June 12, 2018June 12, 2018 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

ECS Introduces GLKD-I DC Powered Gemini Lake Motherboard Family

Except for the odd industrial motherboard, most Gemini Lake motherboards launched so far rely on an ATX connector and power supply, but if you prefer a DC powered Gemini Lake motherboard, ECS now provides several options thanks to their GLKD-I series mini-ITX motherboards equipped with Gemini Lake processor. ECS GLKD-I motherboard specifications: SoC – Intel Gemini Lake processor with Intel UHD graphics; 10W TDP (Celeron J4005, J4105 or Pentium J5005) System Memory – 1x DDR4 SO-DIMM socket up to 8GB RAM; supports DDR4 2400 non-ECC, un-buffered SDRAM Memory Storage – 2x SATA III ports, 1x M.2 slot for SSD, 128 MB SPI Flash ROM for AMI BIOS Video Output – HDMI port, optional D-Sub/VGA port, optional DisplayPort, optional eDP header Audio Realtek ALC662 6-Channel HD audio CODEC 16/20/24-bit PCM format for 5.1 channel audio solution Line Out/Line In/Mic In jacks Front panel MIC/Speaker out header Connectivity – Gigabit Ethernet via […]

March 16, 2018 by Jean-Luc Aufranc (CNXSoft) - 26 Comments

ASRock J5005-ITX Pentium J5005 Motherboard Coming Soon for around $120 and Up

Several products based on Gemini Lake processors have already been announced, and some are already available through pre-orders, but so far, I’ve not seen many retail hardware based on Intel Pentium J5005, the most powerful processor of the family, except for one Intel NUC. ASRock J5005-ITX motherboard brings another option, and while it had been expected for a while, the company has now setup a proper product page, and the motherboard can be seen as “coming soon” for about $120 and up (excluding VAT) on some websites like Alzashop (in Europe) or Kakaku (in Japan). ASRock J5005-ITX motherboard specifications: SoC – Intel Pentium J5005 quad core processor @ 1.50/2.8 GHz with 18EU Intel UHD Graphics 605 up to 800 MHz; 10W TDP System Memory – 2x DDR4-2400/2133 SO-DIMM slots up to 8GB (2GB per module not supported) Storage 2x SATA3 6.0 Gb/s connectors, support NCQ, AHCI and Hot Plug 2x […]

March 7, 2018 by Jean-Luc Aufranc (CNXSoft) - 20 Comments

ASUS PRIME J4005I-C Gemini Lake Mini-ITX Motherboard is Selling for around 80 Euros

Slowly but surely we are starting to see some Intel Gemini Lake products for sale / pre-order such as Intel June Canyon NUC Mini PC/Kits, or Jumper EBook X1 laptop, and if are based in Europe, it’s now possible to purchase ASUS PRIME J4005I-C mini-ITX motherboard for under 80 Euros. The motherboard is equipped with an Intel Celeron J4005 dual core processor, two U-DIMM slots for up to 8GB RAM, SATA and mSATA for storage, HDMI/RGB/LVDS ports, Gigabit Ethernet, and more. ASUS PRIME J4005I-C specifications: SoC – Intel Celeron J4005 dual core processor @ 2.0 / 2.7 GHz with Intel UHD Graphics 600 up to 700 MHz; 10W TDP System Memory – 2x U-DIMM sockets up to 8GB DDR4 2400/2133 MHz Non-ECC, Un-buffered Memory Storage 2x SATA 6Gb/s ports 1x M.2 Socket with M Key, type 2260/2280 storage devices support (PCIe mode) 128 Mb Flash ROM for UEFI AMI BIOS […]

February 12, 2018 by Jean-Luc Aufranc (CNXSoft) - 13 Comments

GIGABYTE MZGLKAI is an Industrial Mini-ITX Motherboard Powered by an Intel Gemini Lake Processor

Last month, we got news of Gemini Lake motherboards by ASRock, and GIGABYTE. The former provided decent technical details about their boards, but the latter basically published a more-or-less useless press release about their upcoming J/N motherboards (e.g. J4005N D2P) with very few technical details. The company has now introduced MZGLKAI industrial mini-ITX motherboard featuring an Intel Celeron J4105 core Gemini Lake processor, dual Gigabit Ethernet, five SATA ports, plenty of COM ports, and more. GIGABYTE MZGLKAI (9MZGLKAINR-S) specifications: SoC – Intel Celeron J4105 quad core processor @ 1.50/2.5 GHz with 12EU Intel UHD Graphics 600 up to 750 MHz; 10W TDP System Memory – 2x DDR4 1.2V SO-DIMM slots up to 2400Mhz, 8GB max. Storage – 5x SATA III 6Gbps including 4x via Marvell 88SE9230, 1x from J4105 with SATA DOM support; 3x SATA power connectors Video Output / Display I/F HDMI 2.0a port up to 3840×2160 @ 60 Hz […]

February 1, 2018February 1, 2018 by Jean-Luc Aufranc (CNXSoft) - 52 Comments

Pine64 ClusterBoard is Now Available for $100 with one Free SOPINE A64 System-on-Module

We’ve previously reported Pine64 had developed “Sopine Clusterboard” for a specific project with support for up to seven SOPINE A64 SoMs powered by Allwinner A64 quad core Cortex A53 processor. At the time (August 2017), it was unclear whether the company would sell to the solution publicly, but they’ve now gone ahead and launched Pine64 ClusterBoard for $99.99 plus shipping, including one free SOPINE A64 module for a limited time. PINE64 ClusterBoard specifications: SoM Slots – 7x SO-DIMM slot for SOPINE A64 modules Connectivity 1x Gigabit Ethernet port (RJ45) All SoMs are connected via Gigabit Ethernet using 7x RTL8211E transceivers and RTL8370N network switch (See diagram below) USB – 7x USB 2.0 port, one per SoM Expansion – Headers for each SoM with UART (serial console), I2C, key ADC, GPIOs, SPI, RESET/POWER 5V and GND Misc – RTC, reset button, optional EEPROM connected to RTL8370N Power Supply 5V/15A via power barrel […]

January 19, 2018January 20, 2018 by Jean-Luc Aufranc (CNXSoft) - 26 Comments

ASRock Unveils J4105-ITX & J4105B-ITX Gemini Lake Mini-ITX Motherboards

We’ve already seen several Intel Gemini Lake mini PCs at CES 2018 from companies such as ZOTAC, MeLE or ECS, but if we exclude LattePanda Delta development board, I had not seen any motherboards with the latest low power Intel processors. But today I found out ASRock had listed at least two Gemini Lake mini-ITX motherboards on their website, namely J4105-ITX & J4105B-ITX, both powered by an Intel Celeron J4105 quad core Desktop processor. Both motherboards have similar specifications, except for some connectors and features: SoC – Intel Celeron J4105 quad core processor @ 1.50/2.5 GHz with 12EU Intel UHD Graphics 600 up to 750 MHz; 10W TDP System Memory – 2x DDR4-2400/2100 SO-DIMM slots up to 8GB (2GB per module not supported) Storage 2x SATA3 6.0 Gb/s connectors, support NCQ, AHCI and Hot Plug 128Mb NOR flash for AMI UEFI BIOS with GUI support J4105-ITX only – 2x SATA3 6.0 Gb/s […]

July 5, 2017July 5, 2017 by Jean-Luc Aufranc (CNXSoft) - 15 Comments

Supermicro A2SDi-2C-HLN4F Server Mini-ITX Motherboard is Based on Intel Atom C3338 “Denverton” Processor

Almost exactly one year ago, I wrote about Intel Atom C3000 Series “Denverton” processor based on the same Goldmont architecture used in Apollo Lake processor, and used in an early GIGABYTE MA10-ST0 server motherboard prototype. The latter is not out yet, but according to a YouTube video, the 16-core motherboard should be launched in H2 2017. In the meantime, Supermicro also made their own Denverton motherboard based on a lower-end Atom C3338 dual core processor. Supermicro A2SDi-2C-HLN4F board specifications: Processor – Intel Atom C3338 dual core Denverton processor @ 1.50 / 2.20 GHz with 4 MB cache; 9W TDP System Memory Up to 64GB Register DIMM RDIMM and DDR4-1866MHz Up to 32GB Unbuffered ECC/non-ECC UDIMM, DDR4-1866MHz, in 2 DIMM slots Storage – 4x SATA 3 ports, but up to 8x SATA 3 (6 Gbps) ports are configurable; N.B.: total combined PCI-E lanes and SATA ports is up to 8 Connectivity […]

April 24, 2017 by Jean-Luc Aufranc (CNXSoft) - 33 Comments

SolidRun MACCHIATOBin Mini-ITX Networking Board is Now Available for $349 and Up

SolidRun MACCHIATOBin is a mini-ITX board powered by Marvell ARMADA 8040 quad core Cortex A72 processor @ up to 2.0 GHz and designed for networking and storage applications thanks to 10 Gbps, 2.5 Gbps, and 1 Gbps Ethernet interfaces, as well as three SATA port. The company is now taking order for the board (FCC waiver required) with price starting at $349 with 4GB RAM. MACCHIATOBin board specifications: SoC – ARMADA 8040 (88F8040) quad core Cortex A72 processor @ up to 2.0 GHz with accelerators (packet processor, security engine, DMA engines, XOR engines for RAID 5/6) System Memory – 1x DDR4 DIMM with optional ECC and single/dual chip select support; up to 16GB RAM Storage – 3x SATA 3.0 port, micro SD slot, SPI flash, eMMC flash Connectivity – 2x 10Gbps Ethernet via copper or SFP, 2.5Gbps via SFP, 1x Gigabit Ethernet via copper Expansion – 1x PCIe-x4 3.0 slot, Marvell […]
