November 17, 2023November 17, 2023 by Jean-Luc Aufranc (CNXSoft) - No Comments

AAEON PICO-ADN4 Pico-ITX Alder Lake-N SBC features Processor N50 to Atom x7425E SoC

AAEON PICO-ADN4 Pico-ITX SBC comes with a choice of four Alder Lake-N processors – Processor N50, Processor N97, Core i3-N305, or Atom x7425E – and is available in SKUs with both standard (0°C ~ 60°C) and wide-temperature (-40°C ~ 85°C) ranges for industrial applications. The single board computer comes with up to 16GB LPDDR5, SATA and mSATA storage, three display interfaces (HDMI, eDP/LVDS, DDI), dual Ethernet with 2.5GbE and GbE RJ45 ports, USB 3.2 Gen 2 ports, and M.2 and mPCIe sockets for expansion. The board supports 12V DC power input by default, but AAEON company offers a 9V to 36V DC input option. PICO-ADN4 specifications: Alder Lake-N SoC (one or the other) Intel Processor N50 dual-core processor up to 3.4 GHz with 6MB cache, 16EU Intel UHD Graphics; TDP: 6W Intel Processor N97 quad-core processor up to 3.6 GHz with 6MB cache, 24EU Intel UHD Graphics; TDP: 12W Intel […]

August 22, 2023August 22, 2023 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Tiny solder-down NXP i.MX 93 System-on-Module powers credit card-sized evaluation board

Ka-Ro Electronics’ QS93 is a tiny solder-down NXP i.MX 93 System-on-Module (SoM) running Linux and designed for edge processing. The company also offers a credit card-sized evaluation board that may remind some of the Raspberry Pi with its GPIO header and general layout, but it comes with two Fast Ethernet ports and one USB 2.0 port. We’ve already covered several system-on-modules based on the NXP i.MX 93 Cortex-A55/M33 AI processor including some with high-density board-to-board connectors such as the Compulab UCM-IMX93 and Forlinx FET-MX9352-C, others with a SO-DIMM connector like the VAR-SOM-MX93, and finally some designed to be soldered on the carrier board such as the OSM-L compatible iW-RainboW-G50M, and the QS93 adds to the latter category in a tiny 27×27 mm form factor. Ka-Ro electronics QS93 specifications: SoC – NXP i.MX 93 with CPU – Up to dual-core Cortex-A55 processor @ up to 1.5 GHz Real-time core – Arm […]

May 17, 2023May 17, 2023 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

Micro-ATX motherboard takes socketed Raptor Lake CPUs, offers PCIe Gen 5 slots, 2.5GbE, up to 8x SATA ports…

AAEON MAX-Q670A is an industrial micro-ATX motherboard that accepts socketed 13th Gen Intel Core Raptor Lake processors, supports up to 128GB DDR5, offers eight SATA ports with RAID 0/1/5/10, up to four Ethernet ports (GbE and 2.5GbE), and two 16-lane PCIe Gen 5 slots. Other features include five display interfaces with HDMI, DisplayPort, VGA, LVDS, and eDP, four bootable USB 3.2 Gen 2 Type-A ports, an RS232/RS422/RS485 COM port, and plenty of internals headers for more serial and USB ports, as well as M.2 expansion sockets and a digital I/O port AAEON MAX-Q670A specifications: SoC – 12th/13th Generation Intel Core LGA1700 Socket processors (Alder Lake or Raptor Lake) with up to 125W TDP Chipset – Intel Q670 Express Chipset I/O Chipset – NCT6126D System Memory – Up to 128GB via 4x DIMM slots for DDR5 4,000MHz non-ECC, un-buffered memory Storage 8x SATA III ports with support for RAID 0, 1, […]

January 4, 2023 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

Forlinx FET-MX9352-C – An NXP i.MX 9352 system-on-module for industrial AIoT applications

Forlinx FET-MX9352-C is a system-on-module based on NXP i.MX 9352 dual Cortex-A55 processor with Cortex-M33 real-time core and a 0.5 TOPS AI accelerator that can be used for industrial control, IoT gateways, medical equipment, and various applications requiring machine learning acceleration. The FET-MX9352-C follows last week’s announcement of the iWave Systems iW-RainboW-G50M OSM module and SBC with a choice of NXP i.MX 93 processors. The Forlinx module comes with two board-to-board connectors instead of solderable pads and can be found in the OK-MX9352-C single board computer with dual GbE, various display and camera interfaces, RS485 and CAN Bus, etc… FET-MX9352-C i.MX 9352 system-on-module Specifications: SoC – NXP i.MX 9352 with 2x Arm Cortex-A55 cores @ up to 1.7GHz (commercial) or 1.5 GHz (industrial), Cortex-M33 real-time core @ 250 MHz, 0.5 TOPS Arm Ethos U65 microNPU System Memory – 1GB/2GB LPDDR4 RAM Storage – 8GB eMMC flash 2x high-density 100-pin board-to-board […]

November 25, 2022 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

AIoTBOX-3568GK industrial control box offers six USB ports, RS232, RS485, CAN Bus, LVDS, and more

SMDT AIoTBOX-3568GK is an industrial control PC powered by a Rockchip RK3568 quad-core Cortex-A55 AIoT processor and offering plenty of interfaces including six USB ports, four RS232 ports, and terminal blocks with RS485 and CAN bus interfaces. The embedded computer ships with 2GB RAM and 16GB eMMC flash by default, and also features HDMI and LVDS display interfaces, 3.5mm jacks for headphones and microphone, as well as network connectivity through a Gigabit Ethernet port, WiFi, and optional Bluetooth and/or 4G LTE. AIoTBOX-3568GK specifications: SoC – Rockchip RK3568A quad-core Cortex-A55 processor @ up to 2.0GHz with Arm Mali-G52 2EE GPU with support for OpenGL ES 1.1/2.0/3.2, Vulkan 1.1, OpenCL 2.0, 0.8 TOPS NPU, and VPU with 4Kp60 H.265/H.264/VP9 video decoding, 1080p60 H.265/H.264 video encoding System Memory – 2GB RAM by default Storage – 16GB or 32GB eMMC flash, MicroSD card slot, optional 2KB EEPROM Video Output HDMI port up to 4Kp60 […]

August 23, 2022August 24, 2022 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

LeapFive NB2 quad-core RISC-V processor comes with GPU, NPU, and DSP

After SiFive and StarFive, here comes LeapFive RISC-V silicon vendor offering the NB2 quad-core 64-bit RISC-V application processor with GPU, NPU, and vision and audio DSPs capable of running Linux. LeapFive NB2 processor is equipped with MIPI DSI and LVDS display interface, dual GbE, USB 3.2/2.0 interfaces, and other peripheral interfaces that make it well-suited to a wide range of applications including Smart Home applications, robotics, industrial gateways, drones, building automation, smart cities, digital signage, medical equipment and more. LeapFive NB2 specifications: CPU – Quad-core SiFive U74 64-bit RISC-V processor @ 1.8 GHz delivering 2.5 DMIPS/MHz Cache – 32KB I-cache, 32KB D-cache, 2MB level 2 cache GPU – “High-performance graphics processor” @ 850 MHz DSP – Dedicated vision DSP, audio DSP NPU – Independent AI engine delivering up to 4 TOPS @ 1.4 GHz VPU – 4Kp60 H.264/H.265 Video encoding and decoding, JPEG image codec System Memory – Up to […]

January 11, 2022January 11, 2022 by Jean-Luc Aufranc (CNXSoft) - No Comments

Rockchip RK3568 SBC to power 4G/5G, WiFI 6 connected smart displays, features an optional tuner

Geniatech is back with another Rockchip RK3568 SBC. The K3-3568 single board computer is designed specifically for smart displays with 4G LTE, 5G, or WiFi 6 connectivity, and follows last year’s “Geniatech RK3568 development board” (aka DB3568) offered as a full-featured development kit for Rockchip RK3568 SoC. K3-3568 SBC ships with up to 8GB RAM, up to 64GB eMMC flash, and offers multiple display interfaces with HDMI, MIPI DSI, LVDS, eDP, plus and an internal HDMI input connector, as well as support for an optional DVB-T2, ISDB-T, DMBT, or ATSC digital tuner. Geniatech K3-3568 specifications: SoC – Rockchip RK3568 quad-core Cortex-A55 processor up to 1.5/2.0 GHz with Arm Mali-G52 GPU supporting OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1, 0.8 TOPS NPU for AI acceleration System Memory – 2GB, 4GB, or 8GB LPDDR4 Storage 16GB, 32GB, or 64GB eMMC 5.1 flash MicroSD card slot M.2 socket for NVMe SSD (See expansion […]

November 11, 2021March 27, 2022 by Jean-Luc Aufranc (CNXSoft) - No Comments

Amlogic T972 multimedia networking SBC supports 4K V-by-One displays

We’ve seen plenty of Amlogic S-series TV boxes and SBCs over the years, but Amlogic also manufacturer T-series SoCs designed for televisions. Since there are relatively few TV manufacturers compared to TV boxes or board manufacturers we seldom read about those. But a few years ago, we noticed a TV box based on Amlogic T962E quad-core Cortex-A53 processor offering both HDMI input and output ports, and now Shenzhen Tomao just informed me they were offering an Amlogic T972 multimedia network SBC for digital signage applications with multiple HDMI inputs and a V-By-One display interface with support for up to 4K resolutions. Amlogic T972 SBC specifications: SoC – Amlogic T972 (or T962X2) quad-core Arm Cortex-A55 processor @ 1.98 GHz with Arm Mali-G31 MP2  GPU with support for OpenGL ES 3.2, Vulkan 1.1 and OpenCL 2.0 System memory – 2GB or 4GB DDR4 Storage – 16GB eMMC flash, MicroSD card socket Display […]
