Linux

Posted on by Jean-Luc Aufranc (CNXSoft) - 21 Comments on ODROID-M2 low-profile SBC features Rockchip RK3588S2 SoC, up to 16GB LPDDR5, 128GB eMMC flash

ODROID-M2 low-profile SBC features Rockchip RK3588S2 SoC, up to 16GB LPDDR5, 128GB eMMC flash

ODROID-M2 SBC

Hardkernel has just launched the ODROID-M2 low-profile SBC based on a Rockchip RK3588S2 octa-core Cortex-A76/A55 AI SoC with up to 16GB LPDDR5, 64GB eMMC flash, an M.2 PCIe socket, support for three displays through HDMI, USB-C, and MIPI DSI interfaces, gigabit Ethernet, and more. The ODROID-M2 follows the ODROID-M1 and ODROID-M1S single board computers based on respectively Rockchip RK3568 and RK3566 quad-core Cortex-A55 processors, but a significantly more powerful Rockchip RK3588S2 processor, and a larger 90x90mm form factor to accomodate for extra features and interfaces. ODROID-M2 specifications: SoC – Rockchip RK3588S2 CPU – Octa-core processor with 4x Cortex-A76 cores @ up to 2.3 GHz (+/- 0.1Ghz), 4x Cortex-A55 cores @ up to 1.8 GHz GPU – Arm Mali-G610 MP4 GPU @ 1 GHz compatible with OpenGL ES 3.2, OpenCL 2.2, and Vulkan 1.2 APIs VPU – 8Kp60 video decoder for H.265/AVS2/VP9/H.264/AV1 codecs, 8Kp30 H.265/H.264 video encoder AI accelerator – 6 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 15 Comments on $30 Banana Pi BPI-WiFi6 Mini is a dual GbE and WiFi 6 router board with optional 4G LTE or 5G cellular connectivity

$30 Banana Pi BPI-WiFi6 Mini is a dual GbE and WiFi 6 router board with optional 4G LTE or 5G cellular connectivity

Banana Pi BPI-WIFI6 Mini

Banana Pi BPI-WiFi6 Mini is an inexpensive WiFi 6 and dual Gigabit Ethernet router board with an M.2 Key-B socket and Nano SIM card slot to add 4G LTE or 5G cellular connectivity. It’s a smaller version of the Banana Pi BPI-WiFi 6 router board based on the Triductor TR6560 dual-core Arm Cortex-A9 processor and Triductor TR5220 WiFi 6 chipset that follows the form factor of the Banana BPI-R3 Mini low-profile router board based on MediaTek Filogic 830 processor. Banana Pi BPI-WiFi6 Mini specifications: SoC – Triductor TR6560 dual-core Arm Cortex-A9 processor @ 1.2 GHz with LSW (Line-Card Switching) and hardware NAT up to 5 Gbps WiFi chipset – Triductor TR5220 WiFi 6 chipset System Memory – 128MB DDR3 Storage – 128MB SPI NAND flash Networking 2x Gigabit Ethernet RJ45 ports WiFi WiFi 6 with 2×2 MIMO @ 2.4 GHz, 2×2 MIMO @ 5GHz Antennas – 2.4GHz antenna connector, 2.4GHz/5GHz […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on UP Squared 7100 Alder Lake-N fanless SBC ships with up to 16GB LPDDR5 and 128GB eMMC flash

UP Squared 7100 Alder Lake-N fanless SBC ships with up to 16GB LPDDR5 and 128GB eMMC flash

UP Squared 7100

AAEON has just introduced the UP Squared 7100 fanless single board computer powered by Intel Processor N-series CPUs (N97 or N100 by default) with up to 16GB LPDDR5 and 128GB eMMC flash in a compact 90 x 85.6mm form factor. The SBC can drive up to three independent 4K displays at 60 Hz, features two RS232/422/485 interfaces, gigabit Ethernet, three USB 3.2 ports, and expansion options that include a 40-pin GPIO header, and two M.2 sockets for NVMe storage and WiFi/Bluetooth connectivity. UP Squared 7100 specifications: Alder Lake-N SoC (one or the other) Default options Intel Processor N100 quad-core processor up to 3.4 GHz with 6MB cache, 24EU Intel UHD Graphics Gen 12 @ 750 MHz; TDP: 6W Intel Processor N97 quad-core processor up to 3.6 GHz with 6MB cache, 24EU Intel UHD Graphics Gen 12 @ 1.2 GHz; TDP: 12W Additional options upon request Intel Core i3-N305 octa-core processor […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on Radxa X4 SBC kit review – Part 1: Unboxing, case assembly, Ubuntu 24.04 installation

Radxa X4 SBC kit review – Part 1: Unboxing, case assembly, Ubuntu 24.04 installation

Radxa x4 SBC review

The Radxa X4 is a single-board computer that uses an Intel N100 processor instead of an Arm-based SoC found in most SBCs and also embeds a Raspberry Pi RP2040 microcontroller for GPIO control. What’s interesting is that the Radxa X4 is a small computer board with a similar form factor as the Raspberry Pi 5 SBC, but benefits from the higher performance of Intel “Alder Lake-N” Processor N100 CPU and out-of-the-box compatibility with most operating systems, except for specific features such as GPIOs. The Intel N100 board also comes with a built-in M.2 M-key socket (so no need for an extra HAT) that supports higher speed storage thanks to a PCIe 3.0 x4 interfaces, as well as WiFi 6 connectivity, making the Radxa X4 an interesting option for those looking for a small, capable computer board for home, IoT, or industrial use. The company sent us a full kit with […]

Posted on by Sayantan Nandy - 3 Comments on ASUS N97T-IM-A – A thin mini-ITX motherboard powered by an Intel Processor N97 Alder Lake-N CPU

ASUS N97T-IM-A – A thin mini-ITX motherboard powered by an Intel Processor N97 Alder Lake-N CPU

Asus N97T IM A

The ASUS N97T-IM-A is a thin Mini-ITX motherboard for industrial and embedded use, featuring the Intel N97 Alder Lake-N processor (4 cores, 2.0–3.6 GHz) with up to 16GB of DDR5 memory at 4800 MHz, and two gigabit Ethernet ports using Realtek RTL8111H controllers. The board also includes two SATA III 6Gbps ports, a PCIe 3.0/2.0 x1 slot, and dual M.2 slots for NVMe and Wi-Fi/Bluetooth. It supports HDMI 2.0, DP++, and LVDS video outputs, with optional eDP, and can handle resolutions up to 4K at 60 Hz. Built for durability, the N97T-IM-A is designed for demanding environments with a seven-year product lifecycle. In one of our last posts, we wrote about the Jetway JNUC-ADN1, another Intel N97-powered SBC, but in a smaller Next Unit of Computing (NUC) form factor and the Jetway JMTX-ADN8 another N97 mini-ITX motherboard. Other than that we have also written about similar motherboards in the mini-ITX form factor including […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 14 Comments on Radxa ROCK 5 ITX RK3588 mini-ITX motherboard review – Building an Arm PC and NAS with Debian KDE

Radxa ROCK 5 ITX RK3588 mini-ITX motherboard review – Building an Arm PC and NAS with Debian KDE

ROCK 5 ITX Review: Build Arm Computer NAS

In this review, I’ll show how I installed Debian on the ROCK 5 ITX mini-ITX motherboard powered by a Rockchip RK3588 octa-core Arm Cortex-A76/A55 processor, before building a computer/NAS with the Arm mini-ITX motherboard, testing various features and running benchmarks. In the first part of the review, we checked out the Radxa ROCK 5 ITX (Arm) and Jupiter (RISC-V) mini-ITX motherboards with specifications and unboxing, and the Auriga 6-Bay NAS mini-ITX chassis used in this review. I already built the computer with the Jupiter RISC-V mini-ITX motherboard, so here I simply switched the RISC-V motherboard with the Radxa ROCK 5 ITX Arm motherboard and installed a few SATA drives. Radxa ROCK 5 ITX first boot – A tricky start… Radxa provides getting started instructions on the documentation website which I mostly follow to hopefully boot within a few minutes. I had to prepare the hardware first. So I installed a […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 14 Comments on Luckfox Pico Mini – A tiny Arm Linux camera board based on Rockchip RV1103 SoC with 64MB on-chip RAM

Luckfox Pico Mini – A tiny Arm Linux camera board based on Rockchip RV1103 SoC with 64MB on-chip RAM

Luckfox Pico Mini A microSD card

Luckfox Pico Mini is a tiny (28 x 21 mm) board based on the Rockchip RV1103 Cortex-A7 camera SoC with a built-in 0.5 TOPS NPU, 64MB on-chip DDR2 RAM, USB-C port for power and data, two rows of headers with up to seventeen GPIOs, and five castellated holes for Ethernet. Two versions are offered: the Pico Mini A with a microSD card slot or the Pico Mini B with an extra 128MB SPI NAND flash. Both boards are a shorter version of the Luckfox Pico with similar features but additional GPIOs and the Luckfox Pico Plus model also adds an RJ45 Ethernet port. Luckfox Pico Mini A and B specifications: SoC – Rockchip RV1103 SoC CPU – Arm Cortex-A7 processor @ 1.2GHz + RISC-V core Memory – 64MB DDR2 NPU – 0.5 TOPS NPU with support for INT4, INT8, and INT16 ISP – 4M @ 30 fps ISP Storage MicroSD […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 17 Comments on Radxa ROCK E20C “Mini Network Titan” features 2.0 GHz Rockchip RK3528A SoC, dual GbE, metal case

Radxa ROCK E20C “Mini Network Titan” features 2.0 GHz Rockchip RK3528A SoC, dual GbE, metal case

Radxa ROCK E20C router

Radxa ROCK E20C, also “dubbed Mini Network Titan”, is a router with dual Gigabit Ethernet, a USB 2.0 host port, and a microSD card slot powered by a Rockchip RK3528A quad-core Cortex-A53 processor clocked at 2.0 GHz. Housed in a CNC aluminum alloy case, the ultra-compact fanless router is offered with 1GB to 4GB LPDDR4 memory, 8GB to 32GB eMMC flash, and also exposes two USB-C ports, one for power and the other for serial console access without having to tear down the device. Radxa ROCK E20C specifications: Processor – Rockchip RK3528A CPU – Quad-core Arm Cortex-A53 @ 2.0 GHz GPU – Arm Mali-G450 GPU with support for OpenGL ES1.1, ES2.0, and OpenVG 1.1 APIs VPU H.264, H.265, and AVS2 decoder up to 4Kp60 H.264 and H.265 encoder up to 1080p60 NPU – 1 TOPS NPU (TBC) Memory – 1GB, 2GB, or 4GB LPDDR4 Storage 8GB, 16GB, or 32GB eMMC flash […]

UP 7000 x86 SBC
