Posted on by Jean-Luc Aufranc (CNXSoft) - 9 Comments on ESP32-C2 WiFi & Bluetooth LE 5.0 chip to support Matter WiFi protocol

ESP32-C2 WiFi & Bluetooth LE 5.0 chip to support Matter WiFi protocol

ESP32-C2

Espressif ESP32-C2 is a new WiFi 4 and Bluetooth LE 5.0 chip the Shanghai-headquartered company has been working on since last year. The company claims it has better RF performance due to a smaller package reducing stray parasitics, and it will support the Matter protocol whose first version should become ratified later this year. The first ESP32-C2 product wafers have been received by the Shanghai team in spite of the current lockdown and quarantine in Shanghai due to the COVID-19, and teams in other parts of Asia, Europe, and Singapore are working without interruption on software integration into ESP-IDF and ESP-RainMaker. ESP32-C2 preliminary specifications: RISC-V core 272KB of memory Connectivity WiFi 4 + BLE 5.0 Tx power 20 dBm (FCC limit) 18 dBm for 802.11N MC7 packets (72.2 Mbps) Receiver sensitivity – -97 to -100 dBm for 1 Mbps 802.11B packets. Receive current – 58 mA Package –  4 x […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on Silicon Labs BG24 and MG24 2.4 GHz wireless MCU’s quadruple AI performance at a fraction of the energy

Silicon Labs BG24 and MG24 2.4 GHz wireless MCU’s quadruple AI performance at a fraction of the energy

Silicon Labs BG24 & MG24 block diagram

Machine Learning is getting everywhere including into 2.4GHz wireless microcontrollers with SIlicon Labds BG24 Bluetooth and MG24 multi-protocol Cortex-M33 microcontrollers that improve AI/ML performance by 4 times using 1/6th of the energy thanks to a built-in AI accelerator. That makes the new microcontrollers suitable for battery-powered edge AI devices with support for Matter (coming soon) as well as PSA Level 3 Secure Vault protection. Silicon Labs expects the chips to be found in various smart home, medical and industrial applications. BG24 and MG24 share the same block diagram and the same specifications apart from the supported wireless protocols: MCU core – Arm Cortex-M33 @ 78.0 MHz with DSP instruction and floating-point unit Memory – Up to 256 kB RAM data memory Storage – Up to 1536 kB flash program memory Wireless CPU – Arm Cortex-M0+ 2.4 GHz Radio Performance -104.5 dBm sensitivity @ 250 kbps O-QPSK DSSS -104.9 dBm sensitivity […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on NXP IW612 Wi-Fi 6, Bluetooth 5.2, 802.15.4 tri-radio solution supports Matter

NXP IW612 Wi-Fi 6, Bluetooth 5.2, 802.15.4 tri-radio solution supports Matter

NXP IW612 block diagram

Matter, previously known as Project Chip, is a unified interface for Smart Home devices to improve interoperability between devices from different manufacturers and associated services like Google Assitant or Amazon Alexa. Matter can work over Thread, WiFi, Ethernet, BLE, etc… so it’s not limited by the physical layer. So far, we mostly heard about development related to Matter, and Espressif has published a series of posts about Matter to be for instance used by their upcoming ESP32-H2 wireless MCU, but I had not seen many other solutions, not commercial products. This is going to change in 2022, as Belkin announced it’s working on “redesigned smart plugs and lighting solutions” with support for Matter over Thread” that start selling this summer. Separately, NXP also announced the IW612 tri-radio solution with Matter support and dual-band WiFI 6, Bluetooth 5.2, and 802.15.4 radios. NXP IW612 IW612 key features and specifications: Dedicated, independent CPUs […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 9 Comments on Home Assistant Yellow – A Raspberry Pi CM4 based automation gateway (Crowdfunding)

Home Assistant Yellow – A Raspberry Pi CM4 based automation gateway (Crowdfunding)

Home Assistant Amber

The team behind the popular Home Assistant open-source home automation framework has just launched their second hardware with Home Assistant Yellow automation gateway based on Raspberry Pi CM4 module. This follows last year’s ODROID-N2+ based Home Assistant Blue which was a limited edition and has now been discontinued, albeit still supported. The carrier board for Home Assistant Amber is designed from scratch and notably includes Silicon Labs MGM210P Mighty Gecko Module with support for Zigbee 3.0, OpenThread, and Matter (Soon), as well as M.2 socket that can take an NVMe SSD, or an AI accelerator card. Home Assistant Yellow specifications: Supported SoM – Raspberry Pi Compute Module 4 (CM4) with Broadcom BCM2711 quad-core Cortex-A72 processor @ 1.5 GHz, up to 8GB RAM, up to 32GB storage. (Note: optional WiFI 5 and Bluetooth 5.0 connectivity not covered by regulatory approval) Storage – Support for NVMe SSD via M.2 socket, bootable for […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on The Zigbee Alliance renames to the Connectivity Standards Alliance (CSA), Project CHIP becomes “Matter”

The Zigbee Alliance renames to the Connectivity Standards Alliance (CSA), Project CHIP becomes “Matter”

connectivity-standards association matter

The Zigbee Alliance is/was an organization of hundreds of companies creating, maintaining, and delivering open standards for Zigbee… and other Internet of Things (IoT) standards including Smart Energy, Green Power, JupiterMesh, rf4ce, Dotdot, etc… Since the organization does not reflect its involvement beyond Zigbee, the name has just been changed to the Connectivity Standards Alliance (CSA), and while they were at it they also rebranded “Project CHIP” (Connected Home over IP) to “Matter”, maybe because “connectivity standards matter!” 😉 There’s also a new website csa-iot.org but it may not have complete information just yet, and they invite you to access the Full website (https://zigbeealliance.org/about/) for extra details. Nothing much has changed here besides the name. But there’s more to report about Matter. A dedicated website has launched for the new standard, although the code remains under the Project Chip GitHub account at this time. What’s more interesting is that formal […]
