel Celeron N3350 dual core processor @ 1.10 / 2.40 GHz with Intel HD Graphics 500; 6W TDP Intel Pentium N4200 quad core processor @ 1.10 / 2.50 GHz with Intel HD Graphics 505; 6W TDP System Memory – 2, 4, or 8GB RAM Storage – 16, 32, 64, or 128GB eMMC flash, SATA connector and M.2 SATA socket Video Output – 1x HDMI Connectivity – 2x Gigabit Ethernet, with optional LTE/3G, WiFi, ZigBee, LoRa, […]

March 31, 2018March 30, 2018 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

$24 Eastron SDM120C Smart Meter Supports RS485, ModBus, Up to 45A Load

A couple of days ago, I wrote about Sonoff POW R2 WiFi switch with power monitoring function that meant to be connected to your mains via terminal, and I was made aware of another product – Eastron SDM120C – that also does power metering, but support up to 45A (good enough for whole house in many cases), and use RS485 / Modbus communication instead of WiFi. I’ve also noticed it’s compatible with Domoticz with source code released on Github, so it might be worth a look. Eastron SDM120C specifications: Rated Voltage (Un) – 220/230V Voltage Range – 0.8~1.2 Un Base Current – 5A Max. / Min. Current – 45A / 0.25A Frequency – 50/60Hz Remote Reading – RS485 port using Modbus RTU protocol Pulse Output – Pulse 1: 1000/100/10/1 imp; pulse 2: 1000 imp/kWh Power Consumption – <2W/10VA Safety / Certifications: AC voltage test – 4KV for 1 minutes Impulse […]
