January 31, 2024January 30, 2024 by Debashis Das - 19 Comments

Mcuzone MPS2280 M.2 NVMe HAT for Raspberry Pi 5 takes an up to 22110 Gen3 SSD drive

Raspberry Pi 5 PCIE M.2 NVME HAT with 2280 2230 2242 Gen3 SSD Support

The Mcuzone MPS2280 M.2 NVMe HAT is another PCIe to NVMe adapter board built for the Raspberry Pi 5. What sets it apart from other boards is that it supports 2280 SSDs and offers the option to Jerry-rigg a 22110 SSD with zip ties. Previously we have covered many PCIe to NVMe expansion boards such as Pimoroni NVMe Base, Geekworm X1003 PCIe to NVMe SSD adapter, and PineBerry Pi’s HatDrive, so feel free to check those out if interested. Mcuzone MPS2280 M.2 NVMe HAT specifications: PCIe Support – Compatible with PCIe x1 interface, offering Gen2 and Gen3 modes. SSD compatibility – Supports M.2 M-key interface with 2280, 2242, and 2230 size SSDs, and offers the option to Jerry-rigg a 22110 SSD with zip ties. SSD booting – Enables booting from an NVMe SSD, with options for storage expansion. Alternatively, the system can boot from TF while using the SSD for […]

January 28, 2024January 28, 2024 by Debashis Das - 8 Comments

Mcuzone MP4GM 4G LTE PCIe Module for Raspberry Pi 5 also adds three USB 2.0 interfaces

Mcuzone recently announced the MP4GM, a new 4G LTE module for the Raspberry Pi 5 SBC. This module connects to the Raspberry Pi 5 via PCIe and includes three extra 1.25mm JST connectors for three additional USB 2.0 interfaces. This HAT is compatible with various 4G LTE mini PCIe modules from Mcuzone and Fibocom, providing flexible options for 4G connectivity. We have previously covered a 5G Modem Kit for the Raspberry Pi 5, but this is the first time we have found out about a 4G LTE kit designed for the Pi 5. We have also covered Mcuzone RK3308 SoM and the MDK3308-EK Evaluation Kit, designed for smart voice applications as well as a Raspberry Pi CM4 board with dual Ethernet capabilities all from MCUzone. So, feel free to check those out if you are interested in their products. Mcuzone MP4GM 4G LTE module specification: Model – MP4GM PCIe to […]

March 15, 2021 by Jean-Luc Aufranc (CNXSoft) - 8 Comments

Raspberry Pi CM4 boards offer dual Ethernet, 4G LTE

Since the launch of Raspberry Pi CM4 and CM4Lite systems-on-module last October, we’ve seen carrier boards bring their own set of features including industrial communication interfaces, a stereoscopic camera, four SATA ports to build a NAS, a DIN-rail based industrial controller, and more. But so far, I have not seen a Raspberry Pi CM4 carrier board with dual Ethernet ports. Seeed Studio’s “Dual Gigabit Ethernet Carrier Board for Raspberry Pi Compute Module 4” was brought to our attention this morning, but there’s another one with 4G LTE connectivity, Fast+Gigabit Ethernet ports, and extra I/Os courtesy of MCUZone’s CM4-4G IO board. Let’s have a look at both of them. Dual Gigabit Ethernet Carrier Board for Raspberry Pi Compute Module 4 Specifications: Supported SoMs – Raspberry Pi CM4 and CM4Lite with up to 8GB RAM, 32GB eMMC flash, optional WiFi & Bluetooth Storage – MicroSD card slot to load OS on CM4Lite […]

June 8, 2019 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Mcuzone RK3308 SoM and MDK3308-EK Evaluation Kit are Designed for Smart Voice Applications

Mcuzone MDK3308-EK Rockchip-RK3308 Development Board

Rockchip RK3308 is a quad-core Cortex-A35 processor that was announced in 2018 together with RK3326 specifically for Smart AI solutions. While the processor is equipped with an RGB LCD output interface, it does not come with a 2D or 3D graphics accelerator, so it’s better suited to smart speakers with an optional display using a basic user interface. I’ve not seen many hardware platforms or boards based on the processor, but today I noticed “Hangzhou Wild Chip Tech” had an RK3308 system-on-module, as well as development kits for sale on Aliexpress with the module price starting at $23. Mcuzone MDK3308 Coreboard Specifications: SoC – Rockchip RK3308 quad-core Cortex-A35 processor @ 1.3 GHz with NEON and VFPv4 FPU System memory / storage configurations: 256MB DDR3/3L + 256MB NAND flash 512MB DDR3/3L + 8GB eMMC flash 2x 100-pin dual row headers (1.27mm pitch) exposing: Display – LCD interface up to 1024×600 (RGB), […]
