mini pc

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Zimaboard 2 – An Intel N150 micro server and mini PC with dual SATA, dual 2.5GbE, PCIe slot, miniDP (Crowdfunding)

Zimaboard 2 – An Intel N150 micro server and mini PC with dual SATA, dual 2.5GbE, PCIe slot, miniDP (Crowdfunding)

ZImaboard 2

ZimaBoard 2 is a compact Intel Processor N150 “Twin Lake” mini PC and micro server with two 2.5Gbps Ethernet ports, two SATA ports, two USB 3.1 ports, and a 4K-capable miniDP video output. It built upon the company’s ZimaBoard introduced in 2021 with an Apollo Lake processor, but offers a much faster Intel N150 CPU, LPDDR5x memory, 2.5GbE networking instead of gigabit Ethernet, and a PCIe Gen 3.0 x4 slot as opposed to a PCIe Gen 2.0 x4 slot. Two variants are offered: one with 8GB RAM and 32GB eMMC flash and the other in a 16GB/64GB configuration. Zimaboard 2 specifications: SoC – Intel Processor N150 quad-core “Twin Lake” processor  @ up to 3.6 GHz (Turbo) with 6MB cache, 24EU Intel UHD graphics @ 1000 MHz; PBP: 6W (but set to 10W here) System Memory and Storage ZimaBoard 2 832 – 8GB LPDDR5X 4800MHz; 32GB eMMC flash ZimaBoard 2 1664 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on ALPON X4 – A Raspberry Pi CM4 fanless Edge Computer with 4G LTE cellular connectivity

ALPON X4 – A Raspberry Pi CM4 fanless Edge Computer with 4G LTE cellular connectivity

ALPON X4

SixFab ALPON X4 is yet another fanless Raspberry Pi CM4-powered edge computer whose main selling point is built-in 4G LTE cellular connectivity with an eSIM, besides two Ethernet ports, and dual-band WiFi 5 and Bluetooth 5.0 on the system-on-module. The edge computer ships with 8GB RAM and 32GB eMMC flash by default, but another Raspberry Pi CM4 can be used upon request. Other ports include HDMI video output,  two USB 2.0 ports, and an RJ11 jack for GPIO expansion. The system supports three power options: USB PD, a 9V to 30V DC input terminal block, or PoE. ALPON X4 specifications: SoM – Raspberry Pi CM4 SoC – Broadcom BCM2711 CPU – Quad-core Cortex-A72 SoC @ 1.5GHz GPU – VideoCore VI with support for OpenGL ES 3.1 and Vulkan 1.0 VPU Decode – H.265/HEVC up to 4Kp60, H.264 up to 1080p60 Encode – H.264 up to 1080p30 Memory – 8GB LPDDR4-3200 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on AAEON UP 710S Edge Intel Processor N50/N97/N100/N200 mini PC is offered with Windows 11 IoT Enterprise or Ubuntu Pro 24.04 LTS

AAEON UP 710S Edge Intel Processor N50/N97/N100/N200 mini PC is offered with Windows 11 IoT Enterprise or Ubuntu Pro 24.04 LTS

AAEON UP 710S Edge Mini PC

AAEON UP 710S Edge is a small fanless Mini PC powered by Intel Processor N50, N97, N100, or N200 Alder Lake-N SoC designed for companies wanting to upgrade industrial automation setups, and running Windows 11 IoT Enterprise 24H2 LTSC or Ubuntu Pro 24.04 LTS. Based on the UP 710S SBC introduced last November, the mini PC features a 10-pin terminal block with up to eight GPIOs, SPI, I2C, and PWM, an RS-232/422/485 COM, and support for WiFi and Bluetooth via an M.2 2230 E-Key slot. The computer also offers HDMI video output, three USB 3.2 ports, and gigabit Ethernet networking. UP 710S Edge specifications: Alder Lake-N SoC Intel Processor N50 dual-core processor up to 3.4 GHz with 6MB cache, 16EU Intel UHD Graphics @ up to 750 MHz; TDP: 6W Intel Processor N97 quad-core processor up to 3.6 GHz with 6MB cache, 24EU Intel UHD Graphics @ up to 1.2 GHz; […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Sterolabs ZED Box Mini is a compact NVIDIA Jetson Orin Nano/NX Vision AI PC with two GMSL2 camera inputs

Sterolabs ZED Box Mini is a compact NVIDIA Jetson Orin Nano/NX Vision AI PC with two GMSL2 camera inputs

ZED Box Mini

Stereolabs ZED Box Mini “Super” is a compact mini PC based on NVIDIA Jetson Orin Nano or NX system-on-module and equipped with two GMSL2 camera inputs with synchronization trigger input/output, enabling AI Vision processing for robotics and smart infrastructure. The AI vision mini PC / embedded computer unit (ECU) also features a 256GB SSD, HDMI 1.4/2.1 video output, a gigabit Ethernet port, an optional Intel AX201 wireless module with two external antennas, a USB 3.0 port, a micro USB port for flashing the OS, and a 10-pin GPIO header with CAN Bus and UART for expansion. ZED Box mini specifications: System-on-Module (one or the other) NVIDIA Jetson Orin Nano 4GB | 34 TOPS NVIDIA Jetson Orin Nano 8GB | 67 TOPS NVIDIA Jetson Orin NX 8GB | 117 TOPS NVIDIA Jetson Orin NX 16GB | 157 TOPS Storage – 256GB SSD inserted in M.2 Key-M 2242 socket Video Output – […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 10 Comments on Mini UPS with 5V, 9V, 12V DC, and PoE output could be useful for routers, security cameras, SBCs, and mini PCs

Mini UPS with 5V, 9V, 12V DC, and PoE output could be useful for routers, security cameras, SBCs, and mini PCs

Mini Uninterruptible Power Supply DC USB PoE

Most uninterruptible power supplies (UPS) require AC voltage and use specific batteries that must be changed every few years. But those may be oversized and not the most efficient if you just want to keep single board computers (SBCs), low-power mini PCs, routers, or security cameras up and running during power failures. Luckily, some mini UPS solutions use standard rechargeable 18650 batteries, output 5V, 9V, or 12V DC, or even PoE (15V/24V) which may be more suitable for those use cases. Many mini UPS solutions come from WGP (Wonderful Green Power), so let’s have a look at the WPG103A model. WPG103A mini UPS specifications: Batteries – 4x 18650 batteries for a combined 10,400 mAh capacity Protection – Overcharge, over-discharge, overcurrent, and short circuit protection Misc – Power button, status LEDs Power Input – 12V/2A via DC jack Power Output 5V via USB Type-A port (likely limited to 1.5A or 2A […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 13 Comments on NVIDIA DGX Spark – A desktop AI supercomputer powered by NVIDIA GB10 20-core Armv9 SoC with 1,000 TOPS of AI performance

NVIDIA DGX Spark – A desktop AI supercomputer powered by NVIDIA GB10 20-core Armv9 SoC with 1,000 TOPS of AI performance

NVIDIA DGX Spark desktop AI supercomputer

NVIDIA DGX Spark may look like a mini PC, but under the hood, it’s a powerful AI supercomputer based on the NVIDIA GB10 20-core Armv9 SoC with Blackwell architecture delivering up to 1,000 TOPS (FP4) of AI performance, and high memory bandwidth (273 GB/s) with 128 GB 256-bit LPDDR5x. The GB10 SoC is equipped with ten Cortex-X925 cores, ten Cortex-X725 cores, a Blackwell GPU, 5th Gen Tensor cores, and 4th Gen RT cores. The system also features a 1 TB or 4TB SSD, an HDMI 2.1a video output port, 10GbE and WiFi 7 networking, and four USB4 ports. NVIDIA DGX Spark specifications: SoC – NVIDIA GB10 CPU – 20-core Armv9 processor with 10x Cortex-X925 cores and 10x Cortex-A725 cores Architecture – NVIDIA Grace Blackwell GPU – Blackwell Architecture CUDA Cores – Blackwell Generation 5th Gen Tensor cores 4th Gen RT (Ray Tracing) cores Tensor Performance – 1000 AI TOPS (FP4) […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on UP Squared 7100 Edge fanless mini PC features Intel Processor N97 or N100 CPU for industrial automation

UP Squared 7100 Edge fanless mini PC features Intel Processor N97 or N100 CPU for industrial automation

UP Squared 7100 Edge

AEEON UP Squared 7100 Edge is a fanless industrial mini PC for edge applications powered by an Intel Processor N97 or Processor N100 CPU and based on the UP Squared 7100 SBC. The computer comes with up to 16GB LPDDR5, 128GB eMMC flash, M.2 sockets for storage and wireless expansion, HDMI and DisplayPort video outputs, two gigabit Ethernet ports, three USB 3.2 ports, two COM ports (RS232/RS485), and Line Out and Mic In audio jacks. The mini PC takes 12V DC up to 5A via a screwable DC lock and can operate in the 0 to 60°C temperature range.   UP Squared 7100 Edge mini PC specifications: Alder Lake-N SoC (one or the other) Intel Processor N97 quad-core processor up to 3.6 GHz with 6MB cache, 24EU Intel UHD Graphics Gen 12 @ 1.2 GHz; TDP: 12W Intel Processor N100 quad-core processor up to 3.4 GHz with 6MB cache, 24EU […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 8 Comments on Ubuntu 24.04.2 released with Linux 6.11 kernel and hardware enablement stack

Ubuntu 24.04.2 released with Linux 6.11 kernel and hardware enablement stack

Ubuntu 24.04.2

Ubuntu 24.04.2 has just been released with Linux 6.11 kernel and hardware enablement (HWE) stack. I would typically not care too much about a point release, but our reviews of mini PCs have shown Ubuntu 24.04 with Linux 6.8 was not always well supported with recent mini PC, mostly due to issues with WiFi or Bluetooth, but sometimes it’s even worse. The most common problem I encountered was that MediaTek MT7922-based WiFi 6 and Bluetooth 5.3 module would not support Bluetooth on Ubuntu 24.04 unless we updated the Linux kernel to version 6.10 or newer. Mini PCs with recent processors like the Khadas Mind 2 AI Maker Kit based on Intel Core Ultra 7 258V AI SoC required even more tweaks for HDMI audio, GPU, and WiFi + Bluetooth which is why I tested it with Ubuntu 24.10 instead. Ubuntu 24.04.2 should solve all of those issues. The announcement explains […]

"}; --> "}; -->
Youyeetoo X1 x86 SBC
